Merit 710E User Manual

Elliptical
Hide thumbs Also See for 710E:
Table of Contents

Advertisement

Quick Links

FOR MODEL :
710E
720E
EL L IPT ICA L US ER 'S GU I DE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 710E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Merit 710E

Summary of Contents for Merit 710E

  • Page 1 FOR MODEL : 710E 720E EL L IPT ICA L US ER ’S GU I DE...

  • Page 3: Table Of Contents

    CONGRATULATIONS and THANK YOU for your purchase of this Merit Fitness elliptical! Whether your goal is to win races or simply enjoy a fuller, healthier lifestyle, an Merit Fitness elliptical can help you attain it – adding club-quality performance to your at-home workouts, with the ergonomics and innovative features you need to get stronger and healthier, faster.

  • Page 4: Important Precautions

    I M PO R TAN T P RECAUT I ON S SAVE THESE INSTRUCTIONS Read all instructions before using this elliptical. When using an electrical product, basic precautions should always be followed, including the following: Read all instructions before using this elliptical. It is the responsibility of the owner to ensure that all users of this elliptical are adequately informed of all warnings and precautions.

  • Page 5: Assembly

    AS S E M BLY IMPORTANT: READ THESE SAFETY INSTRUCTIONS BEFORE USE! There are several areas during the assembly process of a elliptical that special attention must be paid. It is very important to follow the assembly instructions correctly and to make sure all parts are firmly tightened. If the assembly instructions are not followed correctly, the elliptical could have frame parts that are not tightened and will seem loose and may cause irritating noises.

  • Page 6: Tools Included

    2 Lower Link Arm assemblies 2 Wheel Covers 2 Pivoting Foot Pads (720E) Manual Resistance Knob (710E Only) 1 Top Side Cover 2 AA Batteries (710E) If you have questions or if there are any missing parts, contact Customer Tech Support.
  • Page 7 A S S E M BLY ST E P 1 MAIN FRAME BOLTS (A) WASHERS (B) FRONT FOOT TUBE A) Open HARDWARE BAG FOR STEP 1. B) Attach the FRONT FOOT TUBE to the MAIN FRAME using 2 BOLTS (A) and 2 WASHERS (B). HARDWARE BAG FOR STEP 1 CONTENTS : BOLT (A) WASHER (B)
  • Page 8 A S SE MB LY S T E P 2 MAIN FRAME PEDAL ARM COVER SCREW (C) BOLTS (D) REAR WASHERS (B) WHEEL TRACKS BOLT (A) A) Open HARDWARE BAG FOR STEP 2. B) Attach the REAR WHEEL TRACKS to the MAIN FRAME using 2 BOLTS (A) and 2 WASHERS (B) from the front. Then, finish securing the REAR WHEEL TRACKS to the MAIN FRAME by inserting 2 BOLTS (D) and 2 WASHERS (B) from above and secure to 2 NUTS (F) from below.
  • Page 9 A SS EM B LY S T EP  CONSOLE MAST CONSOLE MAST BOLT (A) SPRING WASHER (D) WASHER (B) WASHERS (B) MAIN FRAME BOLTS (E) MAIN FRAME A) Open HARDWARE BAG FOR STEP 3. B) Slide the CONSOLE MAST BOOT over the CONSOLE MAST. Carefully pull console wires through the console mast.
  • Page 10 A S SE MB LY ST E P  STEPS A-E (710E ONLY) STEPS F-H PRE-INSTALLED UPPER HANDLEBAR BOLT & WASHER RESISTANCE TOP KEY HOLE KNOB BOTTOM KEY HOLE PRE-ATTACHED SET SCREWS PRE-ATTACHED BOLTS AND WASHERS LOWER HANDLEBAR TENSION CABLE...
  • Page 11 ASS E MB LY ST EP  720E ONLY HANDLEBAR COVERS NOTE: There is NO hardware bag for this step. A) (Model 720E only) Attach WIRES from mast to handlebar. DO NOT PINCH WIRES. B) Snap the front and back HANDLEBAR COVERS together onto the UPPER HANDLE BARS. Note the position of the snap tabs on the covers before snapping into position.
  • Page 12 AS SE M BLY S T EP  HARDWARE BAG FOR STEP  CONTENTS (720E ONLY): SCREW (A) 8 mm Qty: 6 FOR MODEL 720E ONLY FOOTPAD LOWER LINK ARM SCREWS (A) A) Open HARDWARE BAG FOR STEP 6. B) Attach FOOTPAD to LOWER LINK ARM PLATE using 3 SCREWS (A). C) Repeat on other side.
  • Page 13 ASS E MB LY S T E P 7 STEP C SPACER (G) BOLT (E) TEFLON WASHERS (B) LOWER HANDLEBAR NUT (C) TEFLON WASHERS (B) LOWER LINK ARM A ) Open HARDWARE BAG FOR STEP 7. B) Align LOWER HANDLEBAR with LOWER LINK ARM. CAUTION: Be careful to keep the LOWER HANDLEBAR aligned with guide rail.
  • Page 14 C) Attach CONSOLE to the CONSOLE MAST using the 4 PRE-ATTACHED SCREWS (screws will have to be removed from the console first). DO NOT PINCH WIRES! YO U ’ R E F I N I S H E D ! 710E 720E...

  • Page 15: Before You Begin

    B E F OR E Y OU B EG I N CONGRATULATIONS! on choosing your elliptical. You’ve taken an important step in developing and sustaining an exercise program! Your elliptical is a tremendously effective tool for achieving your personal fitness goals. Regular use of your elliptical can improve the quality of your life in so many ways. HERE ARE jUST A FEW OF THE HEALTH BENEFITS OF ExERCISE: •...

  • Page 16: Elliptical Operation

    E L L I P T IC A L OPERATI ON POWER Your elliptical is powered by a power supply. The power must be plugged into the power jack, which is located in the front of the 720E near the STABILIZER TUBE. Some ellipticals also have an on/off switch located on the back of the console.
  • Page 17 7 1 0 E CO NS O L E D I SP L AY R E S E T S T A R T / S T O P Note: There is a thin protective sheet of clear plastic on the overlay of the console and should be removed. A) MONITOR DISPLAY: Speed, Time, Pulse, Distance, and Calories.
  • Page 18 7 2 0E C ON S OL E DI S P L AY Note: There is a thin protective sheet of clear plastic on the overlay of the console and should be removed. A) MONITOR DISPLAYS: Speed, Time, Pulse, Distance, Level, Calories and Program Profiles. B) START/STOP: Press to start/pause/end your workout.
  • Page 19 7 2 0 E CO NS O L E OP ER AT I ON Q U ICK S TA RT Turn on Elliptical by pressing any key. Press START button and begin exercising. Program will automatically default to MANUAL (P1), the time will count up from 0:00, and the resistance MANUAL will default to level 1.

  • Page 20: Conditioning Guidelines

    HE AR T R AT E HANDLEBARS Place the palm of your hands directly on the grip pulse handlebars. Both hands must grip the bars for your heart rate to register. It takes 5 consecutive heart beats (15-20 seconds) for your heart rate to register. When gripping the pulse handlebars, do not grip tightly.

  • Page 21: Perceived Exertion Level

    PERCEIVED ExERTION LEVEL A simple way to gauge your exercise intensity is to evaluate your perceived exertion level. While exercising, if you are too winded to maintain a conversation without gasping, you are working out too hard. A good rule of thumb is to work to the point of exhilaration, not exhaustion.
  • Page 22 STRETCHING TI P S STRETCH FIRST Before using your product, it is best to take a few minutes to do a few gentle stretching exercises. Stretching prior to exercise will improve flexibility and reduce chances of exercise related injury. Ease into each of these stretches with a slow gentle motion.
  • Page 23 T IP S THE IMPORTANCE OF A WARM-UP & COOL DOWN WARM UP The first 2 to 5 minutes of a workout should be devoted to warming up. The warm-up will limber your muscles and prepare them for more strenuous exercise. Make sure that you warm-up on your product at a slow pace.
  • Page 24 W E E K LY L O G SH E ETS WEEK # WEEKLY GOAL D AY DATE DI S TA NC E C AL OR IES T I M E CO MM E NT S S UN D AY M O N DAY T UE S DAY W E D NE S DAY...
  • Page 25 M ONTH LY L OG S H EE TS WEEK # WEEK LY GOAL DATE D IS TA NC E CA L O R IES T IME C OMM E NT S SU ND AY M OND AY TUES D AY WE DN E SD AY THUR S D AY FR IDAY...

  • Page 26: Troubleshooting & Maintenance

    • The outlet the machine is plugged into is functional. Double check that the breaker has not tripped. • The correct adapter is being used. Only use the adapter provided or authorized by Merit Fitness. • The adapter is not pinched or damaged and is properly plugged into the outlet AND the machine.
  • Page 27 • Does the problem occur when using the handlebars? Without using the handlebars? Answering these and other questions will give the technicians the ability to send proper replacement parts and the service necessary to get you and your Merit Fitness elliptical running again!
  • Page 28 CO MM O N PR OD UCT Q U E S T I O NS ARE THE SOUNDS MY ELLIPTICAL MAKES NORMAL? Our ellipticals are some of the quietest available because they use belt drives and friction free magnetic resistance. We use the highest grade bearings and belts to minimize noise. However, because the resistance system itself is so quiet, you will occasionally hear other slight mechanical noises.
  • Page 29 Clean with soap and water cleaners only. Never use solvents on plastic parts. Cleanliness of your elliptical and its operating environment will keep maintenance problems and service calls to a minimum. For this reason, Merit Fitness recommends that the following preventive maintenance schedule be followed.

  • Page 30: Limited Warranty

    • Any attempt to repair this equipment creates a risk of injury. Merit Fitness is not responsible or liable for any damage, loss or liability arising from any personal injury incurred during the course of, or as a result of any repair or attempted repair of your fitness equipment by other than an authorized service technician.
  • Page 32 US 5573480 US 7316633 US 5813949 CN 99808486.7 US 5924962 TW 364373 US 5938567 TW 371899 US 6135927 710E / 720E Rev. 2.1 | © 2006 Merit Fitness Products | Designed & Engineered in the U.S.A. | Made in China...
