Model PS20D630
20 Watt Amplified Horn
Loudspeaker
Installation and
Operating Instructions
DOCUMENT NUMBER PS20D630/OEM/01
REVISION 1.2
8th December 2008
Advertisement
Table of Contents
Related Manuals for Advanced Visual Solutions PS20D630
Summary of Contents for Advanced Visual Solutions PS20D630
-
Page 1: Operating Instructions
Advanced Visual Solutions Ltd Unit 2, Eastman Way Hemel Hempstead, Hertfordshire HP2 7DU Telephone : ( 01442 ) 252280 Fax : ( 01442 ) 244578 Email : sales@avsl.com : Website : avsl.com Model PS20D630 20 Watt Amplified Horn Loudspeaker Installation and... - Page 2 TESTING USING A PERSONAL STEREO DEVICE (e.g.MP3 Player) Page 7 REMOVING THE REAR COVER Page 7 PCB SWITCHES & VOLUME CONTROL LOCATIONS Page 8 GAIN TABLE & SWITCH SETTINGS DETAIL Page 8 DOCUMENT NUMBER PS20D630/OEM/01REVISION 1.2 8 December 2008 Page 2 of 8...
- Page 3 • Do not stand or sit on, nor hang from the unit as this may cause it to fall or drop, resulting in personal injury and/or property damage. DOCUMENT NUMBER PS20D630/OEM/01REVISION 1.2 8 December 2008 Page 3 of 8...
-
Page 4: System Overview
This unit will operate with a regulated supply Voltage range of 9 Volts DC to 18 Volts DC. Operating at Voltages lower than 18 Volts will reduce the maximum power output (e.g. at 12 Volts DC the maximum power output is approximately 8 Watts RMS). DOCUMENT NUMBER PS20D630/OEM/01REVISION 1.2 8 December 2008 Page 4 of 8... - Page 5 Do not connect (Earth at signal SOURCE end) UNBALANCED INSTALLATION Wire Colour Connect To +18VDC BLACK 0VDC WHITE Audio Cable Signal Core GREEN Loop to SHIELD SHIELD Audio Cable Screen See following sample drawings DOCUMENT NUMBER PS20D630/OEM/01REVISION 1.2 8 December 2008 Page 5 of 8...
- Page 6 DOCUMENT NUMBER PS20D630/OEM/01REVISION 1.2 December 2008 Page 6 of 8...
- Page 7 Remove the four screws which hold the rear cover in place (shown on the right). Carefully remove the cover. Take not to lose the screws or gasket and do not pull on the internal wiring. Rear View DOCUMENT NUMBER PS20D630/OEM/01REVISION 1.2 8 December 2008 Page 7 of 8...
- Page 8 TECHNICAL SUPPORT Advanced Visual Solutions Ltd provide full technical support for our products. We have two, fully equipped “central station” workstations, running the latest version of ADPRO video central gold software and HEITEL monitoring software. We can therefore connect to ADPRO or HEITEL remote transmitters, providing that they are on standard PSTN telephone lines (modem), standard ISDN lines (terminal adapter) or standard ADSL (broadband) connections.
