Milpower Source M110BA-1 User Manual

Single phase - 1kw/2kva uninterruptible power source
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
UNINTERRUPTIBLE POWER SOURCE
East Coast
Milpower Source
7 Field Lane, RTE. 106
Belmont, NH 03220
Phone: (603) 267-8865
West Coast
Hytech Associates
1498 Linda Vista Ave.
Pasadena, CA 91103
Phone: (818) 7964761
November, 2003
Publication Number: 110BA1UM, REV(B)
MILPOWER SOURCE
SINGLE PHASE – 1kW / 2kVA
M110BA-1
MADE IN THE U.S.A
USER'S MANUAL
Fax: (603) 267-7258
Fax: (818) 304-9620

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M110BA-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Milpower Source M110BA-1

Summary of Contents for Milpower Source M110BA-1

  • Page 1 MILPOWER SOURCE UNINTERRUPTIBLE POWER SOURCE SINGLE PHASE – 1kW / 2kVA M110BA-1 MADE IN THE U.S.A USER’S MANUAL East Coast Milpower Source 7 Field Lane, RTE. 106 Belmont, NH 03220 Phone: (603) 267-8865 Fax: (603) 267-7258 West Coast Hytech Associates 1498 Linda Vista Ave.

  • Page 2: Table Of Contents

    MILPOWER SOURCE 110BA1UM, REV(B) 110BA1UM, REV(B) Table of Contents Page Safety Instructions ....................iii General Description....................1 Intended Applications .....................1 Functional Overview ....................1 Setting the Input Voltage Range ................3 Installation Instructions ..................3 Front Panel Description ..................6 Front Panel: Main Components ................6 Front Panel: Indicators and Switches ..............7 Rear Panel Description ...................8...

  • Page 3: Important Safety Instructions

    MILPOWER SOURCE 110BA1UM, REV(B) IMPORTANT SAFETY INSTRUCTIONS • The M110BA-1 contains an internal high voltage, high energy power source (96VDC battery) and large high voltage (340VDC) capacitors. • The unit should not be tampered with by unauthorized personnel !!! •...

  • Page 4: General Description

    Source (UPS). In addition to full compliance with all the requirements of MIL-STD-1399 (Section 300), the M110BA-1 is specifically designed to meet the harsh military shipboard environment. The high reliability and ruggedness of the M110BA-1 make it an excellent choice not only for military shipboard applications, but for critical shore-based applications as well.

  • Page 5: Fig. 1 Block Diagram

    DC-AC 320 Vdc CONVERTER INVERTER AC OUTPUT 115VAC REMOTE INPUT 120 VDC ON/OFF ON/OFF BATTERY SWITCH SWITCH CHARGER 24 VDC MASTER ON/OFF SWITCH BATTERY CONTROL J4 RS-232 PACK & J3 DRY MONITOR CONTACTS 24VRTN 24VDC Figure 1: M110BA-1 Block Diagram...

  • Page 6: Setting The Input Voltage Range

    Use Figure 2 if it is desired to use the power conditioner as a buffer between the mains and the load when the M110BA-1 is externally bypassed. Please note that grounding of the power conditioner’s output is permitted only at the output side of the bypass selector (marked as “NEUT”...

  • Page 7: Fig. 2 Electrical Connections (With Bypass)

    MILPOWER SOURCE 110BA1UM, REV(B) PWR COND. INPUT PHASE 2 115VAC VIA TWO-POLE PWR COND. INPUT PHASE 1 20 AMP CIRCUIT BREAKER CHASSIS GND UPS IN 2 UPS IN 1 PWR COND. OUT 1 NEUT AC TO PWR COND. OUT 2...

  • Page 8: Fig. 3 Electrical Connections (Without Bypass)

    MILPOWER SOURCE 110BA1UM, REV(B) PWR COND. INPUT PHASE 2 115VAC VIA TWO-POLE PWR COND. INPUT PHASE 1 20 AMP CIRCUIT BREAKER CHASSIS GND (NOTE 2) UPS OUT 1 (NEUT) AC TO LOAD UPS OUT 2 (HOT) CHASSIS REAR PANEL GND CONN.

  • Page 9: Front Panel Description

    MILPOWER SOURCE 110BA1UM, REV(B) Front Panel Description Front Panel: Main Components (See Figure 4) Removable air filter (of the Power Conditioner’s cooling air). Visual Indicators and Switches (for detailed view see Figure 5). Air Inlet (of main UPS heatsink). Input ON/OFF Switch.

  • Page 10: Front Panel: Indicators And Switches

    MILPOWER SOURCE 110BA1UM, REV(B) Front Panel: Indicators and Switches (See Figure 5) Input ON/OFF switch. Master ON/OFF switch. Input Fail LED (red). Input OK LED (green). Output Standby LED (yellow). Output OK LED (green). 10. Output Fail LED (red). 11. On Battery Warning LED (blinking yellow).

  • Page 11: Rear Panel Description

    MILPOWER SOURCE 110BA1UM, REV(B) Rear Panel Description (See Figure 6) Cooling Fan (Air Outlet). J1 Input Power Connector (see Figure 2 for pin out). J2 Output Power Connector (see Figure 2 for pin out). GND Connection. Dry Contacts Connector J3 (see paragraph 8 for pin out description).

  • Page 12: Operation, Controls And Indicators

    MILPOWER SOURCE 110BA1UM, REV(B) Operation, Controls and Indicators (ref. Figures 4 and 5) Turning the UPS ON and OFF In order to turn the UPS ON (after an electrical connection is made), turn ON the Input ON/OFF switch (4), the Master ON/OFF switch (5) and the remote ON/OFF switch. (The order is not important).

  • Page 13: Input Ac Failure

    MILPOWER SOURCE 110BA1UM, REV(B) 6.2.3 Input AC Failure When the input AC voltage is below the minimum required for proper operation, the UPS runs on battery power. During this condition the red Input Fail LED (6) is on, the yellow On Battery Warning LED (11) blinks, and five seconds after input power loss an audible alarm starts beeping once every five seconds.

  • Page 14: Battery Test

    Charge-Discharge Cycles Temperature The battery used in the M110BA-1 is sealed and does not “dry up” or lose gasses, but its end of service life is brought about by the gradual corrosion of the electrodes. This process is accelerated by high operating temperatures. Every 10°C rise above 20°C will reduce the battery service life by half.

  • Page 15: Replacing The Battery Pack

    Replacing the Battery Pack For ease of use, the battery of the M110BA-1 is packaged within a Removable Battery Pack (MPS P/N M357380) that may be ordered separately. During storage, the Battery Pack may be removed and stored separately in a cooled ambient.

  • Page 16: Communications And Remote Control

    MILPOWER SOURCE 110BA1UM, REV(B) Communications and Remote Control Dry Contacts Interface Dry Contacts Interface is available through connector J3 ( a DB9 male connector located on the rear panel). This interface allows control and monitoring of the UPS by a server. Two configurations are available: Option 0 (Standard) and Option 1.

  • Page 17: Option 1 Dry Contacts Interface

    MILPOWER SOURCE 110BA1UM, REV(B) 8.1.2 Option 1 Dry Contacts Interface Table 2 shows J3 pin assignment for Option 1. In this option the server interfaces to the UPS via a quasi - RS232 communication link Table 2 Dry Contacts Connector J3 Pin Assignment, Option 1...

  • Page 18: Rs-232 Communication Interface

    Internally shorted to J3 pin 9. (not used by RS232 link) Remote ON/OFF Interface J5 Important note: The M110BA-1 is shipped with a matting connector plugged into J5, with a jumper that enables the unit. If remote ON/Off is not desired, do not remove it.

  • Page 19: Specifications

    MILPOWER SOURCE 110BA1UM, REV(B) Specifications Voltage 84-165VAC or 180-260VAC (selectable) without switching to battery power. INPUT (below this level the battery will be used). Frequency 48-64 Hz Power Factor > 98% Spikes 200 joules clamping device Isolation Input is galvanically isolated from output and chassis (> 1 MΩ at 600VDC).
  • Page 20 The alarm may be silenced by pressing the "Alarm Off" push-button on the front panel. d) Power The M110BA-1 has two double-pole contactors, one on the input and one on Switches the output. The input ON/OFF contactor is controlled by the input ON/OFF switch located on the front panel.
  • Page 21 MILPOWER SOURCE 110BA1UM, REV(B) INTERFACE Discrete Four dry contacts indicating the following conditions: interface "UPS ON" (Output OK) "Battery Voltage Low" "Input Power Loss" (Battery Operation) "Fault Detect" A "Shutdown" input (via opto-isolator) for remote shutdown of the UPS during AC input fail.
