Summary of Contents for Inline MSV0502
- Page 1 MSV0502 VGA MATRIX SWITCHER M SV0502 OPERATION MANUAL High Resolution Video Products • A/V System Integration Tools • Interactive Training Systems...
- Page 2 Para prevenir un incendio, reemplace solo con el mismo tipo de fusible. CE COMPLIANCE All products exported to Europe by Inline, Inc. after January 1, 1997 have been tested and found to comply with EU Council Directive 89/336/EEC. These devices conform to the following...
-
Page 3: Table Of Contents
Table of Contents Product Overview ............................2 Description............................2 Product Features..........................2 Compatibility ...............................3 Video Inputs............................3 Audio Inputs............................3 Analog Audio Signals.......................3 Video Outputs ..........................3 Audio Outputs..........................3 Analog Audio Signals.......................3 Comparison with MSV0804......................3 Installation ..............................4 Operation ..............................7 Front Panel Controls ........................7 Switching - Connecting Inputs & Outputs (Front Panel) ..............7 To make a connection between an input and an output:............7 To select a different input: ....................7 To blank the output:......................7... - Page 4 Select the serial communication protocol format for the serial port as required according to the chart below. Serial Format Dipswitch Settings RS-232* 123 OFF RS-422/485 123 ON *Factory default © 2002 - INLINE, INC. MSV0502 Matrix Series Switcher Quick Start - v1.0 1/29/02...
- Page 5 Press the Mute button to alternately Example: To patch input 5 to output 2, press: silence / restore audio output. Output 2 button followed by Input 5 button. MSV0502 Matrix Series Switcher Quick Start - v1.0 1/29/02 © 2002 - INLINE, INC.
-
Page 6: Product Overview
Product Overview Description MSV0502 is a compact 5 x 2 VGA and stereo audio matrix switcher featuring VGA stereo audio matrix switching, 450 MHz video bandwidth and one switching mode. It is ideal for permanent installations, rentals, complex staging operations and any other display system requiring a high performance, economical VGA stereo audio matrix switcher. -
Page 7: Compatibility
Comparison with MSV0804 The MSV0502 and MSV0804 matrix switchers are virtually identical. Besides the number of inputs/outputs, the only other difference between the two units is that the MSV0502 is 1U and the MSV0804 is 2U in height. 2002 - INLINE, INC. -
Page 8: Installation
Note: power supply cord connected to the unit 1. Place/install the MSV0502 at the desired location. Seat the unit on a flat surface or securely install it in a standard 19" equipment rack using the MTR102 rack ears (provided). The MSV0502 is exactly 1U high without the feet. -
Page 9: Application Diagram
MSV0502-3 MATRIX SWITCHER APPLICATION DIAGRAM = Video = Audio = Aux. Power = Control input devices Local Laptop Monitor IN8200 Cable CIA111-1 Computer Interface Local Monitor IN1404 Video Scaler DAV101CM VGA Line Driver DAV101CM Power Video Input Line Driver DAS101CM Audio Buffer... - Page 10 MSV0502 VGA MATRIX SWITCHER CONNECTORS & CONTROLS IR Window BLANK PRESET VOLUME MUTE INPUT SELECT OUTPUT SELECT MSV0502 VGA Matrix Switcher Mute Button Input Buttons Output Buttons Blank Volume Button Buttons Preset Button Front Rear View View Auxiliary Power Ports...
-
Page 11: Operation
Press the button of the input you desire. To blank the output: Press the Blank button. Once you select an output, you can change the input as many times as desired. 2002 - INLINE, INC. MSV0502 OPERATION MANUAL - v1.0 4/26/02... -
Page 12: To Configure A New Input/Output Patch
Switching and defining multiple groups is only feasible if you control the unit via RS-232. Audio The MSV0502 routes stereo audio along with the video. The audio for the selected input routes to the selected output. The MSV0502 has Volume Up and Down buttons as well as a Mute button. These buttons function as follows: Volume Up/Down - The Volume Up button increases the output volume;... -
Page 13: Adjusting Input Audio Volume Level
To mute and/or restore audio output: Press the Mute button to alternately silence/restore audio output. Serial Port Pin-Outs The MSV0502 utilizes a 5-pin captive screw terminal block. The pin configurations are as follows: For unbalanced For balanced Stereo For unbalanced... -
Page 14: Rs-232/422/485 Connections
Dipswitches make subtle adjustments to that signal type. Configure the dipswitch settings according to the following table. Serial Format Dipswitch Settings RS-232* 123 OFF RS-422/485 123 ON *Factory default 2002 - INLINE, INC. MSV0502 OPERATION MANUAL - v1.0 4/26/02... -
Page 15: To Create A Preset
#1. Power-on Settings To power the MSV0502 up, simply plug the unit it the outlet. There is no power on/off switch. Reset to Factory Default Soft Reset - To restore I/O configurations, volume levels, and the serial set up to the default factory setting, press the 1 and 5 input buttons. -
Page 16: Remote Operation
The MSV0502 recognizes [ and ] as leading and ending characters, also called Command Codes. The factory default for the Command Code is [ ]. The Command code can be changed via RS-232. Some sample command codes follow. -
Page 17: Using The Ctl 120-2 Remote Control
CTL 120-2 IR Remote Control sends infrared commands to the CTL101. The CTL101 will convert these IR signals to serial commands so you can control functions on the MSV0502 matrix switcher. A diagram outlining the location and function of each button is provided on page 19. -
Page 18: Serial Commands
For the MSV0502, ii would be 01 – 05 and oo would be 01 – 02, while the MSV0502, ii would be 01 – 08 and oo would be 01 - 04. -
Page 19: Set-Up Commands
Audio boards (A). For commands that use level designators see Switching Commands below. Default levels include: • Level 1 - RGBHVA • Level 2 - RGBHV • Level 3 - Audio only 2002 - INLINE, INC. MSV0502 OPERATION MANUAL - v1.0 4/26/02... -
Page 20: Switching Commands
= - (minus sign) to decrement output volume o x = @ to return output volume to factory default o x =? to request current volume level 2002 - INLINE, INC. MSV0502 OPERATION MANUAL - v1.0 4/26/02... - Page 21 Sets input volume level for a specific input. [VINiixxx] • Where o oo = 01 - 05 for input o xxx = -640 - 000 o Note: 000 equals max (factory default), -640 equals minimum 2002 - INLINE, INC. MSV0502 OPERATION MANUAL - v1.0 4/26/02...
-
Page 22: Preset Commands
The MSV0502 and MSV0804 have the ability to store and recall common configurations. Both units offer 32 presets available via serial control. The MSV0502 has 7 presets available via the front panel while the MSX0804 has 12 presets available via the front panel. - Page 23 2002 - INLINE, INC. MSV0502 OPERATION MANUAL - v1.0 4/26/02...
-
Page 24: Specifications
17" W x 11.35" D x 3.50" H (excluding mounting flanges) Weight 10 lbs. Regulatory Compliance Safety UL 1950, 3 Ed.; CE: EN60950-92; CAN/CSA-22.2 No. 950 3 FCC class A; CE: EN50081-1, EN55022, EN50082-1 2002 - INLINE, INC. MSV0502 OPERATION MANUAL - v1.0 4/26/02... - Page 25 MSV0502 VGA MATRIX SWITCHER PRODUCT DIMENSIONS 11.35" 1.78" 1.98" 0.20" right side view 17.03" 11.35" top view 17.03" BLANK PRESET VOLUME MUTE 1.78" 1.98" 0.20" INPUT SELECT OUTPUT SELECT MSV0502 VGA Matrix Switcher front view 17.03" OUTPUTS AUX POWER PORTS 90-260VAC;...
-
Page 26: Warranty
• If equipment fails because of such defects and INLINE is notified within three (3) years from the date of shipment, INLINE will, at its option, repair or replace the equipment at its plant, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifications.
