- Page 1 AEC-6293M 1-ch eSATA/ 1-ch SATA/ 1-ch IDE Adapter User's Manual Version: 1.1 Copyright©2008 ACARD Technology Corp. Release: March 2008...
-
Page 2: Copyright And Trademarks
ACARD is the trademark of ACARD Technology Corp. Microsoft and the Windows Logo are the registered trademarks, and Windows is the trademark of Microsoft Corporation. All brands and trademarks are the properties of their respective owners. -
Page 3: Table Of Contents
Table of Contents Chapter 1 Introduction ............... 1.1 Overview ................1.2 Features ................1.3 Specifications ..............1.4 OS Compatibility ..............1.5 Package and Others ............1.5.1 Package ................ 1.5.2 Spec Parameters ............1.5.3 Connectors ..............Chapter 2 Installation ..............2.1 Hardware Installation ............2.2 Software Installation ............ - Page 4 Member nations already established their free of charge recycle systems of WEEE before August 13, 2005. Accordingly, ACARD has to be responsible for recycling all products exported to Germany. You can return your ACARD product that needs recycling to a local collector.
- Page 5 électrique usagé. Depuis le 13 août 2005, les pays membres ont mis en place un système de recyclage gratuit selon le WEEE,. De ce fait, Acard est responsable du recyclage de tous les produits exportés vers l’Allemagne. Vous pouvez mettre au rebut votre équipement ACARD usagé dans votre centre local de recyclage.
-
Page 6: Chapter 1 Introduction
ACARD AEC-6293M is a 32-bit/66MHz, 1-ch eSATA/ 1-ch SATA/ 1-ch PATA and high-performance PCI to SATA II/ PATA card for Mac computer. Within ACARD’s latest cutting-edge single chip, the speed of its SATA ports can reach 3.0Gbps and can be switched to 1.5Gbps manually. Moreover, its eSATA/ SATA II ports include port multiplier that can expand your storage by connecting to a SATA RAID subsystem such as ANS-9050 SATA RAID family. -
Page 7: Package And Others
AEC-6293M Manual 1.5 Package and Others 1.5.1 Package AEC-6293M × 1 Internal Serial ATA Cable × 1 IDE Cable × 1 ACARD Support CD × 1 User's Manual × 1 1.5.2 Spec Parameters Temperature: Operation: -20° C to 60° C Non-operation: -20°... -
Page 8: Chapter 2 Installation
PCI Slot 4. Screw the AEC-6293M onto the chassis 5. Connect AEC-6293M with a SATA/ IDE hard drive via SATA/ eSATA/ IDE cable and connect the power cord to the hard drive properly. 6. Clost the chassis and power on the system. -
Page 9: Chapter 3 Firmware Update
Chapter 3 Firmware Update 1. Extract “6293M_1.04 UpdateRom Utility” from “Support CD\IDE\6293M” to your local hard disk. 2. Open “ACARD Update ROM Utility” program. 3. Selects ACARD6293M for update firmware. 4. Selects current firmware to update and click “OK” to continue. -
Page 10: Chapter 4 Troubleshooting
A. Mac cannot boot up after install AEC-6293M HBA. It could be: 1. AEC-6293M touch area with PCI slot are not clean, please use rubber to clean touch area. 2. Install the AEC-6293M not properly, please re-install it again. 3. PCI card conflict with AEC-6293M, please remove other card and install AEC-6293M first. -
Page 11: Technical Support Form
AEC-6293M Manual Technical Support Form Email address: support@acard.com Website: http://www.acard.com Model Name* (ex: AEC-6293M) Firmware version* System Configuration Motherboard/System model* SCSI host adapter/chip brand & model* SCSI host BIOS version Other I/O card* Operating System* SATA HDD brand & model*...
