Ver 1.0.0.1
Quick Installation Guide for 3G Super Modem
1. 3G Super Modem Packing List :
Before you start installing 3G Super Modem, please verify that the package contains the
following items:
One Set of 3G Super Modem
1x Power Adapter
1x 3G Antenna
External 3G Antenna with 3M Antenna Cable (Optional)
1x RJ45 Cable
User's Manual and this Quick Installation Guide
NOTE: Please notify your sales representative immediately if any items listed above is missing or damaged.
2. Hardware Connection Settings for the 3G Mode
(Please skip this section if you would like to use the Bridge mode connection. For more details about the mode
switching, please jump to Section 4.)
1) Connect PC to LAN port of your 3G Super Modem using a RJ45 cable.
2) Screw the antenna to 3G ANT SMA connector on your 3G Super Modem.
3) Make sure the SIM card has inserted to the SIM card slot on your 3G Super Modem, and the
modem is ready as well.
4) Connect the power cable to the power connector of your 3G Super Modem.
1
