Summary of Contents for 3Jtech ILP 0001
- Page 1 ILP 0001 User’s Manual Revision 1.0 3J Tech Co., Ltd. 342 Fu-Hsing N. Rd., 2F Taipei, Taiwan Tel: +886-2-2500 6916 info@3jtech.com.tw 3JTech (A3J Eng.), Inc. 15344 E. Valley Blvd., Suite C City of Industry, CA 91746 USA Tel: 1-626-934 7600 info@3jtech.com...
- Page 2 Related Documents or Files 1) ISSC ISBTM8-3 Bluetooth Module specification.. 2) SI3014 silicon DAA data sheet. 3) IP568x –DS-P02-010815 modem chip set data sheet 4) BPM 0001 & ILP 0001 Instruction manual Table of Contents General Description Application Specification Block diagram AT commands...
-
Page 3: General Description
General Description The ILP 0001 is a highly integrated, low-cost, high performance, and low-power dissipation wireless modem. This wireless modem implements V.90 to achieve Internet connection rates up to 56Kbps, supporting existing V.34 data mode, DTE terminal and provide reliable connection with connection rate ranging from... - Page 4 Specification . Data mode capabilities: . ITU-T V.90 . ITU-T V.34 . ITU-T V.32bis, V.32 . ITU-T V.22bis,V.22 . ITU-T V.23, V.21 . Bell 212 . Bell 103 . V.42 error correction (LAPM and MNP) . V.42bis and MNP class 5 data compression . TIA/EIA 602 standard for AT command set .
- Page 5 Advanced Ceramic X AT9520 Series Multilayer Chip Antenna Features Monolithic SMD with small, low-profile and light-weight type. Wide bandwidth Applications 2.4GHz WLAN, Home RF, Bluetooth Modules, etc. Specifications Frequency Peak Gain Average Gain Part Number Range VSWR Impedance (XZ-V) (XZ-V) (MHz) AT9520- 50 Ω...
- Page 6 IDEAL LIFE Pod™ Location/Interferance IDEAL LIFE Pod™ Location/Interferance When using an IDEAL LIFE Pod™ to communicate information from your IDEAL LIFE BP-Manager™, wireless radio waves are used. For maximum distance and interference-free operation, the recommended IDEAL LIFE Pod™ location is: •...
- Page 7 Before You Start Before You Start To assure the correct use of the product basic safety measures should always be followed including the precautions listed below: • Read all information in the instruction manual and any other literature included in the box before using the unit.
- Page 8 Before You Start YOUR IDEAL LIFE Pod™ Power button LED Display AC Adapter Jack Telephone line cord RJ11 Jack For Telephone Connection Telephone line cord RJ11 Jack For Line Connection Battery Cover Instruction Manual...
- Page 9 Installation Installation ! FOR YOUR IDEAL LIFE Pod™ ! Connecting your IDEAL LIFE Pod™ USING AN RJ11 JACK CAUTION! • Unplug phone cord from wall before installing, plugging in an external power source, or changing batteries. • Never install telephone wiring during a lightning storm. •...
- Page 10 Installation Press the POWER button on top of the IDEAL LIFE Pod™ to begin. RECHARGING BATTERIES WITH YOUR IDEAL LIFE POD™: • Remove the battery compartment door on the bottom of your IDEAL LIFE Pod™ by pushing gently in the direction shown on the battery cover. •...
- Page 11 Installation POWERING UP YOUR IDEAL LIFE BP-Manager™ INSTALLING THE BATTERIES (INCLUDED) • Remove the battery compartment door on your IDEAL LIFE BP-Manager™ by lifting the battery door using the notch • Place the batteries as instructed • Replace the battery compartment door and click into place FIRST TIME POWER UP AND ACTIVATION To use the IDEAL LIFE BP-Manager™...
- Page 12 Installation On the next screen, you will be asked to confirm your IDEAL LIFE Pod™ ID number, so as to ensure that you are LINKING your IDEAL LIFE BP-Manager™ with your IDEAL LIFE Pod™ correctly. Simply use the buttons labelled YES or NO to confirm the number. You will find the IDEAL LIFE Pod™ ID number displayed on the bottom of the IDEAL LIFE Pod™...
- Page 15 FCC Label Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 16 ILP 0001 User’s Manual AT Command Set...
- Page 17 In Request Identification Information Section 1. Data Mode Command This command displays specific product information about the modem. A/ Executes Last Command Returns product ID code. When modem receives this command, modem executes Display Firmware version and checksum on the the last command string entered.
- Page 18 On Return Online to Data Mode Xn Result Code Selection and Call Progress detection O0* Exit online command mode and return to data mode This command enables tone detection options during (see AT Escape Sequence, +++AT). (Default) dialing procedure. As these functions are chosen, the O1 This command issues a retrain before returning to modem chip set result codes are also affected.
- Page 19 Zn Recall Stored Profile &Pn Pulse Dial Make-to-Break Ratio Selection This command instructs the modem chip set to go &P0 39/61 make-to-break ratio (10 pps). on-hook and restore the profile saved by the last &W &P1 33/67 make-to-break ratio (10 pps). command.
- Page 20 &Yn Select Stored Profile for Power On or Reset *In Connect Speed Selection This command does not change the behavior of the Selects connect speed 1200bps modem but is included for compatibility with applications Selects connect speed 2400bps that issue the &Y0 command Selects connect speed 4800bps &Y0* Select stored profile 0.
- Page 21 *NCnn Country select \Nn Error Control Mode Selection This command provides customers chose the country for This command determines the type of error control used phone line regulation. by the modem when sending or receiving data. Normal mode. *NC40 Australia Direct mode.
- Page 22 Section 2. Result Code Section 3. S Registers Definitions S registers generally affect how the AT commands Long Form Short Form n value in ATXn perform. Contents of the registers can be displayed or 0 1 2 3 4 modified when the modem is in command mode. x x x x x To display the value of an S register: TYPE: ATSn?, CONNECT...
- Page 23 S6 Wait Before Dialing This register sets the value (in 20 ms increments) for the This register sets the length of time, in seconds, that the required pause after the escape sequence (default 1 s). modem must wait (pause) after going off-hook before Range: 0-255 dialing the first digit.
- Page 24 S22 Bit mapped Register Bit-mapped register S22 lets you control internal speaker Value Function and the modem responses. Mapping to AT*I Mapping to AT&U Bit Function 0,1= 0 Speaker volume off (L0) S30 Inactivity Timer 1 Low speaker volume (L1) S30 specifies the length of time (in minutes) that the 2 Medium speaker volume (L2) –...
- Page 25 This command causes the modem to receive data at the Section 4. Class 1 FAX Commands modulation specified by <m>. The modem chip set supports FAX commands conforming to EIA standard 578. These commands are +FRM = 24 V.27ter 2400 given here with short descriptions;...
- Page 26 sds=128 Normal level of sensitivity(-40dbm) Section 6. AT%TTn Commands sds>= 128 More aggressive ;ex. sds=129 is –39dbm %tt0=0 erase %TT command sds<= 128 Less aggressive :ex sds=127 is –40dbm %tt2=A,B,C,D Tx v34 signal parameter sdi :Specify the amount of time the modem will A: baudrate (parameter range:0-5) report silence to DTE B: data rate (parameter range:1-9 if a=0)
- Page 27 %tt5=10 : V17 14400 short train %tt5=11 : V17 14400 long train...
