Chameleon Labs
Model TS-2
Tube Condenser Microphone
Owner's Manual
th
704 228
Avenue NE, # 826
Sammamish, WA 98074
206-264-7602
www.chameleonlabs.com
Revision B - September, 2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TS-2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Chameleon Labs TS-2

  • Page 1 Chameleon Labs Model TS-2 Tube Condenser Microphone Owner’s Manual 704 228 Avenue NE, # 826 Sammamish, WA 98074 206-264-7602 www.chameleonlabs.com Revision B - September, 2006...
  • Page 2: Unpacking And Inspection

    As an option, the TS-2 can also be ordered, or factory modified to include a hand selected tube as well as circuit changes to enhance its sonic character for discriminating users.
  • Page 3 After ten to fifteen seconds, you can lift the STANDBY switch. The TS-2 will soon begin to output an audio signal from the 3-pin XLR jack. It requires about five minutes for the microphone to warm up completely, though a period of fifteen minutes is recommended to assure that the TS-2 has fully stabilized and has attained its optimum operating temperature.
  • Page 4 Maintenance A spare fuse is included with your TS-2 power supply. It is located in the fuse carrier just above the AC receptacle. To access the fuse, gently pry out the carrier with a flat bladed screwdriver.
  • Page 5 TECHNICAL SPECIFICATIONS TRANSDUCER TYPE: Diaphragm: 1-inch diameter, gold sputtered Diaphragm thickness: 3-microns VACUUM TUBE: 12AT7 - high-frequency twin triode tube Output impedance: 160 ohms Sensitivity: -35dB = 17.8mV/Pa Noise: 18.5dB-A Maximum Output: 700mV = 126dB SPL Frequency Response: 20Hz – 20 kHz +/- 4 dB. DIMENSIONS AND WEIGHT Carrying case with microphone, power supply, shock mount and cables: lbs.
  • Page 6 WARRANTY AND LIABILITY Your Chameleon Labs product is warranted to the original owner for a period of one year. Chameleon Labs guarantees this product to be free from electrical and mechanical defects and will repair or replace defective components, or replace the microphone at Chameleon Lab’s option.
