Installation and Operating
Instructions for Gas Log
Heaters
Models: PS24RN, PS24RP
Models with "N" after the model number use natural gas; models with "P" after the model number use propane (LP) gas.
This appliance operates as an unvented room
heater certified under ANSI Z21.11.2-2000 when
fitted to a solid fuel burning masonry or factory
built fireplace with the flue damper closed. It also
operates as a decorative appliance under ANSI
Z21.60a-2000.CSA 2.26a-2000, when fitted to a solid
fuel burning masonry or factory built fireplace with
the flue damper open. When used as a decorative
appliance, the use of a thermostat is not allowed.
State or local codes may only allow operation of
this appliance in a vented configuration. Check
your state or local codes.
If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
—
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
•
Do not try to light any appliance.
•
Do not touch any electric switch; do not use any phone in your building.
•
Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instruc-
tions.
•
If you cannot reach your gas supplier, call the fire department.
—
Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be provided. Refer to Section Provisions For Adequate
Combustion and Ventilation Air - Page 4.
5L24
READ AND SAVE THESE INSTRUCTIONS
WARNING
FOR YOUR SAFETY
WHAT TO DO IF YOU SMELL GAS
Gas Fired
Unvented
Room Heaters
PATENT NO. US 6,390.808 B1
Temco Fireplace Products
410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777
76683 11/03 Rev. 14
Advertisement
Table of Contents
Related Manuals for Temco PS24RN
Summary of Contents for Temco PS24RN
- Page 1 Installation and Operating Instructions for Gas Log Heaters Models: PS24RN, PS24RP Models with “N” after the model number use natural gas; models with “P” after the model number use propane (LP) gas. READ AND SAVE THESE INSTRUCTIONS This appliance operates as an unvented room heater certified under ANSI Z21.11.2-2000 when...
-
Page 2: Table Of Contents
Warranty Information ........................19 Installation and Startup Checklist ..................... 20 Warranty Registration ......................... 22 Minimum Dimensions for Existing Solid Fuel Burning Fireplaces Opening Height Front Width Rear Width Depth Hearth Size Table PS24RN 18” 30” 21” 15” PS24RP 18” 30” 21”... -
Page 3: Important Information
Important Information INSTALLER: Please leave these instructions with the minimum free (vent) opening area of 15 sq. ins. This must owner. be accomplished by a clamp or screw on the chimney OWNER: Please retain these instructions for future damper to stop at the minimum vent area. The fireplace must also have a minimum free (vent) opening of 15 sq. -
Page 4: Provisions For Adequate Combustion Air
Provisions for Adequate Combustion and Ventilation Air ________(volume of space) ÷ 50 cu. ft. = (Maximum BTU/ WARNING: This heater shall not be installed in a Hr the space can support. confined space or unusually tight construction unless Example: 5,000 cu. ft. (volume of space) ÷ 50 cu. ft. = 100 provisions are provided for adequate combustion or 100,000 (maximum BTU/Hr the space can support) ventilation air. - Page 5 Unusually tight construction is defined as construction If your home meets all of the three criteria above, you must where: provide additional fresh air. a. walls and ceilings exposed to the outside atmosphere have You may provide two permanent openings: one within 12" of a continuous water vapor retarder with a rating of one perm the ceiling and one within 12"...
-
Page 6: Installation
Installation Unpacking However, it is recommended that these instructions be followed even when the appliance will be used as a vented decorative Open both cartons and remove the logs and the chassis. appliance in case local codes change to allow unvented space Remove each of the logs by gripping at either end of the log heaters or in the event that the flue damper is inadvertently while avoiding any undue pressure. -
Page 7: Gas Connection
12" 6" 62" 27" 1¹⁄₂" 20" 11¹⁄₂" 2" Fireplace Hearth Level Fig. 4A Minimum clearance to wall and ceiling. Fig. 4C Mantel clearances (single or multi-sided opening fireplaces). Combustible 10" Materials Allowed Combustible Mantel in Shaded Areas Noncombustible 6" Facing 21"... - Page 8 Piped Gas Supply Less Than 6’ Piped Gas Supply Drop Manual Shut-Off Valve Horizontal If using flexible connector, check local Ground Joint codes for specific 1/8” N.P.T. Plugged Union requirements Hole for Test Gauge Fitting Valve Ground Joint Nipple Piped Gas Supply Union 3”...
-
Page 9: Gas Line Pipe Sizing
Gas Line Pipe Sizing NOTE: To determine the size of the branch gas line from the main gas line to the fireplace, enter the tables below (for iron pipe or copper tubing) using the distance from the gas meter or second stage regulator to the furthest appliance on the gas system. -
Page 10: Log Assembly
WARNING Log Retaining DANGER OF PROPERTY DAMAGE, Clip BODILY INJURY OR DEATH. Never use a match or open flame to test for leaks. Never exceed specified pressures for testing. High pressures may damage the appliance regulator which would require replacement. Liquid petroleum (l.p.) is heavier than air and it will settle in any low area, including open depressions and it will remain there unless area is ventilated. -
Page 11: Optional Wireless Remote Installation
Optional Wireless Remote Installation Recommended Maximum Lead Length (Double Wire) When Using Wall Switch or Thermostat Two remote control kits are offered. The standard ON/OFF model is a WRD-I and the thermastatic model is a WRST-K Wire Size Maximum Length The remote receiver will be similar to that shown in Figure 12, 14 ga. - Page 12 Turn knob Turn knob clockwise counterclockwise to increase flame to decrease flame T155 Fig. 13 Flame control knob. A - Existing valve wiring (Do not tamper with) B - Remote receiver wires (red or white) on either side T148 Fig. 16 Attach remote receiver terminals to out two connec- tors.
-
Page 13: Lighting Instructions
For Your Safety, Read Before Lighting WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot which must be lighted by hand. •... -
Page 14: Important Safeguards
Natural Gas 1¹⁄₂" 1¹⁄₂" Air Shutter Settings - Dim “A” Model Blue Flame Yellow Flame Front Burner Rear Burner T122 PS24RN 0.250” Closed Fig. 23 Pilot flame position and location. T134 PS24RP 0.500” 0.250” Fig. 25 Air shutter settings. 76683... -
Page 15: Managing Heat Output
Managing Heat Output The heat output from the appliance can be controlled by the Whenever the appliance is operated with the fireplace's position of the flue damper on vented fireplaces. flue damper closed, glass doors - if present - must be open and the outside air damper and the ash dump (if the The damper setting should be fully closed for maximum heat fireplace is equipped with either one) must be closed. -
Page 16: Troubleshooting
Always check for gas leaks after servicing. Repair Parts Always include the correct name, part number, model number, Temco Fireplace Products control type and serial number of the appliance when ordering 410 Admiral Blvd. service parts. Refer to the parts list below. - Page 17 17, 18 16, 18 76683 PS24RN/RP Description PS24RN PS24RP Qty. Grate Assembly 76512 76512 Log - Support 76511 76511 Log Retainer Clip 76517 76517 Pilot Bracket (for OP ODS) 76513 76513 Yellow Flame Burner 76719 76719 Blue Flame Burner 76720...
- Page 18 PS24RN/RP (continued) 3/8” Tee 71134 71134 Knob, Ext. - Pilot 76402 76402 Knob, Ext - HI/LO 76403 76403 3/8” Blk Pipe by 1” Long Thread 71867 71867 Lava Gravel Assy 20000198 20000198 Ember Coals 74511 74511 24” Log Kit PL24 PL24 Front Log 24”...
-
Page 19: Warranty Information
TEMCO, any component covered Pages 18 and 19 of this manual. under this warranty is found to be defective, TEMCO will, The limited warranty applies only to the original owner of at its option, repair or replace the defective component at... -
Page 20: Installation And Startup Checklist
INSTALLATION AND STARTUP CHECKLIST Customer Copy NOTE: TEMCO Fireplace Products gas logs and fireplaces require installation by a qualified gas appliance installer. A copy of this checklist must be submitted, along with proof of purchase, when applying to Technical Services for prior written approval of warranty repair or replacement. - Page 21 INSTALLATION AND STARTUP CHECKLIST Installer’s Copy NOTE: TEMCO Fireplace Products gas logs and fireplaces require installation by a qualified gas appliance installer. A copy of this checklist must be submitted, along with proof of purchase, when applying to Technical Services for prior written approval of warranty repair or replacement.
-
Page 22: Warranty Registration
Mississauga, Ontario Canada L5T 2N6 Serial # ______________________________________ Model # ______________________________________ I certify that I have followed all codes and regulations and adhered to the TEMCO installation instructions. I have completed the proper installation and startup checklist. Installer’s Signature Print Installer’s Name...
