FW1177 User's Manual
Class A Digital Device (industrial & commercial environment)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CE and
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
M4042-04
FW1177 User's Manual
(Product Guide)
Version 4.14(Rev.E)
April 13, 2012
1
Seyeon Tech Co., Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FW1177-DE and is the answer not in the manual?

Questions and answers

Related Manuals for Flexwatch FW1177-DE

Summary of Contents for Flexwatch FW1177-DE

  • Page 1 FW1177 User’s Manual FW1177 User’s Manual (Product Guide) Version 4.14(Rev.E) April 13, 2012 Class A Digital Device (industrial & commercial environment) This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CE and FCC Rules.
  • Page 2 Trademarks FlexWATCH ® and FlexWATCH ® Logo are trademarks of Seyeon Tech Co., Ltd. Windows and Internet Explorer are a trademark of Microsoft Corporation.

  • Page 3: Table Of Contents

    EATURES 1.3............................6 ECHNICAL PECIFICATION 1.4. FW1177 P ..............................9 ACKING HARDWARE DESCRIPTION ......................10 2.1. FW1177-DE ................................10 2.2. FW1177-FP ................................. 11 FW1177 INSTALLATION AND BASIC SETUP ................. 12 3.1..............................12 EFORE NSTALLATION 3.2............................12 ACTORY...

  • Page 4: Product Overview

    1. Product Overview 1.1. FW1177 FlexWATCH® 1177 is a stand-alone device transmitting video from built-in PTZ camera over IP network. There is one type of FW1177 model: DE and FP. It can transmit up to 30fps@D1(DE)/2M(FP) over the existing network. You can monitor video of FW1177 through web browser(ie.

  • Page 5: Key Features

    FW1177 User’s Manual 1.2. Key Features Standalone device built-in web server 10M/100M Auto-Sensing Ethernet Configuring and controlling through Web browser Max 30/25 fps transmission rate at maximum resolution Effective Bandwidth & Bit-rate Control (VBR/CBR) by H.264 Supports Dual Stream (MJPEG & H.264) Built-in 2 way Audio transmission (1ch A-in, 1 A-out) Support Dynamic IP network by IPCCTVDNS server Support PTZ (Pan/Tilt/Zoom) function...

  • Page 6: Technical Specification

    FW1177 User’s Manual 1.3. Technical Specification FW1177-DE FW1177-FP 32bit Embedded CPU NAND Flash 128Mbytes / DDR2: 128Mbytes Hardware Linux version 2.6.xx operating system Battery backed up real-time clock 1/2.8” progressive scan CMOS 1/4”Sony 410K Super HAD CCD Active pixels 2080H x 1553V, 3.23M Resolution: 520 TV Lines Effective pixels 2096H x 1561V, 3.27M...
  • Page 7 FW1177 User’s Manual 8 bit PCM (G.711-u-low), Sampling rates 8KHz, Mono Audio Audio 1ch in & 1ch ou LAN interface 10/100BaseT Ethernet auto sensing Alarm I/O Interface 1 Photo-coupled inputs and 1 Relay output Input Impedence : 4 KOhm Pantom Power : 3.3 Volt Audio Input(MIC) Gain : 20 dB Jack : 3.5mm Mono...
  • Page 8 Windows XP Pro or later Internet Explorer 6.x or later Powerful API for software integration available at http://www.flexwatch.com, including Simple Viewer API, FlexWATCH Control SDK, event trigger data in video stream, System integration embedded scripting and access to serial port peripherals over HTTP/TCP...

  • Page 9: Fw1177 Packing List

    FW1177 User’s Manual 1.4. FW1177 Packing List FW1177 (Bracket Separate) Power Supply Unit (24V AC Power Cord) (Power Cable & SMPS DC12V 3A Adapter) CD (User’s Manual, IP Installer and etc) Table 2 : FW1177 Packing List Note: Please check all the listed items are included in your package. For any missing items, please contact your local distributor.

  • Page 10: Hardware Description

    FW1177 User’s Manual 2. Hardware Description 2.1. FW1177-DE Picture 2 : FW1177-DE Name Description PTZ Camera Camera supporting PTZ(Pan/Tilt/Zoom) BODY Frame Body Frame for Camera Bracket Wall Mount Bracket (Separate) Table 3 : FW1177-DE M4042-04 Seyeon Tech Co., Ltd...

  • Page 11: Fw1177-Fp

    FW1177 User’s Manual 2.2. FW1177-FP Picture 3 : FW1177-FP Name Description PTZ Camera Camera supporting PTZ(Pan/Tilt/Zoom) BODY Frame Body Frame for Camera Table 4 : FW1177-FP M4042-04 Seyeon Tech Co., Ltd...

  • Page 12: Fw1177 Installation And Basic Setup

    Connect the power supply of FW1177. After that, you need to follow the steps below. Network Configuration: Refer to “IP Installer User’s Manual” Camera Configuration: Refer to “FlexWATCH Admin Menu User’s Manual” Service Configuration: Refer to “FlexWATCH Admin Menu User’s Manual” M4042-04...
