FW1178 User's Manual
Class A Digital Device (industrial & commercial environment)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CE and
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
M4049-02
FW1178 User's Manual
(Product Guide)
Version 4.12(Rev.E)
February 7, 2012
1
Seyeon Tech Co., Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FW1178 and is the answer not in the manual?

Questions and answers

Related Manuals for Flexwatch FW1178

Summary of Contents for Flexwatch FW1178

  • Page 1 FW1178 User’s Manual FW1178 User’s Manual (Product Guide) Version 4.12(Rev.E) February 7, 2012 Class A Digital Device (industrial & commercial environment) This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CE and FCC Rules.
  • Page 2 Revised: February 7, 2012 About This Document This document is prepared for users of FW1178 supplied by Seyeon Tech Co., Ltd. It is assumed that the users are familiar with Microsoft Windows operating systems and Web browsers such as Internet Explorer.

  • Page 3: Table Of Contents

    1.3............................6 ECHNICAL PECIFICATION 1.4. FW1178 P ..............................9 ACKING HARDWARE DESCRIPTION ......................10 2.1. FW1178 ..................................10 FW1178 INSTALLATION AND BASIC SETUP ................. 11 3.1..............................11 EFORE NSTALLATION 3.2............................11 ACTORY EFAULT ETTINGS 3.3. FW1178 ..............................11...

  • Page 4: Product Overview

    IP(Internet Protocol) network. There is one type of FW1178 model: DP. It can transmit up to 30fps@D1 over the existing network. You can monitor video of FW1178 through web browser(ie. MS Internet Explorer), if FW1178 is connected to network. FW1178 supports video compression both Motion-JPEG and H.264 simultaneously so that user can choose appropriate video compression for the...

  • Page 5: Key Features

    FW1178 User’s Manual 1.2. Key Features Standalone device built-in web server 10M/100M Auto Sensing Ethernet Configuring and controlling through Web browser Max 30 fps transmission speed on TCP/IP network Effective Bandwidth & Bit-rate Control (VBR/CBR) by H.264 Supports Dual Stream (Motion JPEG & H.264)

  • Page 6: Technical Specification

    FW1178 User’s Manual 1.3. Technical Specification FW1178-PE 32bit Embedded CPU NAND Flash 128Mbytes / DDR2: 128Mbytes Hardware Linux version 2.6.xx operating system Battery backed up real-time clock 1/4”Sony 410K Super HAD CCD Resolution: 520 TV Lines [Detail] S/N ratio: 50dB or more (AGC OFF)
  • Page 7 Live-cast for up to 16 clients Installation, management Installation CD and web-based configuration and maintenance Firmware upgrades over HTTP or FTP , firmware available at www.flexwatch.com Video access from Web Video access from Web browser browser Pentium 4, 2 GHz, 2GB(RAM) or higher...
  • Page 8 FW1178 User’s Manual Powerful API for software integration available at http://www.flexwatch.com, including Simple Viewer API, FlexWATCH Control SDK, event trigger data in video stream, System integration support embedded scripting and access to serial port peripherals over HTTP/TCP User can be installed user program daemon for event notification or sending image Embedded operating system: Linux 2.6...

  • Page 9: Fw1178 Packing List

    Power Supply Unit (24V AC Power Cord) CD (User’s Manual, installation wizard and etc) Table 2 : FW1178 Packing List Note: Please check all the listed items are included in your package. For any missing items, please contact your local distributor.

  • Page 10: Hardware Description

    FW1178 User’s Manual 2. Hardware Description 2.1. FW1178 Picture 2 : FW1178 Name Description PTZ Camera Camera supporting PTZ (Pan/Tilt/Zoom) BODY Frame Body Frame for Camera Table 3 : FW1178 M4049-02 Seyeon Tech Co., Ltd...

  • Page 11: Fw1178 Installation And Basic Setup

    Following steps are the physical installation process for FW1178. Fix the FW1178 in place Connect the FW1178 to the Internet cable through the LAN port. Connect the power supply of FW1178. After that, you need to follow the steps below.
