- Page 1 INSTALLATION AND USER MANUAL INSTALLERS Please read these instructions carefully before undertaking the installation of a Siddons Solarstream Heat Pump Water Heater Models Domestic: 264SSBD, 327SSAD Commercial: 327SSAC3, AC4, AC5, AC6 www.siddonssolarstream.com Version 2.2 04/10...
-
Page 2: Heat Pump Specifications
This needs to drain away with out causing any damage to the surrounding building or CYLINDER SPECIFICATIONS: material. 327SSAD 264SSBD The location of the tank and Heat Pump is Capacity 327 Litres 264 Litres flexible. Good design considerations should... -
Page 3: Section 1: Plumbing Installation
SECTION 1: PLUMBING INSTALLATION A licensed plumber should install the Solarstream. It is the installers responsibility to comply with all AS/NZ Standards, Building Codes and Trade Codes of Practice for compliant installations of domestic hot water heaters. In Australia, your plumber should also hold a Restricted Split System Air Conditioning Installation and Decommissioning License (Certificate II course under the Australian Refrigeration Council’s code RSS03) covering air conditioning and heat pump split systems. -
Page 4: Section 2: Heat Pump Installation
SECTION 2: HEAT PUMP INSTALLATION Clear space clearance around outdoor unit. • Locate the heat pump away from combustible material Installation limitations • Inlet - 200mm clear air height and distance • Outlet - 1000mm clear air hot water outlet Heat Pump Unit can be installed on first floor roof. -
Page 5: Section 3: Heat Pump To Tank Connections
SECTION 3: HEAT PUMP TO TANK CONNECTIONS CONNECTING THE REFRIGERANT LINES TO THE WATER TANK Step 1. Carefully unwind the copper refrigeration pipes on the heat pump, take care to avoid kinking the pipes. The pipes are quite hard copper and will kink if care is not taken to carefully mould or form the curve required. If a tight bend to the right is required in the refrigeration lines, cut back the insulation and use a soft copper tube bender to form the bend. -
Page 6: Section 4: Electrical Installation
SECTION 4: ELECTRICAL INSTALLATION CONNECTING THE ELECTRICAL SYSTEMS The Solarstream is designed for single phase 230~240 V A.C. 50 Hz supply, max load 1400 watt. Australian Standard AS/ NZ 3000 or AS/NZ 3006 Wiring Code and local supply authority regulations apply. The Heat Pump should be plugged into standard day rate power points, or alternatively arrangements may be made with an electrician to have the power lead directly wired into an off-peak supply at the main circuit board. -
Page 7: Section 5: Trouble Shooting
SECTION 5: TROUBLE SHOOTING INSTALLERS AND SYSTEM CHECKS Commissioning Heat Pump unit is securely fastened to prevent tipping over. Water Tank is totally secure and cannot tip over. Water Tank is plumbed correctly, bled of air and full of water. ... -
Page 8: Section 6: Warranty Information
cost of travelling may be charged to the owner. Siddons Solarstream Pty Ltd is excluded to the extent allowable by law from responsibility for any consequential loss including: injury to persons, injury to property, economic loss, pain and suffering or legal or other damages flowing from any manufacturing fault/defect.
