PIX 250i User Guide and Technical Information
Digital Audio Input/Output (DB-25)
6)
8 channels of AES digital audio input
and 8 channels of AES digital output.
"Connector Pin Assignments", page
Analog Audio Outputs (XLR)
7)
2 channels of balanced, line-level analog
audio outputs.
Analog Audio Inputs (XLR)
8)
2 channels of balanced, line-level analog
audio inputs.
Ethernet (RJ-45)
9)
Attaches to 1G or 100M Ethernet net-
works. Provides Network Grouping
"Network Grouping", page
cess for remote control
- PIXNET", page
service.
ment", page
RS-422 Control (DB-9)
10)
Connects to RS-422 Controllers for exter-
nal control of the PIX 250i.
page 42)
4
v. 2.00 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
69)
40), web ac-
(See "Web Interface
42), and network file
(See "Storage and File Manage-
51)
(See "RS-422",
GPIO Remote (Phoenix 10-pin)
11)
Logic contact points for remote control.
(See (See "GPIO (General Purpose Input / Out-
put)", page
SDI Video Input (BNC)
12)
SDI video input. Accepts 3G-SDI, HD-
SDI, or SD-SDI signal with up to 16 chan-
nels of embedded audio.
SDI Video Output (BNC)
13)
SDI video output. Provides 3G-SDI, HD-
SDI, or SD-SDI signal with up to 16 chan-
nels of embedded audio.
HDMI Video Input (HDMI)
(See 14)
Accepts HDMI (1.4a) signal with 8
channels of embedded audio. The PIX
250i does not record or display content
encoded with HDCP.
HDMI Video Output (HDMI)
15)
Provides HDMI (1.3) signal with 8 chan-
nels of embedded audio.
USB Connection
16)
Factory use only.
49)
