TracVision LF Installation Manual

TracVision
These instructions explain how to install the TracVision LF/SF
satellite TV antenna system on a vehicle. Complete instructions
on how to use the system are provided in the User's Guide and
the selected receiver's owner's manual.
Step
1. Inspect Parts and Get Tools
2. Plan the Installation
3. Remove the Shipping Restraint
4. Mount the Antenna
5. Cut the Switchplate Mounting Hole
6. Wire the Antenna
7. Seal the Cable Access Hole
8. Wire the Receiver(s)
9. Wire the Switchplate
10. Mount the Switchplate
11. Test the System

Technical Support

If you need technical assistance,
please contact KVH Technical Support:
Phone: 1-401-847-3327
E-mail: techs@kvh.com
Internet: www.kvh.com/help
54-0286 Rev. A
LF/SF Installation Guide
®
See Page:
2
3
4
5
6
7
8
9
10
11
12
TracVision Antenna
Data/Power
RF2 RF1
(optional)
Satellite Receiver 2
TV 2
Vehicle
Power
12 VDC
Switchplate
Low-speed Data
®
(DIRECTV only)
Satellite Receiver 1
TV 1
1
