- Page 1 CH-107 TX & RX HDMI v1.3 over ONE CAT6 HDMI Transmitter & Receiver Operation Manual CH-107 TX & RX...
- Page 2 Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document. Cypress also makes no commitment to update or to keep current the information contained in this document.
-
Page 3: Safety Precautions
Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 4: Table Of Contents
Table of Contents Introduction ……………………..……………………...…..….……. Applications …………………..………………….……....….. Package Contents ………………………...………....… System Requirements ……………..………..………....……. Features …………………………………………..……..…...…… Specifications ………………………………...……..………..…. Operation Controls and Functions ……………...……....…… Front Panel ................Rear Panel .…………………………………..……..…...….… Connection and Installation ….…………………..…..…..…..Acronyms ….................. -
Page 5: Introduction
1. Introduction The HDMI 1.3 transmitter and receiver over ONE CAT 6 is a tool for displaying HDMI content at long distances. Instead of using expensive HDMI cables, your existing CAT 6 cables/sockets can perform functions like transferring Deep Color (12 bits/color) video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) Digital audio, with a bandwidth up to 2.25Gbps. -
Page 6: Features
5. Features Compliant with HDMI 1.3, HDCP 1.1 and DVI1.1 standards. Supports digital video formats in Deep Color Mode at up to 36 bits (12bits/ color) and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) Digital audio . Supports one CAT-6 cable for data/DDC transmission. -
Page 7: Specifications
6. Specifications Frequency Bandwidth 2.25Gbps (single link) Transmitter Input/Output Ports 1 x HDMI Female port/1 x CAT6 Receiver Output/Input Ports 1 x HDMI Female port/1 x CAT6 Power Supply 5V/ 1A DC (US/EU standards, CE/FCC/UL certified) ESD Protection Human Body Model: ± 8kV (air-gap discharge) ±... -
Page 8: Rear Panel
③ HDMI OUTPUT: This slot is where you connect the HDMI or DVI input port of your display such as an HDTV/HD monitor or connect it to another transmitter from the same family in order to extend your transmission over long distances. -
Page 9: Acronyms
Acronyms Acronym Complete Term CAT6 Category 6 Cable HDMI High-Definition Multimedia Interface... - Page 12 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20100325 MPM-CH107TX&RX...
