- Page 1 User’s Manual ATS 4121CCL 2.4GHz Digital Spread Spectrum Cordless Telephone To fully enjoy all the benefits of this product, we ask that you review the information contained in this manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Instructions ...3 Safety Instructions for Handset Battery Pack...4 Handset and Base Layouts...5 Handset and Charger ...7 LCD Display...7 Getting Started ...8 Basic Operation...9 Answering Calls ...9 Making Calls ...11 Call Waiting / Call Waiting ID...12 Redial ...12 Muting the Handset Microphone ...12 Headset Operation...123... -
Page 3: Important Safety Instructions
Important Safety Instructions BEFORE USING YOUR TELEPHONE EQUIPMENT, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND INJURY TO PERSON, INCLUDING THE FOLLOWING Read and understand all instructions. Follow all warnings and instructions marked on the product. Unplug this product from the wall outlet before cleaning. -
Page 4: Safety Instructions For Handset Battery Pack
controls may result in damage and will often require extensive work by a qualified technician to restore the product to normal operation. If the product has been dropped or cabinet has be damaged. If the product exhibits a distinct change in performance. 13. -
Page 5: Handset And Base Layouts
Handset and Base Layouts Dialing Keys (0-9; *; #) Talk / End Clear/Delete Flash/Speakerphone LDS (Long Distance Service) Program Volume ▲ / Scroll ▲ Display (LCD) Message Waiting Indicator (LED) Cancel Volume ▼/ Scroll ▼ Intercom Redial/Pause Repeat Dial (Pay-Per-Use) 411 Directory Info. - Page 6 Message Waiting/In Use Indicator Charge Indicator Page...
-
Page 7: Handset And Charger
Handset and Charger LCD Display 1. Caller ID Time 2. Caller ID Date 3. Ringer OFF icon (displayed when user turns the ringer off) 4. Low battery icon (on only if battery voltage is low) 5. Key lock icon (displayed when user locks the keypad) 6. -
Page 8: Getting Started
Getting Started Install and Charge the Battery Pack Open the battery compartment by sliding the cover down. Plug the Battery Pack connector into the Handset socket, then place the battery pack and wires in the compartment. Slide the battery cover back into place. (Optional) Attach the belt clip and change color face plate, if desired. -
Page 9: Basic Operation
Plug the adaptor in socket-outlet which is near equipment and easily accessible. Place the Handset in the Base cradle. The Handset and Base communicate with each other automatically. This is the Registration process, and it may take up to 60 seconds. Allow the Handset to charge for a day for the first time charging. - Page 10 Phone Book. If the CID package sent by the service provider contains name information, this name will be shown. However, if the calling number matches a number you have programmed in the Phone Book, the name associated with this number is shown instead; i.e. the Phone Book name takes precedence. Time/date information is shown, if it is contained within the information package sent out by the service provider.
-
Page 11: Making Calls
Calls with blocked name in Caller ID is shown as: TALK 1:32:56 PRIVATE NAME TALK 1:32:56 UNKNOWN NAME The number ‘1:32:56’ represents the elapsed time of your call, in hours, minutes and seconds. Key entries during a call will replace the number/name in the second line, and the digits are left-truncated in case the entered number exceeds 16 digits. -
Page 12: Call Waiting / Call Waiting Id
Unit automatically goes on-hook (terminates the call), and the Handset will emit an out of range tone as well as display ‘OUT OF SERVICE’. Call Waiting / Call Waiting ID Call Waiting When you receive a Call Waiting alert tone in the earpiece (or Handset Speakerphone), the ‘waiting’ call can be answered by pressing the FLASH key. -
Page 13: Headset Operation
by pressing CLEAR/DEL again. The Mute function is automatically cancelled when you hang up (go on hook). Periodic beeps in the earpiece and a text message in the display indicate that the microphone is muted: TALK 1:35:06 MIC MUTE Headset Operation Your ATS cordless Handset is equipped with a 2.5 mm. -
Page 14: Lds (Long Distance Service)
LDS(Long Distance Service) Key LDS access from the Handset To dial the LDS access number: 1) Press the LDS access key. 2) The phone automatically goes off-hook and you are connected to the Long Distance platform. Handset Menu and Programming 1. - Page 15 The number of entries stored in the call log is indicated when the Handset is in idle mode: READY 1 CALL The number of unanswered calls (NEW), if any, is indicated: READY 2 CALLS/1 NEW The new call indication is removed when the call log has been reviewed. The call log is entered via the menu, as described below or by pressing ▼...
-
Page 16: Phone Book
Two info messages are displayed together with the Caller ID data: ●‘NEW’ icon on the right hand side of the top line indicates that the call has not previously been reviewed. The ‘NEW’ icon is cleared when scrolling to the next entry or when leaving the Call Log. The maximum length of the name shown in the second line is 16 characters. - Page 17 Table 1.2 Character guide. Phone Book Operation The Phone Book is entered via the menu, as described below. The Phone book is accessed as follows: 1) PROG, to enter the menu. >CALL LOG PHONE BOOK 2) DOWN (▼) >PHONE BOOK HANDSET VOLUME 3) PROG, to enter the Phone Book sub-menu.
- Page 18 1) Press PROG to enter the menu; press ▼ to put PHONE BOOK on the top line of the display; press PROG again; with "RECALL" in the first line, press PROG again. ALICE 2278238989 2) Scroll through the Phone book entries using ▼ or ▲; OR enter the first character of the desired name and continue searching using the UP/DOWN keys.
-
Page 19: Volume
RECALL Press CANCEL twice to return to the idle screen. If the Phone Book is full when the user tries to store a new number in it, a message ‘PHONEBOOK FULL’ is displayed, and the phone returns to the Phone Book menu (Store/Recall) after 5 seconds. PHONEBOOK FULL Volume Handset volume is adjusted by the following key sequence:... -
Page 20: Auto Answer
PHONE BOOK 2) Press the ▼ key four times. >RING PATTERN AUTO ANSWER 3) Press PROG to enter the ring pattern sub-menu. >EXTERNAL INTERNAL 4) Press the PROG key to choose external ring pattern setting. EXT RING PATTERN 5) Enter 0 to 9 , or adjust using ▼/▲ keys. The selected ring pattern is played for you. EXT RING PATTERN 6) Press PROG to confirm the setting. -
Page 21: Key Lock
Key Lock It is possible to lock the Handset keypad. The key lock function is set/reset by: 1) Press PROG. >CALL LOG PHONE BOOK 2) Press the ▼ key seven times. >KEY LOCK HANDSET NAME 3) Press PROG to enter the key lock sub-menu. KEY LOCK 4) Enable key lock by pressing 1 or ▲, or disable key lock by pressing 0 or DOWN. -
Page 22: Language
4) Enter Handset name (characters are entered in the same way as for the Phone Book). NAME DAD'S PHONE 5) Press PROG to confirm the setting and to return to idle mode. DAD'S PHONE Language The language used in the Handset display can be selected by following this sequence: 1) Press PROG. -
Page 23: Handset Status Indication
Phone line is idleLED is off Flashing Red Line is ringing 1/2 second Green; 1/2 second Off Handset in use LED is steady Green Extension in use LED is steady Green Handset Status Indication Handset Status Indication – Display Icons and Antenna indicator (LED) Service Indication (Antenna icon) This icon is displayed when the Handset is within range of the Base. -
Page 24: Led Indication - Handset Antenna
If the phone line is disconnected, a "no line" warning is shown on line two: READY NO LINE When the keypad is locked, the status is displayed on line two: READY KEY LOCKED If the phone line is in use (by another telephone connected the same line), the “ext in use” message is presented on line two: READY EXT IN USE... -
Page 25: Registering Your Handset
●The Handset beeps when the registration procedure is successfully completed. ●The Handset emits one double-beep in the event of unsuccessful registration. Registering Your Handsets Your Handset will be registered to the Base Unit as you charge it initially. Registration will be indicated by READY displayed on the screen. -
Page 26: Consumer Information
Consumer Information This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the back of this equipment is a label that contains, among other information, a product identifier in the format US:DDKW400BWWI244X. If requested, this number must be provided to the telephone company. - Page 27 2) According to telephone company reports, AC electrical surges, typically resulting from lightning strikes, are very destructive to telephone equipment connected to AC power sources. To minimize damage from these types of surges, a surge arrestor is recommended. Should you experience trouble with this equipment, please contact ATS Customer Support for service information.
-
Page 28: Limited Warranty
Limited Warranty WHAT DOES OUR WARRANTY COVER? Any defect in material and workmanship. FOR HOW LONG AFTER THE ORIGINAL PURCHASE? To the original purchaser only – ONE YEAR. WHAT WILL ATS DO? At our option, repair or replace your unit. HOW DO I ARRANGE FOR SERVICE, WHETHER IN OR OUT OF WARRANTY? Call Customer Support for Return Authorization at 1-800-845-4774.
