Cirago CTM1000 User Manual

Usb media player
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
U s e r s M a n u a l

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CTM1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Cirago CTM1000

Summary of Contents for Cirago CTM1000

  • Page 1 U s e r s M a n u a l...

  • Page 2: Table Of Contents

    Table of Contents 1. Introduction .......................... 3 1.1 Preface ......................... 3 1.2 What’s In the Box ......................3 1.3 Usage Cautions......................3 1.4 Connection ........................4 1.5 First Time Usage ......................6 2. About the CiragoTV Mini ..................... 7 2.1 Remote Control ......................7 2.2 Front Panel ........................

  • Page 3: Introduction

    Direct playback files from external USB storage devices. Card Reader Supports memory cards: SD/MMC/MS. We are certain this product will enhance your multimedia needs. Thank you again for choosing the CiragoTV Mini and visit www.cirago.com for more multimedia products. 1.2 What’s In the Box Part Quantity...

  • Page 4: Connection

    (2) This player could accept some interference received including interference that may cause undesired operation. 1.3.3 Repair If you encounter any problems with the media player, contact Cirago Customer Service at 408-331-8822 or email support@cirago.com. Repairing the product yourself will lead to voiding the product warranty.
  • Page 5 1.4.2 Memory card A memory card can be used by inserting it into the card slot. (1) Make sure the player is powered on (2) Insert your memory card (SD/MMC/MS) to the memory card slot 1.4.3 TV connection 1.4.3.1 A/V OUT (1) Follow the picture and plug in the connector to the player’s A/V OUT jack;...

  • Page 6: First Time Usage

    Connecting the CiragoTV Mini to your TV with an HDMI cable will provide you with the highest quality video and audio output. 1.4.4 Power connection (1) Follow the picture and connect the AC adaptor to the player’s DC IN jack; (2) Follow the picture and plug in the AC adaptor to the power outlet.

  • Page 7: About The Ciragotv Mini

    2. About the CiragoTV Mini 2.1 Remote Control All functions listed in this user manual can be carried out using the remote control. See the following for details on each button and its function: 1. POWER 9. MUTE 2. HOME 10.

  • Page 8: Front Panel

    Press to enable the buttons in tool bar while in file list mode. DOWN Press to move down when navigating menus; Press to disable the buttons in tool bar while in file list mode. VOL + Press to increase the volume. STOP Press to stop playback.

  • Page 9: Setup Menu

    3. Setup Menu The Setup Menu allows you to configure video, audio, photo and system settings. Select the Setup icon in the main interface to enter this Menu. 3.1 General Setup This section allows you to setup your language preference and other system settings. Select and change the system language.

  • Page 10: Video Setup

    3.2 Video Setup This section allows you to configure the video settings. Set the TV system. TV Type Resolution Set the video output mode: 480i/576i, 480p/576p, 720p, 1080i. Turn subtitle on/off. Divx Subtitle Subtitle Color Select the color of subtitles. Subtitle Backgroud Select the color of the subtitle background.

  • Page 11: Photo Setup

    3.4 Photo Setup This section allows you to configure the photo settings. Select the interval time of photo slide show: 1, 3, 5, or 10 seconds Interval Time Transition Mode Select the transition effect of photo slide show. Back to the main setup menu. Main Page 3.5 Firmware Version This section displays the firmware version.

  • Page 12: Media Playback

    4. Media Playback 4.1 Main Interface Use the navigation buttons on your remote control to select between Photos, Music, Movies, Files and the Setup menu. 4.2 Photos Select the Photo icon on the main interface to enter this menu, and all of the supported pictures stored on the device will be displayed.

  • Page 13: Music

    You can access the following functions during playback:  TOOLS: Press to activate/hide the tool bar during playback.  PREV/NEXT: Press to go to previous/next file.  STOP: Press to stop the playback. Slide Show When browsing through photos press the SLIDESHOW button in the tool bar to activate the photo slide show feature with background music.

  • Page 14: Movies

    4.4 Movies Select the Movies icon from the main interface to enter this menu. All of the supported video files stored on the device will be displayed. In video list, press the LEFT button to enable the buttons in the tool bar. Press the UP / DOWN button to select a video file you wish to play, and press the PLAY / PAUSE button to Play.

  • Page 15: Files

     TOOL: Press to activate/hide the tool bar during playback.  PREV/NEXT: Press to go to previous/next chapter.  STOP: Press to stop the playback. With the buttons in the tool bar, you can switch the audio languages, subtitle, etc. Note: The VIDEO_TS and AUDIO_TS directories need to be copied together to one same folder on the connected external hard drive.

  • Page 16: Upgrading The Firmware

    Press the UP / DOWN button to select a file you wish to browse, and press the PLAY / PAUSE button to begin the playback. 5. Upgrading the Firmware Download the latest firmware from www.cirago.com. Please follow the steps below to upgrade the firmware. 1. Copy the firmware upgrade file to a memory card or an external USB device.

  • Page 17: Specifications

    6. Specifications Format: AVI, VOB, MPG, DAT Codec: MPEG-1, MPEG-2, MPEG-4 ASP Video Resolution: Up to 720x576 (PAL), 720x480 (NTSC) Subtitle: SRT, SSA, SMI, SUB Format: MP3, WMA (DRM, Pro and Advanced Profile not supported) Audio Codec: MP2, MP3, PCM, LPCM Compression rate: MP3: 32 Kbps~320 Kbps;...
  • Page 18 Question 4. Some of my photos on my USB drive do not appear. They are JPEG files, so they should show up. What can I do to view them through the CiragoTV Mini? Answer: There are several different types of JPEG files. The player doesn’t support all the modes. Changing the format as explained below should fix this problem.

  • Page 19: Copyrights And Trademarks

    All rights reserved. No part of this manual may be reproduced, or transmitted in any form or by any means, whether by electronically or mechanically, without the express written permission from Cirago International. Copyrighted materials, such as software, music files, or movies, are protected by local law, and may not be illegally copied or used without permission from the copyright owner.
  • Page 20 20 / 20...
