- Page 1 Autostereoscopic 3D Display "C" Product Line "Cn" Model Operating Manual...
- Page 2 Before you switch on the display for the first time, please make sure to carefully read this operating manual. SeeReal Technologies uses standard branded panels as the basis for the production of this autostereoscopic display. For basic information on the panel and safety regulations, please refer to the manufacturer's manual attached on TECHNICAL DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE.
-
Page 3: Table Of Contents
SeeReal Technologies Cn Display Operating Manual Table of contents Table of contents Applications and function ..............4 First-time operation................5 Installation ................... 5 Connection .................. 5 Switching on ................5 Hard- and software ..............6 Display controls .................. 8 Cleaning ....................9 Transport.................... -
Page 4: Applications And Function
1. Applications and function 1 Applications and function Using the "Cn" display, images and videos with stereoscopic content can be displayed and viewed without any additional image separating equipment (e.g. glasses etc.). This way, the user receives an image of a scene that is truly three- dimensional and extremely close to reality. -
Page 5: First-Time Operation
SeeReal Technologies Cn Display Operating Manual operation 2. First-time 2 First-time operation 2.1 Installation Make sure to place the display in a fixed position, dry and well-ventilated. Protect from moisture, undue heat or cold and areas containing excess dirt. 2.2 Connection 1. -
Page 6: Hard- And Software
3D monitor, please refer to http://www.seereal.com. Common professional OpenGL-applications which support the stereo mode e.g. for shutter glasses, can be displayed stereoscopically on the "Cn" display by means of NVidia-graphics boards (with Quadrochips). To this end, go to “Advanced Display settings”... - Page 7 SeeReal Technologies Cn Display Operating Manual operation 2. First-time The "Cn" display is fully digitally controlled, meaning that only graphics boards with digital DVI connection can be used. case questions specific software problems, please contact support@seereal.com. For a current list of standard applications that can run on the display, please refer to www.seereal.com.
-
Page 8: Display Controls
SeeReal Technologies Cn Display Operating Manual controls 3. Display 3 Display controls For detailed information on the panel, please refer to the exact documentation of the manufacturer. Here, you will find the most important information on the main functions of the different buttons for comfortable everyday work. -
Page 9: Cleaning
SeeReal Technologies Cn Display Operating Manual 4. Cleaning 4 Cleaning Warning! Always disconnect power supply before carrying out any cleaning work! Never use any hard or sharp objects that might scratch the protective screen or the housing when cleaning. Do not use any aggressive cleaning agents such as solvent, benzine, scrubbing detergents, spray-on cleaners, acid or alkaline solutions, or wax. -
Page 10: Transport
5 Transport The display may only be transported in vertical position and in an adequate, solid transportation box. SeeReal Technologies does not take responsibility for any damages to the display during transport that result from inadequate packaging or improper handling of the product by a third party. -
Page 11: Scope Of Delivery
SeeReal Technologies Cn Display Operating Manual 6. Scope of delivery 6 Scope of delivery The following accessories will come enclosed with your "Cn" display: Manual and installation CD of the panel manufacturer "Cn" display operating manual on CD-ROM 3D demo CD-ROM... -
Page 12: Technical Data
SeeReal Technologies Cn Display Operating Manual 7. Technical data 7 Technical data General data Distance 650 mm Sweetspot - width 50 mm - depth 150 mm Number of viewers Size 20.1" Stereo resolution 800 x 1200 Stereo contrast 0.8 BM Luminance 180 cd/m²... - Page 13 SeeReal Technologies Cn Display Operating Manual 7. Technical data System requirements IBM-compatible PC, Pentium II 300 MHz Operating systems Windows 9x/ME/NT4/2000/XP, LINUX Graphics board Digital 3D graphics board (e.g. nVidia Quadro) SGI workstation Fuel or Octon2 with V10 or V12 graphics...
-
Page 14: Safety
SeeReal Technologies Cn Display Operating Manual 8. Safety 8 Safety Please note the following safety instructions when working with the display: • The power supply will heat up and this heat has to be dissipated to the surroundings without any obstruction. Therefore, make sure that the power supply is not covered and not exposed to any heat sources. -
Page 15: Address
SeeReal Technologies Cn Display Operating Manual 9. Address 9 Address SeeReal Technologies GmbH Blasewitzer Str. 43 01307 Dresden / Germany Phone: +49 (0) 351 450 3240 Fax: +49 (0) 351 450 3250 Web: www.seereal.com eMail: info@seereal.com Support: support@seereal.com - 15 -...
