- Page 1 Goldenote® AP 7 ITALIAN 30 WATT INTEGRATED AMPLIFIER Owner’s Manual MANUFACTURED IN ITALY TEL.+39.0571.675005 FAX.+39.0571.675013...
-
Page 2: Table Of Contents
Italian 30 Watt Integrated Amplifier Table Of Contents Congratulations & Introduction Contents of Packaging Back Panel Features Operating Conditions & Front Panel AP 7 Main Functions – Upgrade with PSU 7 Technical Specifications Warranty, Customer Service, Warnings & F.A.Q. Troubleshooting F.A.Q. VERY IMPORTANT: Please read the following instructions carefully before installing your Goldenote®... -
Page 3: Congratulations & Introduction
AP-7 Italian 30 Watt Integrated Amplifier Congratulations Thank you for having purchased a Goldenote® product. Introduction The Goldenote AP7 is a 30 Watt integrated amplifier featuring a high class preamplifier stage having a high end audio active volume control stage. -
Page 4: Contents Of Packaging
Carefully remove the AP-7 30 Watt Integrated Amplifier chassis from the shipping box and foam. Connect the audio cable (not supplied) and the AC Power Chord supplied. AP 7 back panel (1) 3 pairs of RCA Analogue LINE INPUT L1, L2, L3- Unbalanced (2) 1 pair XLR Analogue LINE INPUT L4 –... -
Page 5: Operating Conditions
In any case, take care to unplug completely the unit every time you need to move it, or to move the turntable on which it is installed. AP 7 Front Panel (9) ON/OFF - Master switch, it turns the unit ON/OFF completely. - Page 6 Italian 30 Watt Integrated Amplifier (AP7 Preamplifier with Double Mono Active Volume Control) The Double Mono Active Volume Control system of this unit is made with a Goldenote proprietary designed developed with a Texas Instruments PGA2310 devices feature fine resistors step-by-step DOUBLE MONO high end performance for superior resolution, lowest distortion and perfect channel balance.
-
Page 7: Remote Control
AP-7 Italian 30 Watt Integrated Amplifier (REMOTE CONTROL) The supplied remote control is the same of the Goldenote® Digital Player to integrate with one handset eventually the control of all the Blacknote unit. - VOLUME CONTROL – Up & Down Volume control P1 –... -
Page 8: Technical Specifications
MAINS SUPPLY destination not convertible) POWER ABSORBATION Min. <1watt – Max.100watt DYNAMIC POWER >100W IHF UPGRADES SPECIAL Goldenote Lucca Power Chord PHYSICAL DIMENSIONS 200mm L x 80mm H x 260mm D WEIGHT 5Kilos (11Lbs.) FINISHES FRONT PANEL Brushed Black or Silver anodised aluminium... -
Page 9: Warranty Registration
AP-7 Italian 30 Watt Integrated Amplifier (Warranty Registration) To validate the warranty is necessary to register the unit on the Goldenote internet web site within 15 days from the purchase: http://www.goldenote.com/index.pAP?option=com_content&view=article&id=14&Itemid=31&lang=en If the unit is not registered correctly or is been purchased from a different country of the purchaser origin/home the unit will not be covered by any warranty and the eventual registration refused. -
Page 10: Troubleshooting
AP-7 Italian 30 Watt Integrated Amplifier Troubleshooting SYNPTOM DESCRIPTION CAUSE REMEDY SPEAKER HUMMING speakers • unit correctly • Be sure your area and PROBLEMS when the amplifier coupled with the Ground on personal environment are connected well grounded eventually system isolate the ground Pin of the power chord plug for verification. - Page 11 Note:…………………………………………………………………………………………………………………………………………………… ........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................………................................................................................................................................................................
- Page 12 GOLDENOTE Via della Gora, 6 Montespertoli (Florence) Italy 50025 Tel. + 39 0571 675005 Fax. + 39 0571 675013 www.goldenote.com...
