ELECTRIC BICYCLE OWNER'S MANUAL SUPPLEMENT
For Owners of EG Bali 350 and EG Milan 350 Electric Bicycle
Table of Contents
Descriptions:
Installation Instructions
How to install the bicycle out of the box
Operation Instructions
How to operate the Electric Bicycle
Serial Numbers to your EG Electric Bike
How to detach the rear wheel of the Electric bike
Page
2
2
3
3
5
5
5
5
6
6
6
7
7
7
7
8
8
8
8
1
Advertisement
Table of Contents
Related Manuals for EG Bali 350
Summary of Contents for EG Bali 350
- Page 1 ELECTRIC BICYCLE OWNER’S MANUAL SUPPLEMENT For Owners of EG Bali 350 and EG Milan 350 Electric Bicycle Table of Contents Descriptions: Page Installation Instructions How to install the bicycle out of the box Operation Instructions How to operate the Electric Bicycle...
-
Page 2: Installation Instructions
This portion of owners manual is a supplement to the Bicycle owner’s manual. This section pertains to the features in the electric bicycle and how to care for them. INSTALLATION INSTRUCTIONS Unpack the bicycle from the box and cut all the ties that held the bicycle together during shipping. - Page 3 Install the Quick Release lever onto the front wheel with the lever on the same side as the Disc Brake. Install the front wheel by placing the wheel between the forks. Please make sure that the disk rotor slides in between the disk brake caliper. Loosen the brake caliper cable using the supplied Allen key as necessary.
- Page 4 use among the peddle assist modes. 2b. Peddle Assist Mode (Medium) – To put the bike in “Medium” peddle assist mode, switch on the bike as you would on the above “LOW” mode and then press the green “Mode” button to light up the “MED” mode and peddle the bicycle normally as you would any bicycle.
-
Page 5: Care Instructions
The motor will NOT stop when you stop peddling while the thumb throttle is engaged. The motor will stop if the brake lever is depressed even if the thumb throttle is engaged. ! CAUTION: Remember to let go of the thumb throttle when getting on or off the bike weather or not the brake levers are engaged. - Page 6 Never charge the battery by the discharge terminals or discharge the battery by the charge terminals. Keep the battery away from excessive heat and or open flames. Never pour on or submerge the battery in water. To avoid damage to the battery, never subject the battery to intense physical impact, shock or ...
- Page 7 Charger Storage conditions: Room temperature -20 ～ 35℃, Charger relative humidity: 5～65％RH Charger ！WARNING: Never place any object on the charger. Never pour any liquid on or insert any metal into the charger. Never disassemble or modify the charger in anyway. ...
- Page 8 How to detach the rear wheel of the Electric bike 1. ! WARNING: We do not condone modifying the EG Electric Bicycle in any way shape or form. Modifying the bike in any way, will void your Warranty. The instructions below are written only for the maintenance or repair of the bike.
