Summary of Contents for EG Athens 350DX

  • Page 1 ELECTRIC BICYCLE OWNER’S MANUAL For Owners of EG Athens 350DX Electric Bicycle Table of Contents Descriptions: Page Installation Instructions How to install the bicycle out of the box Operation Instructions How to operate the Electric Bicycle About the Brake Safety Feature on all our Electric Bikes...
  • Page 2 INSTALLATION INSTRUCTIONS How to install the bicycle out of the box 1. Unpack the bicycle from the box and cut all the ties that held the bicycle together during shipping. 2. Install the handle bar by inserting the handlebar stem into the head tube. An Allen key is supplied to install the handle bar stem.
  • Page 3 OPERATION INSTRUCTIONS How to operate the Electric Bicycle The Electric bicycle can be operated in 3 different modes: 1. Manual Mode –  Make sure the Display on the bike is “OFF” and then, pedal the bicycle normally as you would any bicycle.
  • Page 4  To put the bike in Pedal assist and “Throttle on demand” mode, switch “ON” the bike by pressing and holding the “MODE” button on the Pad located to the left of the handlebar and then press “DOWN” button on the pad until “0” appears on the LCD screen. Pedal the bicycle normally as you would any bicycle.
  • Page 5 How to read the Battery Meters and about the Li-on battery There are 2 Battery meters on your bike. 1 is located conveniently on the top of the LCD screen on the handle bar. The 4 red Bar graph indicates the state of the battery discharge. The other Battery meter is located on to the top rear of battery with 4 green and 1 red LEDs showing the current capacity of the battery in various states of discharge.
  • Page 6 If you have any questions about this battery or its usage, please do not hesitate to contact us Storage, Maintenance and transport Battery  If the battery needs to be stored for an extended period of time, it should be kept at around 50% charge capacity (or charge the battery for about 2-3hours from empty) and should be placed in a dry and well ventilated place.
  • Page 7 Electric Motor and Battery Features High efficiency and power saving Electric Motor–  A Brushless Motor with gears  High efficiency of up to 85%.  Efficiency>80%. 36V battery for a continuous run range of more than 40 miles on a single charge in pedal assist mode.
  • Page 8 2. The Bike Frame Serial number to your EG Electric Bike is located on the underside of the bike below the bottom bracket on the frame.
