- Page 1 8-Port 10/100Mbps Fast Ethernet Switch with 4 x 802.3af PoE Ports User’s Guide...
-
Page 3: Fcc Warning
FCC Warning This equipment has been tested and found to comply with the regulations for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 4: Table Of Contents
TABLE OF CONTENT About This Guide................. 1 Purpose .................... 1 Terms/Usage ..................1 Introduction..................3 Fast Ethernet Technology ..............3 Power over Ethernet (PoE) .............. 3 Features.................... 4 Unpacking and Installation ..............7 Unpacking..................7 Installation ..................7 Connecting Network Cable.............. 8 Identifying External Components ............ -
Page 5: About This Guide
This guide discusses how to install your 8-Port 10/100Mbps Fast Ethernet Switch with 4-Port PoE. Terms/Usage In this guide, the term “Switch” (first letter upper case) refers to your 8-Port 10/100Mbps Fast Ethernet Switch with 4-Port PoE and “switch” (first letter lower case) refers to other Ethernet switches. -
Page 7: Introduction
INTRODUCTION This chapter describes the features of the 8-Port 10/100Mbps Fast Ethernet Switch with 4-Port PoE and some background information about Ethernet/Fast Ethernet, Switching and Power over Ethernet technology. Fast Ethernet Technology The growing importance of LANs and the increasing complexity of desktop computing applications are fueling the need for high performance networks. -
Page 8: Features
Features 8 × 10/100Mbps Auto-negotiation Fast Ethernet RJ-45 ports with 4 ports supporting PoE Compliant with 802.3af specification Supports PoE power up to 15.4W for PoE port Supports PoE power up to 30W for all PoE ports Supports PoE Powered Device (PD) classification identity Each port supports auto MDI/MDIX so there is no need to use cross-over cables or an up-link port Full/half duplex transfer mode for each port... -
Page 9: Unpacking And Installation
Switch. Unpacking Open the box containing the Switch and carefully unpack its contents. The carton should contain the following items: One 8-Port 10/100Mbps Fast Ethernet Switch with 4 PoE Ports One AC power adapter Four rubber feet User’s Guide If an item is found to be missing or damaged, please contact your local reseller for a replacement. -
Page 10: Connecting Network Cable
Connecting Network Cable The Switch supports 8 10/100M Ethernet ports with ports 1 through 4 supporting PoE. These PoE ports will automatically activate when a compatible terminal is connected, and the Switch will supply power through the Ethernet port to the connected PoE powered device (PD). For the Legacy devices that are not compatible with PoE, the PoE port will not supply power to the port. -
Page 11: Identifying External Components
IDENTIFYING EXTERNAL COMPONENTS This chapter describes the front panel, rear panel, and LED indicators of the Switch. Front Panel The figure below shows the front panel of the Switch. Figure 1. Front panel Comprehensive LED indicators display the status of the switch and the network (see the Understanding LED Indicators section below). - Page 12 These ports support network speeds of either 10Mbps or 100Mbps, and can operate in half- and full- duplex transfer modes. These ports also support automatic MDI/MDIX crossover detection which provides true “plug and play” capability. Ethernet Ports (Port 5-8): These ports support network speeds of either 10Mbps or 100Mbps, and can operate in half- and full-duplex transfer modes.
-
Page 13: Understanding Led Indicators
UNDERSTANDING LED INDICATORS The front panel LEDs provide instant status feedback, and helps monitor and troubleshoot when needed. Figure 3. LED indicators of the Switch System LED Power: (Power Indicator) The Switch is receiving power. Off: The Switch is not receiving power. PoE status LEDs (Port 1 - Port 4) PoE Status: Green: A PoE powered device (PD) is connected to the port and... -
Page 14: Ethernet Port Status Leds (Ports 1~8)
PoE MAX: On: The system has less than 7.5W of power remaining to power PoE devices. If this LED is on, the system will not provide power to any additional PoE devices connected to the Switch. Off: The system has more than 7.5W of power remaining to power PoE devices. - Page 15 Example: If there are PoE devices connected to the Switch with a total power consumption of 25 watts, the Switch only has 5 watts remaining as a buffer, and the PoE MAX LED will light up. If another POE PD inserted, the system will not provide power to the additional POE PD.
-
Page 17: Technical Specifications
TECHNICAL SPECIFICATIONS General Standards IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3x Full Duplex Flow Control IEEE 802.3af Power over Ethernet Protocol CSMA/CD Data Transfer Rate Ethernet: 10Mbps (half duplex), 20Mbps (full-duplex) Fast Ethernet: 100Mbps (half duplex), 200Mbps (full-duplex) Topology Star Network Cables... - Page 18 Performance RAM Buffer: 96 kilobytes per device Filtering Address Table: 1k entries per device Packet 10Mbps Ethernet: 14,880/pps Filtering/Forwarding Rate: 100Mbps Fast Ethernet: 148,800/pps MAC Address Learning: Automatic update Transmits Method: Store-and-forward...
