Controls and Functions

1
2
1. SENS- Sensitivity control also used as power switch.
Rotate clockwise (away from OFF) to turn on the power. When you
rotate the SENS from 0 to 10, the sensitivity is gradually increased. In
general use, you can set the SENS to a higher position. But in
mineralized area, or area with electrical interference, it's better to
lower the SENS.
2. MODE SWITCH
DISC- The mode DISC/TONE can facilitate in your search and
discriminate the target type based on a long or short tone for
different metal target.
ALL METAL- Search for all kinds of metal objects without
discrimination.
TONE- Works with DISC/TONE. Discriminates metals with two
different tones (high or low).
3. TARGET- To pinpoint the target. Press this button to lower the
sensitivity automatically and to locate the target.
4. LOW BAT- When indicator lights, user has to replace the battery.
5
3 4
7
6
9
