Frigidaire GLGF386DQA Parts Catalog
Frigidaire GLGF386DQA Parts Catalog

Frigidaire GLGF386DQA Parts Catalog

30-inch free-standing gas range

Advertisement

Quick Links

GLGF386D.eps T24G0012.eps T24B0007.eps T24V0026.eps T24T0025.eps
T24D0005.eps
316417808d.eps 316417808s.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
GLGF386DQA GLGF386DSA
Series
30" f/s gas
Color
bisque
Market
North America North America
Wiring Diagram
316417808
Owner's Guide
316417102
Installation Instructions 316259336
Service Data Sheet
316417603
Publication No.
5995420212
04/10/28
(EN/SERVICE/ECL)
369
30" f/s gas
white
316417808
316417102
316259336
316417603
30-INCH FREE-
STANDING GAS
RANGE
Model No.
GLGF386D
©
Copyright
2004 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the GLGF386DQA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Frigidaire GLGF386DQA

  • Page 1 Product No. GLGF386DQA GLGF386DSA Series 30" f/s gas 30" f/s gas Color bisque white Market North America North America Wiring Diagram 316417808 316417808 Owner's Guide 316417102 316417102 Installation Instructions 316259336 316259336 Service Data Sheet 316417603 316417603 30-INCH FREE- GLGF386D.eps T24G0012.eps T24B0007.eps T24V0026.eps T24T0025.eps STANDING GAS T24D0005.eps...
  • Page 2 Publication No: 5995420212 GLGF386D BACKGUARD 10/04...
  • Page 3 GLGF386D Publication No: 5995420212 BACKGUARD Model Index: A GLGF386D (GLGF386DSA) B GLGF386D (GLGF386DQA) POS. NO PART NO. DESCRIPTION 316416100 Shield, backguard, rear wall 316051600 Shield, backguard, inner 316235100 Shield, top, inner 316022500 Light/Lamp, indicator, 125 V 316411403 Support, backguard, white, RH...
  • Page 4 Publication No: 5995420212 GLGF386D BURNER 10/04...
  • Page 5 GLGF386D Publication No: 5995420212 BURNER Model Index: A GLGF386D (GLGF386DSA) B GLGF386D (GLGF386DQA) POS. NO PART NO. DESCRIPTION 316219501 Pipe, manifold 5303935233 Valve, 17K burner, w/mtg screw 2A # 5303935235 Valve, 5K burner, w/mtg screw 2B # 5303935232 Valve, 9.5k/12k burner, w/mtg screw...
  • Page 6 Publication No: 5995420212 GLGF386D BODY 10/04...
  • Page 7 GLGF386D Publication No: 5995420212 BODY Model Index: A GLGF386D (GLGF386DSA) B GLGF386D (GLGF386DQA) POS. NO PART NO. DESCRIPTION 316401601 Back, main 316402201 Shield, oven top 316437100 Brace, oven top 316400102 Panel, bodyside, white, RH 316400103 Panel, bodyside, white, LH 316400106...
  • Page 8 Publication No: 5995420212 GLGF386D BODY 10/04...
  • Page 9 GLGF386D Publication No: 5995420212 BODY Model Index: A GLGF386D (GLGF386DSA) B GLGF386D (GLGF386DQA) POS. NO PART NO. DESCRIPTION 316136400 Blade, fan 316136500 Washer, fan motor 316136600 Nut, fan retainer 316404600 Shield, bodyside 5303935180 Anti-tip Kit, w/bracket, screw 170* 316107200 Bracket, anti-tip...
  • Page 10 Publication No: 5995420212 GLGF386D TOP/DRAWER 10/04...
  • Page 11 GLGF386D Publication No: 5995420212 TOP/DRAWER Model Index: A GLGF386D (GLGF386DSA) B GLGF386D (GLGF386DQA) POS. NO PART NO. DESCRIPTION 316408701 Drawer, utility 316403200 Liner, drawer 316403401 Panel, drawer, white, front 316403403 Panel, drawer, bisque, front 316407400 Glide, drawer, rear 316411217 Maintop, white...
  • Page 12 Publication No: 5995420212 GLGF386D DOOR 10/04...
  • Page 13 GLGF386D Publication No: 5995420212 DOOR Model Index: A GLGF386D (GLGF386DSA) B GLGF386D (GLGF386DQA) POS. NO PART NO. DESCRIPTION 316402001 Trim, oven door, white 316402003 Trim, oven door, bisque 316402600 Glass, door, white 316402602 Glass, door, bisque 316402307 Shield, wool 316403900...
  • Page 14: Wiring Schematic

    Publication No: 5995420212 GLGF386D WIRING SCHEMATIC 10/04...
  • Page 15: Wiring Diagram

    GLGF386D Publication No: 5995420212 WIRING DIAGRAM 10/04 # Functional Parts * Non-Illustrated Parts...
