OWNER'S MANUAL
Model: 002-LESLIE PEDAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the 002-Leslie Pedal and is the answer not in the manual?

Questions and answers

Related Manuals for Leslie 002-Leslie Pedal

Summary of Contents for Leslie 002-Leslie Pedal

  • Page 1 OWNER’S MANUAL Model: 002-LESLIE PEDAL...
  • Page 2 2014 Hammond USA LP0612...

  • Page 3: Safety Information

    Good Vibes you’ll get from playing this pedal are acceptable.) • Pull the plug when not in use - and remove the adapter from the wall socket. Do not transport the Pedal with the AC adapter plug attached. tHe LesLie PeDaL 1...
  • Page 4 LesLie Heritage Congratulations on purchasing the FIRST EVER Digital Leslie Pedal. If this is your first LESLIE, Welcome to our family; if you’re already one of us, welcome home. The Leslie Speaker was invented by Donald H. Leslie in 1940 to make the Hammond Organ sound more like a Theatre Pipe Organ, but even Don Leslie couldn’t begin to imagine...
  • Page 5 Leslie effect appeared, but none had the soul or sound of the genuine article. When the digital age began, the goal drew a little closer, but the true Leslie sound still proved to be elusive. tHe LesLie PeDaL 3...
  • Page 6 The Hammond and Leslie Engineers, some of which were contemporaries of Don Leslie himself, set out to do what has seemed impossible - to make a purely Digital Leslie worthy of that legendary name. In 2012, the Hammond SK1 was released to instant acclaim, and word spread quickly that the Digital Leslie onboard that 15 pound wonder truly and finally “nailed”...
  • Page 7 Mono ¼” cables. When a MONO cable is being used, the Leslie Pedal will convert the Leslie effected signal into a Stereo output. If you use a Stereo “Insert Cable” adapter (Male TRS ¼” plug to dual mono ¼” jacks) you can run any stereo input into the pedal.
  • Page 8 connections STEREO POWER CU-1 RIGHT LEFT/MONO GAIN INPUT 9VDC INPUT OUTPUT OUTPUT LO HI DESIGNED AND MANUF ACTURED IN U.S.A. 6 HammonD Usa...
  • Page 9 LesLie PeDaL 7...
  • Page 10 RISE & FALL: (Ramp Up/Down) Each of the 3 Rotary Cabinet Profiles has its own Rise and Fall speeds that are accurate to the actual Leslie model it is based on. You can increase or decrease these speeds, preserving the individual high/low ratios.
  • Page 11 MODEL 122A The “Classic” Leslie, made famous as paired with a 1950s Hammond B-3. MODEL 147A A slightly brighter sound, often referred to as the “Rock and Roll” Leslie MODEL 18V The Original “Vibratone” Guitar Leslie with one spinning drum MODEL PR-40 The Original Hammond Organ Tone Cabinet.
  • Page 12 NOTE: If you are connected with a MONO cable (like a guitar), the Leslie Effect will be output in Stereo, but in BYPASS mode, only the Left Channel will be output. A 1/4” mono female to stereo male adapter cable is available through Hammond USA, which distributes the signal evenly to both sides of the Stereo input.
  • Page 13 The Deceleration is a fixed value, and the Virtual Rotor’s positions at rest will stop at Center. A convenient feature compared to physical Leslie that will stop arbitrarily. When the BRAKE is engaged both yellow and green LEDs stop flashing.

  • Page 14: Connection Diagrams

    Diagrams Mono Connection Input Outs Keyboard/Instrument/ Other Effects Outs Input Leslie Pedal Bypass Mono-Stereo Connection Inputs Outs Keyboard/Instrument/ Mixer Other Effects Outs Input 1/4” Mono Female to Stereo Male Adapter Leslie Pedal Hammond Part # 003-011-059684 Bypass 12 HammonD Usa...
  • Page 15 Diagrams Stereo Connection Inputs Outs Keyboard/Instrument/ Mixer Other Effects Outs Input Insert Cable Leslie Pedal Male Stereo TRS to 2 Male or Female Mono TS Bypass tHe LesLie PeDaL 13...
  • Page 16 • Stereo operation is preferred to mono. • When using with a Guitar, insert this Leslie Pedal LAST in your chain, following anything that induces Overdrive or Distortion. • If you are using a mono input, and require two channels of output in BYPASS mode, use a mono to stereo splitter on the input jack.

  • Page 17: Specifications

    AC Adapter: 007-AD-LP1 (FY0901000 / ZF120A-1201000) Input: 100-240V, 50/60Hz, 0.25A/0.35A Max, Output: DC9V, 1000mA Center Negative UL and RoHS approved Optional Accessories: CU-1 Half Moon Switch 1/4” Mono Female to Stereo Male Adapter (part # 003-011-059684) tHe LesLie PeDaL 15...

  • Page 18: Warranty

    warranty We guarantee that your pedal will be free of defects in workmanship for a period of one (1) year from the date of purchase. We also guarantee the continued operation of all components for a period of one (1) year from the date of purchase. Within this one year period Hammond will repair or replace at our discretion any pedal that ceases to function properly as a result of faulty workmanship or materials.
  • Page 19 Should the owner require further assistance, inquiries should first be made to your Authorized Hammond and/or Leslie Dealer. If you still need further assistance, contact the Hammond office appropriate for your region.
  • Page 20 Designed and manufactured in the Usa...
