AIR
COMPRESSORS
(Home & Hobby)
SHIPPING DAMAGE CLAIMS
When this equipment is shipped, title passes to the pur-
chaser upon receipt from the carrier. Consequently,
claims for the material damaged in shipment must be
made by the purchaser against the transportation com-
pany at the time the shipment is received.
INSTALLATION AND OPERATION MANUAL
Bend - Pak Inc.
1645 Lemonwood Drive
Santa Paula, CA 93060, U.S.A
Tel: 805 933 9970 - Fax: 805 933 9160
"The Benchmark Of Quality"
Forward this manual to all operators.
Failure to operate this equipment as
directed may cause injury and/or property
BE SAFE
Your new ranger air compressors are designed and built
with safety in mind. However, your overall safety can be
increased by proper training and thoughtful operation on
the part of the operator. DO NOT operate or repair this
equipment without reading this manual and the important
safety instructions shown inside.
damage.
MODELS
R28H
R2513H
R326H
Advertisement
Table of Contents
Related Manuals for Ranger Products R28H
Summary of Contents for Ranger Products R28H
-
Page 1: Air Compressors
Failure to operate this equipment as directed may cause injury and/or property damage. INSTALLATION AND OPERATION MANUAL MODELS COMPRESSORS R28H (Home & Hobby) R2513H R326H SHIPPING DAMAGE CLAIMS BE SAFE When this equipment is shipped, title passes to the pur- Your new ranger air compressors are designed and built chaser upon receipt from the carrier. -
Page 2: Upon Delivery
UPON DELIVERY Carefully remove all packaging material. Inspect the equipment and all parts for any signs of concealed shipment or storage damages. Remember to report any shipping damage to the carrier and make a notion on the delivery receipt. IMPORTANT SAFETY INSTRUCTIONS u·... -
Page 3: Specifications / Features
SPECIFICATIONS / FEATURES HOME / HOBBY Models: R28H / R2513H / R326H-601 Model Motor Max PSI/BAR Max CFM @ Max CFM @ Tank Dimentions Ship 90PSI/LM 115PSI/LM Weight 2hp / 50-60Hz / 115PSI 7.3 CFM 7 CFM 8 Gal W13-3/8"xL23-3/4"xH25-3/4"... -
Page 4: Belt Adjustment
BELT ADJUSTMENT: Install the triangular belt and adjust it so when pres- sure is applied onto center, there should be 1/2” (approx.) slack. See sketch Note: If the belt is installed too tightly, overloading of the motor will occur. This will cause the motor to overheat. -
Page 5: Maintenance
INITIAL START-UP PROCEDURE: Open the air receiver service valve to permit air to escape, preventing air pressure build-up in the air receiver. Plug power supply cord into correct power source. Run the compressor for a minimum of twenty (20) minutes in this no-load position to lubricate the bearings and pistons. -
Page 6: Troubleshooting
TROUBLESHOOTING TROUBLE POSSIBLE CAUSE CORRECTIVE ACTION No start condition Fuse blown or circuit Check for cause of blown fuse or Breaker tripped breaker and replace or reset Loose electrical Check wiring connections Connection Overheated motor Press reset button or wait for automatic reset. - Page 8 R28H Air Compressor Parts List Parts NO. Description Q'ty 42 6011620 In-six Angle Bolt 1 6011640 In-six Angle Bolt 43 60016 Spring Washer 2 60016 Spring Washer 44 6024614 Washer 3 504012C Air Filter 45 403863 Cable Flap 4 50051234C...
- Page 10 R2513H Air Compressor Parts List NO. Parts NO. Description Q'ty NO. Parts NO. Description Q'ty 1 6011640 In-six Angle Bolt 43 60016 Spring Washer 2 60016 Spring Washer 44 6024614 Washer 3 504012C Air Filter 45 403863 Cable Flap 4 50051234C Exhaust Elbow 46 403963 Cable Conduct 5 5101AD15 Cylinder Head...
- Page 12 R326H-601 Air Compressor Parts List No. Parts No. Description Q'ty No. Parts No. Description Q'ty 1 6011650 In-Six Angle Bolt 37 532012 Oil Leveler 2 60016 Spring Washer 38 531814 Oil Drain Plug 3 5101UB20 Cylinder Head 39 5312UB20 Gasket, Bearing Cover 1 4 504012D Air Filter Assy 40 5317UB20 Oil Plug Seal...
- Page 13 R326H601 Air Compressor Parts List No. Parts No. Description Q'ty 73 203314A Nipple 74 30011214B Manifole 75 300214B Air Cock 76 302106510 Unload Elbow 77 302218716 Unload Pipe Nut 78 4E152116 Elec. Motor 79 6031625 In-six Angle Bolt 80 40023519A1Motor Pulley 81 6023820 Motor Bolt 82 6023825...
