AIR
COMPRESSORS
(Professional)
SHIPPING DAMAGE CLAIMS
When this equipment is shipped, title passes to the pur-
chaser upon receipt from the carrier. Consequently,
claims for the material damaged in shipment must be
made by the purchaser against the transportation com-
pany at the time the shipment is received.
INSTALLATION AND OPERATION MANUAL
Bend - Pak Inc.
1645 Lemonwood Drive
Santa Paula, CA 93060, U.S.A
Tel: 805 933 9970 - Fax: 805 933 9160
"The Benchmark Of Quality"
Forward this manual to all operators.
Failure to operate this equipment as
directed may cause injury and/or
BE SAFE
Your new Ranger air compressors are designed and built
with safety in mind. However, your overall safety can be
increased by proper training and thoughtful operation on
the part of the operator. DO NOT operate or repair this
equipment without reading this manual and the important
safety instructions shown inside.
property damage.
MODELS
R7580H-601
R7580H-603
R7580V-601
R7580V-603
Advertisement
Table of Contents
Related Manuals for Ranger Products R7580H-601
Summary of Contents for Ranger Products R7580H-601
-
Page 1: Air Compressors
Forward this manual to all operators. Failure to operate this equipment as directed may cause injury and/or property damage. INSTALLATION AND OPERATION MANUAL MODELS COMPRESSORS R7580H-601 (Professional) R7580H-603 R7580V-601 R7580V-603 SHIPPING DAMAGE CLAIMS BE SAFE When this equipment is shipped, title passes to the pur- Your new Ranger air compressors are designed and built chaser upon receipt from the carrier. -
Page 2: Upon Delivery
UPON DELIVERY Carefully remove all packaging material. Inspect the equipment and all parts for any signs of concealed shipment or storage damages. Remember to report any shipping damage to the carrier and make a notion on the delivery receipt. IMPORTANT SAFETY INSTRUCTIONS u·... -
Page 3: Specifications / Features
SPECIFICATIONS / FEATURES PROFESSIONAL: Models: R7580H-601 / R7580H-603 / R7580V-601 / R7580V-603 Motor Max CFM Max CFM Standard Voltage* Pump Design Speed Tank PSI/BAR @ 90 @ 175 (RPM) PSI/LM PSI/LM 7.5hp 175 PSI 26.5 CFM 25.5 CFM 208-230V / 60 Hz Tri-max™... -
Page 4: Belt Adjustment
BELT ADJUSTMENT: Install the triangular belt and adjust it so when pres- sure is applied onto center, there should be 1/2” (approx.) slack. See sketch Note: If the belt is installed too tightly, overloading of the motor will occur. This will cause the motor to overheat. -
Page 5: Maintenance
INITIAL START-UP PROCEDURE: Open the air receiver service valve to permit air to escape, preventing air pressure build-up in the air receiver. Plug power supply cord into correct power source. Run the compressor for a minimum of twenty (20) minutes in this no-load position to lubricate the bearings and pistons. -
Page 6: Troubleshooting
TROUBLESHOOTING TROUBLE POSSIBLE CAUSE CORRECTIVE ACTION No start condition Fuse blown or circuit Check for cause of blown fuse or Breaker tripped breaker and replace or reset Loose electrical Check wiring connections Connection Overheated motor Press reset button or wait for automatic reset. - Page 8 R7580H-601&R7580H603 Air Compressor Parts List NO. Parts No. Description Q'ty NO. Parts No. Description Q'ty 1 01UT75 Pump Ele.Cable 36 4005553 Bolt 37 4017Y254 Pres. Adjt Connecter 2 60051240 Spring Washer Ele.Cable 3 600112 38 400522 Exhaust assembly Ele.Cable 4 501019870...
- Page 10 R7580V-601 & R7580V-603 Air Compressor Parts List NO. Parts No. Description Q'ty NO. Parts No. Description Q'ty 1 01UV75 Pump Safety Valve 35 30103412 Bolt 36 3004111T Pressure Switch 2 60051040 Spring Washer 37 203314A Nipple 3 600110 4 501019485 Exhaust assembly 38 4017Y254 Pres.
