MA-3600VZ Service Manual

Q43181-9 VZ Switch PWA (D 8174-1 PWB) Parts List

Capacitors
C00 C 2288-6
C16 C 2821-4
C17 C 2821-4
C18 C 3411-3
C19 C 3728-0
C20 C 3411-3
C21 C 6683-4
C22* D 7595-8
C23* D 7595-8
C24* D 7595-8
C25* D 7595-8
Diodes
D17 C 3549-0
D18 C 6578-6
D19* C 8855-6
D20* C 8855-6
Ferrite Bead
FB00 C 9156-0
FB01 C 9156-0
FB02 C 9156-0
Transistors
Q00* C 8516-4
Q01* C 8516-4
Q02* C 8516-4
Q03 D 2961-7
Integrated Circuits
U03 C 7444-0
U04 C 7445-7
U05 C 4345-2
Parts 5-70
.001µF
10pF
10pF
200pF
10µF
200pF
4700pF
6900µF
6900µF
6900µF
6900µF
1N961B 10V
1N4735 6.2V
BYV72-150
BYV72-150
30 Ohm, 10MHz
30 Ohm, 10MHz
30 Ohm, 10MHz
IRF641
IRF641
IRF641
2N3859A, SEL
LM393
LM555
LM339
Resistors
R00 C 2872-7
R01 C 7852-4
R02 A10265-90921 90.9K 1%
R03 C 5707-2
R04 A10265-27421 27.4K 1%
R06 C 5707-2
R07 A10265-90921 90.9K 1%
R08 C 5707-2
R09 A10265-27421 27.4K 1%
R11 C 5707-2
R12 C 6317-9
R13 C 6317-9
R14 A10265-10011 1K 1%
R15 A10265-10011 1K 1%
R16 C 4225-6
R17 C 3620-9
R18 C 2631-7
R19 C 3939-3
R20 C 2632-5
R21 A10266-1221
R22 C 4167-0
R23 C 3622-5
R24 C 6090-2
R25 C 3804-9
R26 A10266-3951
R27 A10266-6811
R28 C 5707-2
Misc.
P00 C 9527-0
P01 C 7592-6
C 3451-9
D 8174-1
* These components do not come with the Q43181-9
PWA.
130366-1 Rev. A
100
2.4K 5W
100K 1%
100K 1%
100K 1%
100K 1%
953 1%
953 1%
470K
68K
10K
4.7K
15K
1.2K
43K
200K
62K
2K
3.9M
680
100K
6 Pin Header
4 Pin Header
8 Pin IC Socket
Board
©2000 Crown International, Inc.
