  • Page 1 WTS32 Wireless Thermostat and Receiver Installation / Operation Manual 950-0160revB February 2, 2012...

  • Page 2: Table Of Contents

    ______________________________________________________ WTS32 Wireless Thermostat TABLE OF CONTENTS Thermostat (transmitter)………………………………………………………………………………………………………………….. LCD Display……………………………………………………………………………………………………………………………….. Key Functions……………………………………………………………………………………………………………………………... Receiver (controller)………………………………………………………………………………………………………………………. Features……………………………………………………………………………………………………………………………………. Systems…….……………………………………………………………………………………………………………………………… Specifications………………..……………………………………………………………………………….……………………………. Wiring Schematics for Conventional Systems…………………………………………………………….…………………………… Wiring Schematics for Heat Pump Systems…………………………………………………………………………………………… Installation…………………………………………………………………………………………………………………………………. Charging the Thermostat………………………………………………………………………………………………………………… Mounting Transmitter and Receiver…………………………………………………………………………………………………….. Standard Terminal Outputs……………………………………………………………………………………………………………….
  • Page 3 ______________________________________________________ WTS32 Wireless Thermostat Auto Changeover….………………………………………………………………………………………………………………………… 39 Filter Monitor……….………………………………………………………………………………………………………………………… 39 Auto Recovery…………………………………………………………………………………………………………………………..…… 40 Keypad Lock…………………………………………………………………………………………………………………………………. 40 Error Mode…………………………………………………………………………………………………………………………………. Low Battery Warning……………………………………………………………………………………………………………………… Operation…………………………………………………………………………………………………………………………………… 42 Standby Mode……………………………………………………………………………………………………………………………… 42 Temperature Range……………………………………………………………………………………………………………………….. 42 Compressor Protection……………………………………………………………………………………………………………………. 42 Fan Operation………………………………………………………………………………………………………………………………. 42 Heating System…………………………………………………………………………………………………………………………….. 43 Cooling System…………………………………………………………………………………………………………………………….. 43 Emergency System –...

  • Page 4: Thermostat (Transmitter)

    ______________________________________________________ WTS32 Wireless Thermostat Thermostat (Transmitter) Model - 4350015 The Sea Breeze wireless set – WTS32 is LCD Display: Shows designed to control room temperature in an time, day, temperature, industrial, commercial or residential environment. and other feature It includes a (4350015) Wireless Thermostat and information as required.

  • Page 5: Lcd Display

    ______________________________________________________ WTS32 Wireless Thermostat LCD Display AUX On Heating On Cooling On Days of Week Compressor Delay Wait Cool On AUX Heat On Period Running Filter Change FILTER Recovery ° C indication Setpoint Temperature ° F indication HEAT Heat or Cool During Programming...

  • Page 6: Key Functions

    ______________________________________________________ WTS32 Wireless Thermostat Key Functions 950-0160revB February 2, 2012...

  • Page 7: Receiver (Controller)

    ______________________________________________________ WTS32 Wireless Thermostat Receiver (controller) Model 4350016 •Press to match to thermostat. SIG LED will illuminate. When signal is received from thermostat SIG LED will flash then turn off. Other LEDs will illuminate when signal is received from thermostat.

  • Page 8: Features

    ______________________________________________________ WTS32 Wireless Thermostat Features  Programming (armchair): 5+2, 5+1+1 or 7 day.  Programmable or non-programmable (selectable).  Temperature range: Heating 41˚F to 95˚F / Cooling 45˚F to 99˚F.  Thermostat power: Lithium battery (USB charging cable included). ...

  • Page 9: Systems

    ______________________________________________________ WTS32 Wireless Thermostat Systems Conventional System  Heat only  Cool only  1 stage cooling / 1 stage heating  2 stage cooling / 2 stage heating Heat Pump System  1 stage cooling / 2 stage heating ...
  • Page 10 ______________________________________________________ WTS32 Wireless Thermostat Heat Pump (No Aux. or Emergency Heat) Heat Pump (with Aux. or Emergency Heat) Standard Heat & Cooling Systems Two Stage Heat & Two Stage Cool Standard Heat Only Systems Millivolt Heat Only Systems– Floor or Wall...

  • Page 11: Specifications

    ______________________________________________________ WTS32 Wireless Thermostat Specifications Transmitter Technical Data (Thermostat) Power Lithium Battery, rechargeable Working environment 32° F~120° F Moisture 0～95%RH(non-condensing) Shell Fire retardant PC ABS Dimension 5.31”x3.74”x0.98” in (HxWxD) Communication interface Wireless Wireless carrier wave frequency 433 MHz Communication baud rate...
  • Page 12 ______________________________________________________ WTS32 Wireless Thermostat Receiver Technical Data (Controller) Power AC24V± 10%，50/60Hz Working environment 32° F~120° F Moisture 0～95%RH(non-condensing) Shell Fire retardant PC ABS Dimension 4.5x3.8x1.8 in (HxWxD) Connection interface Each terminal capable of accepting 2 x 18 AWG solid copper wires.

  • Page 13: Wiring Schematics For Conventional Systems

    ______________________________________________________ WTS32 Wireless Thermostat Wiring Schematics for Conventional Systems - Heat Only Receiver (Controller ) FAN RELAY HEAT RELAY E/W1 24 VAC 950-0160revB February 2, 2012...
  • Page 14 ______________________________________________________ WTS32 Wireless Thermostat Wiring Schematics for Conventional Systems - Cool Only Receiver (Controller ) FAN RELAY COOL RELAY E/W1 24 VAC 950-0160revB February 2, 2012...
  • Page 15 ______________________________________________________ WTS32 Wireless Thermostat Wiring Schematics for Conventional Systems - 1 stage cooling / 1 stage heating NOTE: Receiver When two transformers are in the system, (Controller ) the smaller transformer must be eliminated FAN RELAY and 24 VAC power must be supplied to the receiver.
  • Page 16 ______________________________________________________ WTS32 Wireless Thermostat Wiring Schematics for Conventional Systems - 2 stage cooling / 2 stage heating Receiver (Controller ) NOTE: When two transformers are in the system, FAN RELAY the smaller transformer must be eliminated and 24 VAC power must be supplied to the COOL RELAY receiver.

  • Page 17: Wiring Schematics For Heat Pump Systems

    ______________________________________________________ WTS32 Wireless Thermostat Wiring Schematics for Heat Pump Systems -1 stage cooling / 2 stage heating REVERSING VALVE Receiver IMPORTANT! – If using a Heat Pump (Controller ) System with fossil fuel as AUX Heat, FAN RELAY an external fossil fuel kit or outdoor...
  • Page 18 ______________________________________________________ WTS32 Wireless Thermostat Wiring Schematics for Heat Pump Systems - 2 stage cooling / 3 stage heating REVERSING VALVE Receiver (Controller ) IMPORTANT! – If using a Heat Pump System with fossil fuel as AUX Heat, FAN RELAY an external fossil fuel kit or outdoor...

  • Page 19: Installation

    ______________________________________________________ WTS32 Wireless Thermostat Installation Charging the Thermostat The thermostat is supplied with a replaceable lithium ion battery. The battery can be charged through a USB cable (included) connected to a PC or an optional power supply (PN 4350017). During the charging process the battery icon will flash on and off.

  • Page 20: Mounting Transmitter And Receiver

    ______________________________________________________ WTS32 Wireless Thermostat Mounting Transmitter and Receiver Transmitter Tools required: Screws and wall anchors are included for mounting the thermostat. To install the thermostat you should have the following tools and materials. ■ Slotted screwdriver ■ Phillips screwdriver ■ Hammer ■ Electric drill and 3/16” drill bit 1) Gently pry off the round metal mounting bracket on the back of the thermostat.
  • Page 21 ______________________________________________________ WTS32 Wireless Thermostat Receiver mounting ● Option 1: Tools required: To install receiver the following tools and materials are needed. ■ Slotted screwdriver ■ Small Phillips screwdriver ■ Hammer ■ Electric drill and 3/16” drill bit. This unit includes #6 X 1 slotted screws and wall anchors for mounting. Find an acceptable place to mount the receiver (about 60 inches off the floor and in an area with good air circulation).

  • Page 22: Standard Terminal Outputs

    ______________________________________________________ WTS32 Wireless Thermostat Standard Terminal Outputs Refer to equipment manufacturers' instructions for specific system wiring information. You can configure the receiver for use with either multi-stage electric heat systems or multi-stage gas systems. When configured for electric heat, the G terminal (blower/fan) will be energized on a call for heat.

  • Page 23: Heat Pump Terminal Outputs

    ______________________________________________________ WTS32 Wireless Thermostat Heat Pump Terminal Outputs Refer to equipment manufacturers' instructions for specific system wiring information. You can configure the thermostat for use with the following heat pump system types: Single stage compressor system; gas or electric backup. This thermostat is designed to operate a single-transformer system.

  • Page 24: Receiver Wiring Cover Installation

    ______________________________________________________ WTS32 Wireless Thermostat CAUTION! To prevent electrical shock and/or equipment damage, disconnect electric power to the system at the main fuse or circuit breaker box until installation is complete. WARNING Do not use on circuits exceeding specified voltage. Higher voltage will damage the control and could cause shock or fire hazard.

  • Page 25: Outdoor Sensor Wiring

    ______________________________________________________ WTS32 Wireless Thermostat Wiring cover removal Insert the screwdriver between the wiring cover and receiver cover and gently pry up on each side. Outdoor Sensor Wiring The terminal for outdoor sensor is on the right side. To access the outdoor sensor wiring, please follow the steps as below.
  • Page 26 ______________________________________________________ WTS32 Wireless Thermostat Step 2. Insert the screwdriver into the 8 square holes. Step 3. Wiring the outdoor sensor (part number 4350012) as Rotate the screwdriver clockwise to take off the base. shown. 950-0160revB February 2, 2012...
  • Page 27 ______________________________________________________ WTS32 Wireless Thermostat Step 5. Replace screw in bottom of base. Step 4. Press the case down as shown, until it snaps in place. Tips: Outdoor Sensor can be used for compressor lock out when the heat pump configuration is selected.

  • Page 28: Sea Breeze Ptac Receiver Installation

    ______________________________________________________ WTS32 Wireless Thermostat Sea Breeze PTAC Receiver Installation Step 1 – Disconnect power from PTAC unit. Step 2 - Attach receiver using BT (bit tap) #6X1/2” sheet metal screws. Do not use screws longer than 1/2". Step 3 – Connect receiver to thermostat terminal on PTAC using 18 awg.

  • Page 29: Matching Thermostat To Receiver

    ______________________________________________________ WTS32 Wireless Thermostat Matching Thermostat to Receiver When the thermostat and receiver are purchased together they are matched at the factory. If communication is lost between the thermostat and receiver, follow the matching instructions below. Step 1 - (Receiver): Power on the receiver and press the Match key for less than one second (key is on the right side of the receiver).

  • Page 30: Configuration Menu

    ______________________________________________________ WTS32 Wireless Thermostat Configuration Menu The configuration menu allows you to set certain thermostat operating characteristics to your system or personal requirements. To enter the configuration mode: - Press mode button until the “OFF” is displayed in the SYSTEM box.
  • Page 31 ______________________________________________________ WTS32 Wireless Thermostat INSTALLER/CONFIGURATION MENU (CONTINUED.) PROG Selects time format displays 12 or 24 hour PROG Selects compressor delay OFF or ON PROG Selects stages turn off sequence (COmfort or EConomy) PROG (1 =) Programmable (0 =) Non-Programmable (Selectable)
  • Page 32 ______________________________________________________ WTS32 Wireless Thermostat Step 2) Factory default is “ ” The thermostat can be configured to operate a heat/cool, fossil fuel (gas, oil, etc.), forced air system. “ ” should be electric heat - fan turns on with the call for heat.
  • Page 33 ______________________________________________________ WTS32 Wireless Thermostat Step 6) Factory default is “ ”. SPAN3 - Selects temperature, Stage3 activates from Stage2. (SPAN may also be understood as differential.) Step 7) Factory default is “ ”. Select Backlight function OFF or ON. Step 8) Factory default is “ ”.
  • Page 34 ______________________________________________________ WTS32 Wireless Thermostat IMPORTANT! – If using a Heat Pump System with fossil fuel as AUX Heat, an external fossil fuel kit or outdoor sensor must be installed and CONFIGURATION STEP 11 (STAGES) must be set to CO. The AUX will be activated when the room temperature reaches 3˚F or ˚C below set point if SPAN1, SPAN2 and SPAN3 are set to 1˚F or ˚C.
  • Page 35 ______________________________________________________ WTS32 Wireless Thermostat Step16) Factory default is “ ”. This function must be selected to “ ” if economy programming is to be activated. Activate the economy modes (step 17 and step 18) when “ ” is selected, the selected temperatures will be active when center round button is pressed.
  • Page 36 ______________________________________________________ WTS32 Wireless Thermostat Examples for setting SPAN in “Heat Mode” (Reference step 4. 5 and 6) Example 1 Example 2 Setpoint is set to - 72° F 72° F When - SPAN1 = 1 (° F) SPAN1 = 2 (° F) and - SPAN2 = 1 (°...

  • Page 37: Programming

    ______________________________________________________ WTS32 Wireless Thermostat Programming IMPORTANT: 1. Step number 12 must be selected to #1 before programming can be accessed. To begin programming select HEAT / COOL / AUTO. 2. Step 16 must be in selected to “ON” to activate the economy settings! Select 5+2 (Programming for week + weekend) or 7 day (Program each day individually).
  • Page 38 ______________________________________________________ WTS32 Wireless Thermostat 6) Press to select heat temperature. Press ▲▼ to select heat temperature for this period. (See NOTE 1:) PROG 7) Press to select period 2 (leave). PROG to continue and repeat from step 3. [Period 1 – wake], [Period 2 – leave], [Period 3 – return] [Period 4 – sleep].

  • Page 39: Setting Clock And Day

    ______________________________________________________ WTS32 Wireless Thermostat Setting Clock and Day ■ Initial display after power-up. The temperature will update after a few seconds. ■ During time and day setting mode, the temperature EXAMPLE: Set the thermostat to the current time of 9:43 a.m. on Saturday Refer to Figure below.

  • Page 40: Temporary Manual Override

    ______________________________________________________ WTS32 Wireless Thermostat Temporary Manual Override To temporarily change the current set temperature without affecting your program during the current period if program selection is made. ■ Press up or down key for less than 1 second to enter Manual Override mode.

  • Page 41: Scheduled Override

    ______________________________________________________ WTS32 Wireless Thermostat Scheduled Override To hold your Manual Override for vacation or until a designated day. System must be in HEAT, COOL, AUTO or EMER mode. If OFF mode is selected, Scheduled Override must be re-activated. HOLD ■ Press Hold/Run 2 times. Display will Indicate “Override Until”.

  • Page 42: Auto Changeover

    ______________________________________________________ WTS32 Wireless Thermostat Auto Changeover The Auto Changeover feature will not operate while the thermostat is in Permanent Override. When the AUTO mode is selected the thermostat will automatically change between Heating and Cooling. It is recommended keeping your programmed heating and cooling temperature at least 2˚F (2˚C) apart to allow the Auto Changeover to occur when the appropriate temperature span has been reached.

  • Page 43: Auto Recovery

    ______________________________________________________ WTS32 Wireless Thermostat Auto Recovery Auto Recovery calculates how early to turn your system back on, so that the room temperature is Room already comfortable by the start of the comfort temperature program period. Auto Recovery works RECO SYSTEM in both Heat and Cool modes.

  • Page 44: Error Mode

    ______________________________________________________ WTS32 Wireless Thermostat Error Mode If the thermostat is unable to control your system due to an unexpected problem, the thermostat will enter Error Mode. In this condition the thermostat flashes “E1” or “E2” on the LCD display and shuts off...

  • Page 45: Operation

    ______________________________________________________ WTS32 Wireless Thermostat Operation Standby Mode Press the ▲▼ buttons for 5 seconds or until the display shows ”PE”. The thermostat will disable wireless functions and will go into “Standby” mode to save battery power. Press it again for another 5 seconds to restart the thermostat.

  • Page 46: Heating System

    ______________________________________________________ WTS32 Wireless Thermostat Depending on system configurations and span selections the heating stage (terminals) will activate at different temperatures. The “AUX Heat On” will only display when a heat pump system (HP1 or HP2) is selected. Example: System selection HP2/SPAN1 = 2, Span2 = 2, Span3 = 2.

  • Page 47: Emergency System - Heat Pumps Systems Only

    ______________________________________________________ WTS32 Wireless Thermostat Emergency System – Heat Pump Systems Only EMER bypasses the Heat Pump to use the heat source wired to terminal E on the thermostat. EMER is typically used when compressor operation is not desired, or you prefer back-up heat only. If the heat pump system has two auxiliary heat sources W1 and W2 can be activated at different temperatures based on SPAN settings.

  • Page 48: Troubleshooting

    ______________________________________________________ WTS32 Wireless Thermostat Troubleshooting Problem Solution Scrambled or double display Remove clear Mylar sticker. (numbers over numbers). No display. Charge lithium battery. Entire display dims. Charge lithium battery. 1.Check that the time is set properly to “AM” or “PM”...
  • Page 49 ______________________________________________________ WTS32 Wireless Thermostat Problem Solution Erratic display. 1. Replace unit. 1. Check if the thermostat is working, and if there is power supplied to the receiver. 2. Check if the communication is correct. Match the thermostat and the receiver Receiver no output.

  • Page 50: Fcc Statement

    ______________________________________________________ WTS32 Wireless Thermostat FCCID: XLXA3900 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.

  • Page 51: Warranty

    ______________________________________________________ WTS32 Wireless Thermostat The user shall not make any changes or modifications to the equipment unless authorized by the Installation Instructions or User’s Manual. Unauthorized changes or modifications could void the user’s authority to operate the equipment and will void the product warranty.

  • Page 52: Technical Support

    ______________________________________________________ WTS32 Wireless Thermostat TECHNICAL SUPPORT If you need technical support please call 1-704-504-8590 M-F 8:00am to 4:30pm ET. When calling, please have your unit model number and serial number available. Electronic warranty activation and product information www.irproducts.biz . International Refrigeration Products, Inc.
