Seabreeze TSN11X Installation And Operation Manual

INTERNATIONAL REFRIGERATION PRODUCTS CO., INC.
LIMITED WARRANTY POLICY
International Refrigeration Products Co., Inc. (Hereinafter referred to as "IRP")
warrants the following:
Only cataloged products sold to distributors are warranted to the original
purchaser, to conform with specifications furnished or approved by IRP, and to be
free from defects in material and workmanship, for a period of one (1) year from
the date of purchase, unless specified in writing for a different period. Prior to
returning this product to IRP, the purchaser shall give IRP notice in writing stating
how this product fails to fulfill this warranty. No product shall be accepted for
repair or replacement without a required written notice and without prior written
authorization and shipping address having been received by the purchaser from
IRP. Only IRP's factory is authorized to perform services under this warranty.
Transportation charges are to be prepaid by the purchaser.
This warranty does not extend to any product that has been subjected to misuse,
abuse, neglect, accidents, alternations, improper installation or use in violation of
the printed instructions furnished by IRP. This warranty neither applies to
batteries not deterioration of, nor damage to the product caused by the use of
faulty batteries. Final determination as to whether any product is actually
defective rests solely with IRP.
This warranty is expressly in lieu of all other agreements and warranties,
expressed, implied, or statutory and IRP has no other obligations or liabilities in
connection with this product. In no event shall IRP's obligation or liability
hereunder exceed the purchase price of this product. IRP SHALL NOT IN ANY
EVENT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES.
This warranty gives you specific legal rights, and you also have other rights which
vary from state to state. Some states do not allow the exclusion or limitation of
incidental or consequential damages, or implied warranties, so the above
limitations or exclusion may not apply to you.
INTERNATIONAL REFRIGERATION PRODUCTS CO., INC.
Toms River, N.J. 08755
Customer Service
Phone: 704-504-8590
www.irproducts.biz
950-0078-revI
Fax: 704-504-3023
-12-
TSN11X SINGLE STAGE THERMOSTAT
1 Heat / 1 Cool single stage thermostat.
Non Programmable, Compatible with heat pump system
Installation and Operation Manual
Specification:--------------------------------------------------------------------------------
Power Supply: 20VAC-30VAC 50-60HZ or Battery powered.
Terminal Load: 1.0A per terminal, 3.0A maximum total load
Set Point Temp. Range: 45ºF to 90ºF (7ºC to 32ºC).
Accuracy: +/- 1ºF or +/- 0.5ºC.
Dimensions: 5.1" W X 3.7" H X 1.2" D
Color: White
FEATURES:---------------------------------------------------------------------------------
•
Large LCD display with backlight, continuous backlight option.
•
Simultaneous heat and cool set point storage.
•
Display of room temperature, set temperature and current time simultaneously.
•
Fan switch with ON and AUTO functions.
•
Permanent user setting retention during power loss. No batteries are required.*
•
Operates from 24VAC, or from 2 size "AAA" alkaline batteries.
•
Air Filter change Indicator.
•
Low Battery Indicator.
•
Temperature calibration.
•
Batteries required to maintain clock function.
IMPORTANT SAFETY INFORMATION-------------------------------------------
•
Always turn off power at the main power source by removing the fuse, or
switching the circuit breaker to the off position before installing, removing,
cleaning, or servicing this thermostat.
•
Read all of the information in this manual before installing this thermostat.
•
Use a professional contractor to install this thermostat.
•
This is a 24VAC low-voltage thermostat. DO NOT INSTALL ON VOLTAGES
HIGHER THAN 30 VAC.
•
ALL wiring must conform to local and national building and electrical codes and
ordinances.
•
Do not short (jumper) across terminals on the gas valve or at the system control to
test installation. This will damage the thermostat and void the warranty.
•
Do not switch the system to cool if the temperature is below 50ºF (10ºC). This
may damage the air conditioning system.
•
Replace batteries when the battery icon indicates the low battery message.
•
Change the Air Filter when the Filter Change Icon begins blinking.
•
Use this thermostat only as described in this manual.
-1-
November 21, 2008
