- Page 1 LAVA PayLink-IP/Dial Quick Installation Guide ™ Rev. B00...
-
Page 2: Getting Started
Getting Started Congratulations on your purchase of a LAVA PayLink-IP/Dial. PayLink-IP devices securely connect payment terminals to payment processors over an Ethernet/TCP/IP connection. Any payment terminal that can transmit transaction information over a POTS port can send its information to the LAVA PayLink-IP/Dial. -
Page 3: Hardware Setup
Hardware Setup 1. Connect the power supply to the LAVA PayLink-IP/Dial and to AC power.The power (red) LED will light to indicate that the unit is receiving power. 2. Connect an Ethernet cross-over cable to the Ethernet RJ-45 jack of the LAVA PayLink-IP/Dial . - Page 4 Serial port activity is indicated by two status LEDs per port.The yellow LED lights when the serial port is transmitting data.The green LED lights when the serial port is receiving data. POTS Tx indicator RJ-11 POTS POTS Rx connector indicator Single Port PayLink-IP/Dial...
-
Page 5: Configuring Network Settings
Configuration Configuration consists of the following: A. Configuring network settings B. Host configuration C. Protocol configuration D. Password selection E. Upgrading software A. Configuring network settings PayLink-IP devices installed on your network will need unique IP addresses.These are set by using a web browser. The factory default network settings for the PayLink-IP are: IP address: 192.168.0.35... - Page 6 Opening screen Click "Configure" if no password has been set, or enter the password for the PayLink you are configuring, and then click "Configure." The Configuration menu will open. Configuration Menu...
- Page 7 Changing the network settings of a PayLink-IP device that is installed on a network may make that device unavailable to other stations that have activated a connection to that device using older network settings. The following network parameters can be configured for the LAVA PayLink-IP/Dial:...
- Page 8 IP address The IP address for the LAVA PayLink-IP/Dial will identify the device on the LAN on which it is located. Any conventional IP address can be used.The LAVA PayLink-IP/Dial ships with its default IP address as 192.168.0.35;...
- Page 9 “DHCP enabled” checkbox has been set.The LAVA PayLink-IP/Dial will then act as a DHCP client and obtain its IP address from the DHCP server on its LAN that first leases an IP address to the LAVA PayLink-IP/Dial Assigned local TCP port...
-
Page 10: Host Configuration
B. Host configuration The PayLink-IP/Dial POTS port can be configured through a web browser.The settings for the LAVA PayLink-IP/Dial's host connection should match the requirements of the hosting server used by the payment terminal. Host Configuration The Host Side configuration dialog provides settings for a Primary Host, a Secondary host, and two additional user-defined hosts. - Page 11 Configuring the connection for SDLC communications consists of supplying basic modem communication parameters. SDLC Configuration Configuring the connection for asynchronous communications consists of supplying basic modem communication parameters as well as terminal settings that define the data format and message negotiation protocols for the terminal/server connection.
-
Page 12: Protocol Configuration
C. Protocol configuration The PayLink-IP/Dial Host Side Configuration screen has options for configuring SDLC or Asynchronous links, and the related message formatting protocols. for a variety of payment processing hosts. Users will need to supply the addressing information suitable to their specific payment processing hosts. - Page 13 Protocol Configuration (ASYNC) Protocol Configuration (SDLC)
-
Page 14: Password Selection
By default, the LAVA PayLink-IP/Dial's connection to the payment processor is set up using an SSL Ver. 3.0 link. Disabling this setting will set data over an unsecured TCP/IP link. By default, two host configurations (primary and secondary) are configured to the most common settings.These can be changed to suit specific needs, and additional strings can be defined for other host interfaces. -
Page 15: Upgrading Software
Password Selection E. Upgrading Software New versions of PayLink-IP software and firmware may be found at www.lavalink.com. -
Page 16: Technical Support
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. LAVA Computer MFG Inc. 908 Niagara Falls Blvd. #629. North Tonawanda NY 14120-2060...
