POWER ON BOARD PI500CP User Manual

500 watt dc to ac
Hide thumbs
Table of Contents

Advertisement

Quick Links

PI500CP_ManualEN_010807
1/8/07
4:48 PM
SPECIFICATIONS
Maximum Continuous Power:
High Surge Peak:
Input Voltage:
Output Voltage:
Output Wave Form:
Powers Up To:
USB:
Page 8
500 watts
1000 watts
12.5 volts
120 volts
Modified Sine Wave
4.2 amps
5VDC, 500mA
8
500 Watt DC to AC
Power Inverter
USER'S MANUAL
& WARRANTY INFORMATION
IMPORTANT SAFETY INFORMATION, SAVE THESE INSTRUCTIONS
TO REDUCE THE RISK OF INJURY, USER MUST READ AND UNDERSTAND
THIS INSTRUCTIONAL MANUAL. THIS MANUAL CONTAINS IMPORTANT
INFORMATION REGARDING THE OPERATION AND WARRANTY OF THIS
PRODUCT. PLEASE RETAIN FOR FUTURE REFERENCE.
4140 S.W. 30th Ave., Ft. Lauderdale, FL 33312
Toll Free: (800) 54-HOW-TO
PI500CP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PI500CP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for POWER ON BOARD PI500CP

Summary of Contents for POWER ON BOARD PI500CP

  • Page 1: Warranty Information

    PI500CP_ManualEN_010807 1/8/07 4:48 PM Page 8 SPECIFICATIONS PI500CP Maximum Continuous Power: 500 watts High Surge Peak: 1000 watts Input Voltage: 12.5 volts Output Voltage: 120 volts 500 Watt DC to AC Output Wave Form: Modified Sine Wave Power Inverter Powers Up To: 4.2 amps...

  • Page 2: Important Safety Instructions

    If such a product is returned more than 30 days but less • Do not insert foreign objects into the outlet. than two years from the purchase date, Power On Board will repair the unit or, at its option, replace it free of charge.

  • Page 3: How This Inverter Works

    Specifications ..........8 INTRODUCTION Your new Power On Board ®...

  • Page 4: The Power Inverter Output Waveform

    PI500CP_ManualEN_010807 1/8/07 4:48 PM Page 2 The DC-to-DC converter stage uses modern high frequency power conversion INSTALLATION AND OPERATING INSTRUCTIONS techniques that have replaced the bulky transformers found in less technologically- Power Source Requirements advanced models. The inverter stage uses advanced power MOSFET transistors in a full bridge configuration.

  • Page 5: Direct Hardwiring To Power Source

    PI500CP_ManualEN_010807 1/8/07 4:48 PM Page 4 Direct Hardwiring to Power Source This problem does not occur with the majority of battery-operated equipment. Most of these devices use a separate charger or Use #10 AWG wire if the inverter to power source connection is 10 feet or less. for transformer that is plugged into an AC outlet.

  • Page 6: Troubleshooting

    PI500CP_ManualEN_010807 1/8/07 4:48 PM Page 6 Battery Operating Time TROUBLESHOOTING An operating time of 2 to 3 hours can be expected from a typical vehicle battery. Common Audio/Visual Problems In most instances, 5 to 10 hours of operating time is achievable. However, the “Buzzing”...
