Safety, Installation And Operating Instructions
For The Following Battery Charger Models:
i2412, i3612, i4809, i2425, i3625, and i4818
IMPORTANT NOTICE:
Please save and read these safety, operating and installation instructions
before installing or applying AC power to your Charging Systems International
charger. Contact Charging Systems International with any product, installation,
or service questions at 1-800-742-2740.
Charging Systems International
Nashville, TN • 1-800-742-2740
#Eagle Series
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Charging Systems International i-2412
Summary of Contents for Charging Systems International i-2412
- Page 1 IMPORTANT NOTICE: Please save and read these safety, operating and installation instructions before installing or applying AC power to your Charging Systems International charger. Contact Charging Systems International with any product, installation, or service questions at 1-800-742-2740.
- Page 2 INTRODUCTION Charging Systems International has been manufacturing quality battery charging systems since 1989. Our products are designed and built tough to withstand intense vibration and extreme temperature variations. Temperature compensation is utilized to fully charge a battery in hot or cold environments and all of our systems are controlled by microprocessors in order to assure precise operation.
- Page 3 Personal Safety Precautions Always read all instructions before using your charger! Wear complete eye protection and clothing protection. Avoid touching eyes while working near battery. Have plenty of fresh water and soap nearby in case battery acid contacts skin, clothing or eyes. If battery acid contacts skin or clothing, wash immediately with soap and water.
- Page 4 INSTALLATION AND PREPARATION To reduce risk of battery explosion, follow these WARNING instructions, those published by battery manufacturer, and manufacturer of any equipment you intend to use in vicinity of battery. Review cautionary markings on these products and on engine. If it is necessary to relocate the battery for charging, first remove the grounded terminal from the battery.
- Page 5 We recommend that you leave your system plugged in to reduce sulfate build-up and to allow your Charging Systems International charging system to keep your batteries fully maintained and ready to perform at their best.
- Page 6 Charging Indications When your battery charging system is activated, the battery status indicator provides charging information utilizing five red LED indicators and one green LED indicator. Normal indications: Red LED indicators — Five red LED indicators are provided in order to display the progress of the charge cycle in percentage of charge.
- Page 7 TROUBLESHOOTING PROBLEM: No LED indicators illuminated on battery status indicator. Solution Sequence: 1. Confirm that current is being delivered to the charger. Use a meter or test light to check the AC power supply from its source through all connecting points up to the charger.
- Page 8 LIMITED WARRANTY Charging Systems International makes this Limited Warranty only to the original retail purchaser. Charging Systems International warrants this battery charger for three years from the date of retail purchase against defective materials and/or workmanship. If such should occur, this unit will either be repaired or replaced at the discretion of the manufacturer.
