INSTALLATION
Using a New Construction Bracket:
(See Figure 12 on page 17.)
1. Connect a properly configured CAT-5 cable to the T568A system terminal
on the back of the keypad.
2. Install keypad to Display Keypad Mounting Bracket (IntelliControl ICS
Part #FG01192; not included) as shown.
3. Finish with appropriate color trim plate.
See "Accessories" in this guide for color options and part numbers.
