Related Manuals for MiTraveler 10D8B
Summary of Contents for MiTraveler 10D8B
- Page 1 Android 4.2 10.1” Tablet User Manual Model: 10D8B...
-
Page 2: Table Of Contents
Tablet of Contents Specifications………………………………………………………………….1 What‟s inside the box…………………………………………………………2 Tablet Parts………………………………………………………………….…3 Getting started………………………………………………………………...4 Connect/disconnect the device with/from the computer ……………….16 Install Applications(.apk file) into the device …………………………….16 Trouble Shooting……………………………………………………………...17 Specifications Operation System Google Android 4.2 Gingerbread... - Page 3 Language Multi-Language A20 Dual-Core, ARM Cortex A7@1.0Ghz Mali-400MP2 OpenGL ES2.0 Open CL1.x,DX9_3 Memory RAM 1G DDR3 Nand Flash Storage Extend 4GB-32GB micro SD/TF Support 10.1 inch TFT LCD Display Screen 1024*600 Pixels System Touch Panel Multi-touch Capacitive TP 1*DC 5V Power port 1*Micro USB 1*Micro SD/TF Card slot (Up to 32GB) I/O interface...
-
Page 4: What"S Inside The Box
entertainment Movie, Online Music, Online Radio. EPUB, WORD, EXCEL, POWERPOINT, Office software PDF, TXT There are more than half a million free apps Extend in Google Play Store Input: AC100-240V.50-60HZ ， Output: Power Adapter: DC5V/2A Other Battery: 3.7V/6000mAh polymer battery What’s Inside The box 10.1”... -
Page 5: Getting Started
Important Notice - If the device is freezing or stuck, press the reset button(a small hole) or long press power button for 7 seconds. - When the performance is slow after using some applications, it is recommended to close running application in setting menu. Caution: - For charging, be sure to use one of the DC5V power adapters provided in the package;... - Page 6 Battery Charging The tablet has a built-in rechargeable Li-polymer battery. 1. To charge connect the AC power adapter to the DC jack on the right side of the tablet. 2. When you see “ ” in the tablet, it show the battery is charging. 3.
- Page 7 Note: 1) TF card is not included in the package. It is available in electronic stores. 2)Insert the TF card in correct position, otherwise it will damage the card and the slot. Soft Keyboard The tablet has a soft keyboard which automatically shows up when you tap the place on screen where text or numbers are to be entered.
- Page 8 3. Standby mode(Screen off )/Unlock the screen Short press the power button to turn on/off the screen (Standby mode on/off) After standby mode , slide the lock icon in order to unlock the screen. 4. Wallpaper Settings On the desktop,long press desktop and select one of categories the wallpaper, then choose one picture as wallpaper.
- Page 9 5. Desktop Shortcuts Icon Settings: Press the menu button on the desktop enter into Apps, then Long press your desired APK icon and put it on the desktop. 6. Widgets: Press widgets and press the icon you like and put it on the desktop...
- Page 10 7. System Settings: Press menu icon on the desktop to go into app, then select “Settings”. ◆ Wifi: slide on/off button to connect or disconnect Slide Wi-Fi to on, then the device will automatically search the available Wi-Fi signals. Select the network you want to connect with. Enter the password (if there is any) and click „Connect‟.
- Page 11 ◆ More: you can set whether need airplane mode or not ◆Sound: Set Volumes, vibrate when ringing, default notification, Touch sounds, screen lock sound, vibrate on touch...
- Page 12 ◆ Display: you can set Brightness, wallpaper, sleep time, font size and TV out ( HDMI & output screen size ) ◆ Storage: you can check used storage and available storage...
- Page 13 ◆ Battery: Shows the battery usage status ◆ App: All installed applications are listed. Manage downloaded or running applications. View and control currently running services.
- Page 14 Press Uninstall to uninstall the selected application. ◆ Location services: Google‟s location service, location& google search Allow apps use data from sources such as WiFi and mobile networks to determine your approximate location. ◆ Security Screen lock: None, slide, face unlock, pattern, pin, password Owner info Make password visible Device administrators...
- Page 15 Trusted credentials: display trusted CA certificates Install from SD card – Install certificates from SD card. ◆ Language & input: choose language you like and input Keyboard & input method – Change keyboard & keyboard settings. Default input is English Android keyboard ( AOSP )
- Page 16 ◆ Backup & reset : backup data and factory data reset ◆ Date & time: You can set date and time ◆ Accessibility: Large text, auto-rotate screen, speak password, test-to -speech output, touch & hold delay, enhance web accessibility, enable quick boot, system performance...
- Page 17 ◆ Developer options: Set options for application development ◆ About tablet : status, legal information, model No., Android Version.,kernel version and build number .etc...
-
Page 18: Connect/Disconnect The Device With/From The Computer
How to connect/disconnect the device with/from the computer On main desktop, connect the device with the PC, The device will entry USB storage interface select “Turn on USB storage”. Pop-up a window and Press “OK” The device is recognized at Explorer of the computer. Now you can use it as an external storage. -
Page 19: Trouble Shooting
Trouble Shooting Close Application All running applications take up system memory and will slow down system response. Please shut down all idle applications to release memory and get the system speed back to normal. To close the application, click the icon on the shortcut bar to enter the system configuration interface. - Page 20 530 Showers Dr., Suite #7-204 Mountain View, CA 94040 Tel. 1-888-33-Tivax (1-888-338-4829) Fax. 1-650-963-3585 Website: www.tivax.com...
