Summary of Contents for Westinghouse DWM48F1Y1

  • Page 1 USER’S MANUAL MANUEL DE L’UTILISATEUR MANUAL DEL USUARIO DWM48F1Y1...
  • Page 2 VGA(PC)Connection USB Port Function HDMI&Coaxial&Auido out Connection USB Menu...
  • Page 4 78.8...
  • Page 5 Fix the stand support to the TV using 6 pcs screws. Fix the base stand to the TV using 6 pcs screws.
  • Page 9 MENU Button 6.INPUT Button POWER Button blue 1.USB 2.PC AUDIO IN Jack 3.COMPONENT/VIDEO IN and AUDIO IN Jack 4.Coax OUT Jack 5.AUDIO OUT Jack 6.Headphone Jack 7.TV ANTENNA Terminal 8.VGA IN Jack 9.HDMI IN Jack AUDIO OUT...
  • Page 11 Audio left is white,and Audio right is red. AUDIO OUT Audio left is white,and Audio right is red. AUDIO OUT...
  • Page 12 AUDIO OUT PC Audio Cable AUDIO OUT...
  • Page 13 COAXIAL and AUDIO OUT AUDIO OUT...
  • Page 14 Turn the LED TV on or off. Press once to disable the audio and press again to enable the audio. P.MODE S.MODE Press to adjust between available audio channel. SLEEP SOURCE Displays INFO Press to set the closed caption. V-CHIP Switch to V-CHIP input. CH.LIST Press to display the TV program list.
  • Page 16 HOME Power On Mode Use the Up , Down arrows on your remote control to select power on mode. Home optimizes the video settings for Energy Star qualification. Do you want to set Home mode(Energy saving)? OK: Next :Select OK: Next Retail Power On Mode Use the Up...
  • Page 17 Use the Up and Down arrows on your remote control to select the channel scan type. YPbPr YPbPr/AV Total Found Menu:Skip DTV YPbPr/AV HDMI1 HDMI2 HDMI3...
  • Page 18 Select Input Source Source Select YPbPr/AV HDMI1 HDMI2 HDMI3 Basic Operation Lock...
  • Page 19 Lock Color Temperature Normal Color Temperature Press button to select Color Temperature ,then press button to adjust. Available color Temp. mode:Warm,Cool,Normal.
  • Page 20 Lock Lock Color Temperature Normal Off,Weak,Medium,Strong. Lock Lock Custom Color Saturation Brightness Reset...
  • Page 21 the option you want press Lock Lock...
  • Page 22 AUDIO Menu Lock Sound Mode Standard Bass Treble Balance Stereo Digital Audio Ouput Surround Mode Audio Audio menu. Sound Mode Sound Mode Sound Mode Surround Mode Surround Mode On or Off...
  • Page 23 TIME Menu Lock Sleep Timer Sleep Timer...
  • Page 24: Osd Timeout

    Lock OSD Timeout OSD Timeout OSD Timeout Lock Digital CC Service1 Option...
  • Page 25 Digtial CC Press button to select Advance Selection,then press button to select Service1,Service2 Service3,Service4,Service5,Service6,off. Option Press button to select Option,then press button enter submenu. Lock Lock (0000) Lock Lock Enter Password Press “OK” to confirm...
  • Page 26 Lock Lock Change Password Block Unrated a sub menu will 8899 Lock Lock Lock Block Unrated...
  • Page 27 Lock Unblock YPbPr/AV Unblock Unblock HDMI1 Unblock HDMI2 Unblock HDMI3 Block Unrated Unblock Unblock Lock Lock Block Unrated Lock Lock Block Unrated...
  • Page 28: Signal Type

    Lock Signal Type Signal Type Signal Type Signal Type Lock Lock Total Found Lock Channel Label Prev Next...
  • Page 29 Lock Channel Label Lock...
  • Page 30 Setup Lock Lock AUDIO...
  • Page 31 USB Menu Note:Before operating Media menu,Plug in USB device,then press SOURCE button to set the Input Source to USB. Press S/T button to select USB in the Source menu,then press OK button to enter. M-JPEG Press ◄ / ► button to select the option you want to adjust in the main Media menu,then press OK button to enter.
  • Page 32 Press ◄ / ► button to select the file you want to watch in the file selecting menu,then press OK button to display picture. When highlighting the option you select,the file information will appear on the right and Picture will be previewed in the center.
  • Page 34 47.6 1920x1080 120 W ATSC/NTSC AUDIO - OUT JPEG, M-JPEG 1097 x 257 x 711 mm 1097 x 90 x 644 mm 19.5...
  • Page 35 S/N: Westinghouse Digital, LLC Orange, CA SE-UM-4802-1301...
