• With the engine running, engage the safety latch to the
spray gun trigger (Figure 10).
Figure 10 — Spray Gun with Safety Latch Engaged
• Attach the nozzle extension to the spray gun. Tighten by
hand (Figure 11).
Figure 11 — Connect Nozzle Extension to Spray Gun

How to Stop Your Pressure Washer

• Move the throttle lever to the "Slow" position.
• Wait for the engine to idle down.
• Move the engine switch to the "Off" position.
• Simply shutting off the engine will not release pressure in
the system. Squeeze trigger on the spray gun to
relieve pressure in the hose.
NOTE: A small amount of water will squirt out when you
squeeze the trigger.
Figure 12 — Nozzles
Low Pressure
Use to apply
chemical
Black
25°
Generac Portable Products 2,500 PSI High Pressure Washer
Safety Latch
White
40°
How to Use the Nozzles
If you have any problems operating your pressure washer,
please call the pressure washer helpline at
1-800-270-1408.
CAUTION!
locking the safety latch on the trigger.
The quick–connect on the nozzle extension allows you to
switch between five different nozzles. The nozzles vary the
spray pattern as shown below (Figure 12).
Follow these instructions to change nozzles:
• Engage the safety latch on the spray gun.
• Pull back the collar on the quick–connect and pull the
current nozzle off. Store the nozzle in the space provided
on the control panel.
NOTE: For a more gentle rinse, select the white 40° or
green 25° nozzle. To scour the surface, select the yellow
15° or red 0° nozzle. To apply chemical, select the black
nozzle.
• Pull back on the collar, insert the new nozzle and release
the collar. Tug on the nozzle to make sure it is securely
in place.
• For most effective cleaning, keep the spray nozzle
between 8 to 24 inches away from the cleaning surface. If
you get the spray nozzle too close, you may damage the
cleaning surface.
High Pressure
Green
25°
9 9
Never exchange nozzles without
Yellow
15°
Red
0°
