IMPORTANT: Read entire owner's manual before you
attempt to assemble or operate your new pressure washer.
REMOVE PRESSURE
WASHER FROM
CARTON
• Remove the handle and parts box included with pressure
washer.
• Slice two corners at the end of carton from top to
bottom so the panel can be folded down flat, then
remove all packing material.
• Roll pressure washer out of carton.

Carton Contents

Items in the carton include:
• Main Unit
• High Pressure Hose
• Handle
• Parts Box containing:
- 20oz Oil Bottle
- Goggles
- Nozzle Cleaning Kit
- Bag containing 5 multi–colored nozzles
- O–Ring Maintenance Kit
- Owner's Manual
- Engine Manual
- Warranty Card
- Engine Warranty
- Emissions Control Warranty
- Spray Gun
- Nozzle Extension with Quick–Connect Fitting
- Parts Bag containing:
4 Carriage Bolts
4 Flange Nuts
If any of the above parts are missing or damaged, call the
pressure washer helpline at 1–800–270–1408.
Generac Portable Products 2,500 PSI High Pressure Washer
PREPARING PRESSURE
WASHER FOR USE
If you have any problems with the assembly of your
pressure washer or if parts are missing or damaged, call the
pressure washer helpline at 1–800–270–1408.
To prepare your pressure washer for operation you will
need to perform these tasks:
• Fill out and send in your registration card for a valid
warranty.
• Attach the handle to the main unit.
• Add oil to the engine.
• Add fuel to the fuel tank.
• Connect the high pressure hose to the spray gun and the
pump.
• Connect the water supply to the pump.
• Connect nozzle extension to gun.
• Select and install desired nozzle.
Attach Handle to the Pressure
Washer
Use either a 13mm wrench or adjustable wrench to attach
the handle to the pressure washer.
To attach handle to the pressure washer:
• Slowly tip the pressure washer forward and let it gently
rest on the front bumper (Figure 1).
Figure 1 — Attach Handle to Pressure Washer
