USB 802.11b Wireless LAN Adapter
Installation
Install the Driver & Utility
Note: Always remember to install the Driver
& Utility before you plug USB cable into the
PC's USB port.
In Windows 98SE/ME
For Windows 98SE users: As you perform the
installation,
CD-ROM at hand. You may be asked to insert
the OS CD-ROM for the system to download a
specific driver.
1. Insert
the
CD-ROM drive. Double click on Setup.exe to
install the Wireless LAN Driver & Utility.
2. In the Welcome screen, click Next.
3. Click Next; Windows will copy all the
necessary files to your system.
4. When Windows prompts you to restart your
computer, select Yes and click OK.
have
your
supplied
CD-ROM
1-1
M73-APO01-700
system
operating
into
the
Advertisement
Related Manuals for Abocom WBD512
Summary of Contents for Abocom WBD512
- Page 1 USB 802.11b Wireless LAN Adapter Installation Install the Driver & Utility Note: Always remember to install the Driver & Utility before you plug USB cable into the PC’s USB port. In Windows 98SE/ME For Windows 98SE users: As you perform the installation, have CD-ROM at hand.
- Page 2 In Windows 2000 1. In the Welcome screen, click Next. 2. Click Next; Windows will copy all the necessary files to your system. 3. In the Digital Signature Not Found window, click Yes to continue. 4. Restart your computer. In Windows XP 1.
-
Page 3: Install The Device
Install the Device 1. Plug the square end (Type B) of USB cable into the adapter's USB port. 2. Plug the rectangle end (Type A) of USB cable into the PC's USB port 3. After installing the Wireless USB Adapter, Windows will automatically detect the new device. - Page 4 2. Once the “Please insert the disk labeled ‘Windows 98 Second Edition CD-ROM’, and then click OK” window appears, click 3. Select the correct drive and click OK. Windows will copy all the necessary files to your system.
- Page 5 Windows will auto-detect the 802.11b USB Adapter promptly as the icon showed below. In Windows ME 1. Windows will auto-detect the 802.11b USB Adapter and a “New Hardware Found” window will show up. 2. Windows will auto-detect the 802.11b USB Adapter promptly as the icon showed below.
- Page 6 In Windows 2000 1. In Digital Signature Not Found window, click Yes to continue. 2. Windows will auto-detect the 802.11b USB Adapter promptly as the icon showed below. In Windows XP 1. Windows will auto-detect the 802.11b USB Adapter and a “Found New Hardware Wizard”...
- Page 7 USB 802.11b Wireless LAN 2. Wait and the Wizard will search for the 802.11b USB Adapter. 3. Click Continue Anyway to proceed.
- Page 8 USB 802.11b Wireless LAN 4. Click Next; Windows will copy all the necessary files to your system. 5. Click Finish to complete the installation.
- Page 9 USB 802.11b Wireless LAN 6. Windows will auto-detect the 802.11b USB Adapter promptly as the icon showed below. Configuration Once the driver and utility has been installed, and the device is properly connected to your computer, you can now start using this device with the default settings.
-
Page 11: Install Driver
USB Flash Disk (Optional) Install Driver Windows 98/98SE – Install from CD ROM In Windows 98/98SE, you will need to install the driver found on the CD that comes with this device. Run Flash Driver.exe. 1. Follow the on-screen instructions to proceed. 2. - Page 12 4. Open My Computer and you will see a newly added icon; shown on the screen as a removable disk drive. Windows ME/2000/XP-No Driver is Required This device is Plug and Play compliant, therefore, once you plug it into your Window’s based system, your system will automatically detect it as a removable hard disk.
- Page 13 Manage your USB Flash Disk Main Menu Load the included CD and open it. Double-click MYKEY. An USB Flash Disk icon will appear on your desktop appear on the bottom right corner of the task bar on your screen. Right-click the Click Option.
-
Page 14: Disk Manager
Disk Manager Disk Manager is readable only. On this box, you will know the used/free capacity of your flash disk. Disk Partition In this box, you can divide the USB Flash Disk into two partitions: Un-protected Disk Space: all data located here is accessible to anyone who uses your computer or Flash Disk. - Page 15 Press Create Partition. A warning message appears to advise that all data on the disk will be erased. You can cancel this action by clicking Cancel. Or click OK to continue. Click Cancel to copy your data to a Hard Disk before creating your prtition.
- Page 16 Switch between Protected and Un-protected Disks Enter the Protected Disk Right click You are prompted to enter your password. The default password is 0000. It is suggested that you set your own password. forget your password, press your password hint. .
-
Page 17: Password Manager
Once you enter the protected disk, the disk icon shown in My Computer will change from Enter the Un-protected Disk Right click to enter the Un-protected Disk. Password Manager Password can be changed in this box. You can also set a password hint for use if you forget your password. - Page 18 Change Password Enter the “Old Password”, the default is “0000”. Enter the “New Password”. (Maximum 4 characters long – use letters or numbers) Confirm password by re-entering the new password. Enter a hint of your own; this will be helpful to remind you if you forget your password.
- Page 19 Plug-in USB Flash Disk This means that you have to plug this USB Flash Disk into your computer’s USB port in order to open your PC; Plug-in USB Flash Disk and Input Password This means to open the PC, you are required not only to plug the USB Flash Disk, but also have to enter your password.
- Page 20 4. Select the Unlock Condition that fits your needs. 5. Press Change. 6. Press Exit. Return to your desktop and right click Move the cursor to PC Lock now locked. If this function is enabled, your PC will not respond unless this USB Flash Disk is plugged To unlock a PC 1.
