Hotpoint WMF 740 P Instructions For Use Manual
Hotpoint wmf 740 p/g/a/k/x washing machines instructions for use
Hide thumbs
Also See for WMF 740 P:
- Instructions for use manual (17 pages) ,
- Instructions for use manual (17 pages)
Table of Contents
Advertisement
Instructions for use
GB
English, 1
WMF 740 P/G/A/K/X
Contents
Installation, 2-3-4-5
Connecting the electricity and water supplies
Wash cycles, 8
Table of wash cycles
Cutting off the water or electricity supply
Troubleshooting, 13-14
Assistance, 15-16
WASHING MACHINE
GB
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hotpoint WMF 740 P
Summary of Contents for Hotpoint WMF 740 P
-
Page 1: Table Of Contents
Indicator lights Starting a wash cycle Wash cycles, 8 Table of wash cycles Personalisation, 9 Setting the temperature WMF 740 P/G/A/K/X Setting the spin speed Functions Detergents and laundry, 10 Detergent dispenser drawer Preparing the laundry Garments requiring special care... -
Page 2: Unpacking And Levelling
Installation 2. If the floor is not perfectly level, compensate for any Keep this instruction manual in a safe place for future refe- unevenness by tightening or loosening the adjustable front rence. Should the appliance be sold, transferred or moved, feet (see figure);... -
Page 3: Connecting The Drain Hose
Connecting the drain hose • the supply voltage is included within the values indicated on the Technical details table (see page 5); Connect the drain hose, without bending it, to a • the socket is compatible with the washing machine’s plug. draining duct or a wall drain If this is not the case, replace the socket or the plug. -
Page 4: The First Wash Cycle
The first wash cycle As the colours of the wires in the lead may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: Once the appliance has been installed, and before you use Connect Green & Yellow wire to terminal marked E or it for the first time, run a wash cycle with detergent and no or coloured Green or Green &... -
Page 5: Technical Data
Technical data Model WMF 740 P/G/A/K/X width 59.5 cm Dimensions height 85 cm depth 53,5 cm Capacity from 1 to 7 kg Electrical please refer to the technical data plate fixed to the machine connections maximum pressure 1 MPa (10 bar) Water connections minimum pressure 0.05 MPa (0.5 bar) -
Page 6: Description Of The Washing Machine And Starting A Wash Cycle
Description of the washing machine and starting a wash cycle Control panel WASH CYCLE PROGRESS indicator lights DISPLAY DOOR ON/OFF TEMPERATURE LOCKED button with indicator button light indicator light START/PAUSE SPIN SPEED button with FUNCTION Detergent dispenser drawer indicator light button buttons with indicator lights... -
Page 7: Indicator Lights
Indicator lights Temperature indicator light When a temperature value is selected, the correspon- ding indicator light will illuminate. The indicator lights provide important information. This is what they can tell you: Wash cycle phase indicator lights As the WASH CYCLE knob is rotated, the indicator lights illuminate, indicating the stages which will be performed by Spin indicator light the machine in accordance with the selected wash cycle. -
Page 8: Wash Cycles
Wash cycles Table of wash cycles Max. Max. Detergents load load Max. Max. (kg) (kg) Description of the wash cycle temp. speed Cycle duration (°C) (rpm) Fabric Mini Wash Normal softener load Essentials cycles Cottons: extremely soiled whites. 90° 1400 ... -
Page 9: Personalisation
Personalisation Setting the temperature By pressing the TEMPERATURE button to set the wash temperature (see Table of wash cycles). The temperature may be lowered, or even set to a cold wash ( ). The washing machine will automatically prevent you from selecting a temperature which is higher than the maximum value set for each wash cycle. -
Page 10: Detergents And Laundry
Lingerie cycle: for undergarments of any colour, in any fabric. Use special wash cycle 8. Wool: Hotpoint is the only washing machine manufac- turer to have been awarded the prestigious Woolmark Do not pour detergent into the middle compartment (*). -
Page 11: Precautions And Tips
Precautions and tips Consumers should contact their local authority or This washing machine was designed and constructed retailer for information concerning the correct in accordance with international safety regulations. The disposal of their old appliance. following information is provided for safety reasons and must therefore be read carefully. -
Page 12: Care And Maintenance
Care and maintenance 2. unscrew the lid by rota- Cutting off the water and electricity supplies ting it anti-clockwise (see figure): a little water may • Turn off the water tap after every wash cycle. This will trickle out. This is per- limit wear on the hydraulic system inside the washing fectly normal;... -
Page 13: Troubleshooting
Troubleshooting Your washing machine could fail to work. Before contacting the Technical Assistance Centre (see “Assistance”), make sure that the problem cannot be not solved easily using the following list. Problem: Possible causes / Solutions: The machine does not switch on. •... - Page 14 The machine is noisy. • There will always be some motor, pump and drum noise during spin. The machine wont spin properly. • Out of Balance detected when attempting to go into a spin cycle - If this happens the machine will continue to try to repeat the distribution of the load required before the machine will go into higher spin speeds - This will increase the programme time accordingly.
-
Page 15: Assistance
DOMESTIC PREMISES. 5 Year Parts Guarantee Hotpoint also offers you a free 5 year parts guarantee. This additional guarantee is conditional on you registering your appliance with us and the parts being fitted by one of our authorised engineers. There will be a charge for our engineer’s time. -
Page 16: After Sales Service
195093886.00 05/2011 - Xerox Fabriano After Sales Service No one is better placed to care for your Hotpoint appliance during the course of its working life than us - the manufacturer. Essential Contact Information Hotpoint Service We are the largest service team in Europe offering you access to 400 skilled telephone advisors and 1000 fully qualified engineers on call to ensure you receive fast, reliable, local service.
