User Manual
CBTL
™
is an easy to use,
elegant, single serve brewing
system, based on the proprietary
Caffitaly System, that allows
you to enjoy all the pleasures of
an authentic The Coffee Bean &
Tea Leaf
café beverage at
®
home. One capsule is all you
need to create a single serving
to savor. One touch is all it
takes to brew fresh, fragrant
and flavorful espresso, brewed
coffee or tea. One taste is
enough to transport you to a
moment of comfort—the comfort
of one perfect cup.
One Touch.
One Perfect Cup.
CBTL.com
KALDI
Model S04
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CBTL KALDI S04
Summary of Contents for CBTL KALDI S04
- Page 1 User Manual KALDI Model S04 CBTL ™ is an easy to use, elegant, single serve brewing system, based on the proprietary Caffitaly System, that allows you to enjoy all the pleasures of an authentic The Coffee Bean & Tea Leaf café...
-
Page 2: Table Of Contents
Important Safeguards _ _ _ _ _ _ _ _ _ _ _ _ _ _3 Your CBTL™ System contact _ _ _ _ _ _ _ _ _ _ _ _4... -
Page 3: Important Safeguards
Appliance is intended to prepare beverages according to these instructions. Use only CBTL™/Caffitaly System capsules. CBTL™ assumes no liability for damages from use that is not in accordance with the instructions. 4. The use of accessory attachments not recommended by the appliance manufacturer may result in fire, electric shock or injury to persons. -
Page 4: Your Cbtl™ System Contact
22. Consult a qualified electrician if the grounding instructions are not completely understood, or if doubt exists as to whether the appliance is properly grounded. 23. The CBTL System uses a short power-supply cord to prevent the cord from tangling and to reduce the risk of tripping over a long cord. -
Page 5: Kaldi Overview
Kaldi Overview Capsule compartment access Lever for opening capsule compartment Water tank access Water tank Beverage dispensing spout Used capsule container for 9-11 capsules Drip tray Power cord Power on/off switch Espresso button Long espresso button Descale indicator light Alarm indicator light Brewed coffee/tea button... -
Page 6: Safety And Indicator Symbols
Safety and Indicator Symbols CAUTION This is a safety warning symbol used to call your attention to possible risks of personal injury. NOTE This symbol is used to highlight some actions that will optimize use of the appliance. Dishwasher safe. Not dishwasher safe. -
Page 7: Rinsing Machine Before First Use
Rinsing machine before first use Warning! Use only filtered/ bottled water in this applian- ce! Do not put any other liquid or food in the water tank, except as instructed in the descaling section of this instruction book. Fill the water tank with filtered/bottled water. Plug into outlet then switch on. -
Page 8: Preparing Your Beverage
When the buttons remain steadily lit, the machine is ready for use. A frozen or extremely cold CBTL™ machine will not operate efficiently when exposed to temperature below freezing. Allow at least 2 hours to reach room temperature before brewing. - Page 9 Preparing your beverage Espresso Long espresso Brewed coffee/tea Press your desired beverage button. The selected beverage button will blink. The machine will stop dispensing beverage on reaching the programmed quantity, and beep. Raise lever to eject used capsule into the used capsule container. Close the lever.
-
Page 10: Descale Indicator
Indicator light guidelines DESCALE INDICATOR When the descale indicator light blinks and the machine beeps, it is When the descale and alarm indicator lights blink alternately and the advisable to carry out a descaling cycle. machine beeps, it is necessary to carry out a descaling cycle. EMPTY WATER TANK INDICATOR When the alarm indicator light blinks and the machine beeps, Fill the tank with filtered/bottled water. - Page 11 Indicator light guidelines INTERRUPTED OPERATION INDICATOR When the lever is raised while a beverage is being dispensed— The alarm indicator light will blink and beep. The machine will immediately stop dispensing. Close the lever. Press a beverage button to reset the alarm indicator light. Espresso Long espresso Brewed coffee/tea...
-
Page 12: Programming Quantity Of Beverage Brewed
Programming quantity of beverage brewed Warning! Before you start brewing, make sure the capsule container is not full. Raise the lever to open the capsule compartment. Insert the capsule, pressing it gently into place. Close the lever firmly. Place a cup or mug under the beverage dispensing spout. Espresso Long espresso Brewed coffee/tea... -
Page 13: Programming Energy Saving Function
Programming energy saving function The Kaldi features an energy saving function (normally activated) which automatically reduces energy consumption by around 98% one hour after last use. To deactivate (or reactivate) this function, proceed as follows: Make sure the lever is lowered. Keep long espresso and brewed coffee/tea buttons pressed down and The alarm indicator light will blink and beep three times to confirm simultaneously switch machine on. -
Page 14: Adjusting For Different Cup Sizes
Adjusting for different cup sizes To use espresso cups, lift and turn the grill on top of the drip tray. The machine is initially set for use of 10 ounce cups/mugs. The grill must be positioned over the drip tray turned. Your machine is now set for use of espresso cups. -
Page 15: Daily Maintenance
Daily maintenance Lift the capsule container, empty and rinse. Remove the drip tray and used capsule container. Remove the grill. Empty the drip tray and rinse it with fresh water. Remove the water tank. Empty and rinse. NOTE: The water tank is NOT dishwasher safe. Use a soft, dampened cloth to clean the surfaces of the machine. -
Page 16: Descaling The Machine
Avoid contact with eyes, skin and machine surfaces. Do not use vinegar: it could damage your appliance! During descaling, do not turn the machine off. CBTL™ recommends using the CBTL™ Descaler to descale your machine. Turn the machine off. Empty and rinse out the used capsule container and drip tray. - Page 17 Descaling the machine Place a container under the beverage dispensing spout. Make sure the lever is lowered. Keep the espresso and long espresso buttons pressed down and The long espresso button and the descale and alarm indicator simultaneously switch the machine on. lights blink alternately.
- Page 18 Descaling the machine At the end of a descale cycle, the long espresso button and the Carefully rinse out the water tank and fill it with filtered/bottled water. descale and alarm indicator lights blink alternately. Empty and rinse out the used capsule container and drip tray. The long espresso button and the descale and alarm indicator lights blink alternately.
- Page 19 Descaling the machine At the end of a rinse cycle, the long espresso button and the descale Carefully rinse out the water tank and fill it with filtered/bottled water. and alarm indicator lights blink alternately and the machine beeps. Empty and rinse out the used capsule container and drip tray. Press the long espresso button to exit the rinse cycle.
-
Page 20: Draining The Machine
Draining the machine CAUTION - When the machine is not used for a long time, it is necessary to drain the water lines. Liquids may freeze and damage the machine. Turn the machine off. Make sure the lever is lowered. Remove and empty out the water tank. -
Page 21: Troubleshooting
Empty out the used capsule container. ➤ Remove the used capsule. Beyond the recommended cleaning and maintenance procedures, the CBTL™ machine is not user serviceable. For additional options, please refer to the Limited Warranty Card . Technical data See the data plate on the bottom of the machine Max . - Page 22 CBTL Support Service ™ Country Contact Number Email 888-520-CBTL (888-520-2285) info@cbtl.com Singapore +65 6273-2221 CBTL@coffeebean.com.sg Malaysia (603) 92001833 CBTL@coffeebean.com.my Korea 82-2-548-0552 CBTL@coffeebeankorea.com +971 4 3539500 CBTL@coffeebean.ae Order Online at CBTL.com...
Need help?
Do you have a question about the KALDI S04 and is the answer not in the manual?
Questions and answers
Lever won't close
The lever on the CBTL KALDI S04 may not close if something is blocking it, such as a capsule jammed inside or a mechanical issue. It could also be due to trying to operate the machine incorrectly, like pressing a beverage button without inserting a capsule or raising the lever during brewing, which interrupts operation and causes the alarm light to blink. In such cases, closing the lever and pressing a beverage button can reset the machine.
