Ride-on static roller
Hide thumbs
Table of Contents

Advertisement

Quick Links

OPERATION AND PARTS MANUAL
MODEL R2000H
RIDE-ON STATIC ROLLER
(Honda GX240K1QAE2 ENGINE)
Revision #4 (07/24/08)
To find the latest revision of this
publication, visit our website at:
www.multiquip.com
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R2000H and is the answer not in the manual?

Questions and answers

Related Manuals for MULTIQUIP R2000H

Summary of Contents for MULTIQUIP R2000H

  • Page 1 OPERATION AND PARTS MANUAL MODEL R2000H RIDE-ON STATIC ROLLER (Honda GX240K1QAE2 ENGINE) Revision #4 (07/24/08) To find the latest revision of this publication, visit our website at: www.multiquip.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

  • Page 2: Proposition 65 Warning

    PROPOSITION 65 WARNING PAGE 2 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 3 NOTES R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 3...

  • Page 4: Table Of Contents

    Rear Drum Assembly ......... 44-45 NOTE Drive Assembly ..........46-47 Specification and Transmission Assembly........48-49 part number are subject to change Water System Assembly ........50-51 without notice PAGE 4 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)

  • Page 5: Parts Ordering Procedures

    All orders are treated as Standard Orders and will ship the same day if received prior to 3PM PST. WE ACCEPT ALL MAJOR CREDIT CARDS! R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 5...

  • Page 6: Specifications (Roller)

    PAGE 6 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)

  • Page 7: Specifications (Engine)

    0 . 4 9 . 6 1 . 6 . n i t h g l 1 . . s b 5 2 ( R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 7...

  • Page 8: Dimensions

    Figure 1. R2000H Roller Dimensions . N I l l a l l a . n i l l a . n i i r e . n i PAGE 8 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)

  • Page 9: Safety Message Alert Symbols

    Potential hazards associated with MQ R2000H vibration roller operation will be referenced with Hazard Symbols which appear throughout this manual, and will be referenced in conjunction with Safety Message Alert Symbols. R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 9...

  • Page 10: Safety Message Alert Symbols

    ALWAYS wear approved eye and hearing protection. This roller, other property, or the surrounding environment could NOTE be damaged if you do not follow instructions. PAGE 10 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)

  • Page 11: Rules For Safe Operation

    Multiquip for this equipment. Damage to the equipment and/or injury to user may result. ■ Manufacturer does not assume responsibility for any accident due to equipment modifications. R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 11...
  • Page 12 ■ In the event of hydraulic hose or line failure, promptly return the travel lever to the “neutral” position, stop the engine and set the parking brake. PAGE 12 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 13 ■ NEVER stand below roller when it is being lifted. DANGER : DO NOT allow personnel to stand under or near any suspended machine . Serious injury or death may result. R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 13...

  • Page 14: Operation And Safety Decals

    Machine Safety Decals The R2000H static roller is equipped with a number of safety decals. These decals are provided for operator safety and maintenance information. The illustration below and on the next page shows these decals as they appear on the machine. Should any of these decals become unreadable, replacements can be obtained from your dealer.

  • Page 15: General Information

    Travel speed is infinitely variable from 0 to 4 mph. The neutral position of this lever will cause the roller to stop. Figure 2. Recommended Slope R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 15...

  • Page 16: General Information

    , even death, if side-side operation is used (Figure 3). DO NOT use this roller for side to side applications. PAGE 16 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 17 NOTE PAGE R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 17...

  • Page 18: Roller Components

    R2000H — ROLLER COMPONENTS Figure 4. Roller Components PAGE 18 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)

  • Page 19: Roller Components

    15. Steering Zerk Fitting – Grease this fitting as recommended in the maintenance section of this manual. R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 19...

  • Page 20: Engine Components

    11. Circuit Breaker– Protects the battery charging circuit. See Fuel Valve Lever – OPEN to let fuel flow, CLOSE to stop Honda owner's manual for additional information. the flow of fuel. PAGE 20 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)

  • Page 21: Inspection

    3. When refueling, be sure to use a strainer for filtration. DO Figure 6. Engine Oil Dipstick (Removal) NOT top-off fuel. Wipe up any spilled fuel. R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 21...

  • Page 22: Inspection

    Protect water from freezing by adding antifreeze or draining water tank when not in use. Use only clean water in water tank. PAGE 22 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)

  • Page 23: Initial Start-Up

    Starting the Engine 1. Place the engine fuel valve lever (Figure 11) to the "ON" position. Figure 13. Choke Lever Figure 11. Engine Fuel Valve Lever R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 23...

  • Page 24: Operation

    2. To make the roller move in a forward direction , move the transmission control lever forward as shown in Figure 15. Make sure lever is securely place into notch. PAGE 24 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)

  • Page 25: Operation

    2. Place the engine fuel valve lever (Figure 11) in the OFF position. brake R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 25...

  • Page 26: Maintenance

    A shield or cover should be placed over the reservoir cover during cleaning operation or in other situations where water maybe introduced into the unit. PAGE 26 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)

  • Page 27: Maintenance

    5 lbs. of force applied to the center of the span between the sprockets toward the front of the roller. 8. If the tension is still incorrect, readjust. R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 27...
  • Page 28 If these gases and liquids come in contact with a flame Figure 22. Battery Fluid Levels or spark, an explosion could occur. PAGE 28 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)

  • Page 29: Preparation For Long-Term Storage

    Cover the roller and place it a clean dry area, that is protected from harsh elements. Remove ignition key, and store in a safe place. R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 29...

  • Page 30: Troubleshooting (Roller)

    . d l ? r i c a l . r i t l o , r e l o r . l a . r e PAGE 30 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)

  • Page 31: Troubleshooting (Engine)

    . y l i r p i r p i a f r u l l a i n i r R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 31...

  • Page 32: Explanation Of Code In Remarks Column

    A blank entry generally indicates that the item is not sold separately or is not sold by Multiquip. Other entries will be clarified in the “Remarks” Column. PAGE 32 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)

  • Page 33: Suggested Spare Parts

    3 ..17210ZE2822 ..ELEMENT, AC DUAL 3 ..9807955846 ..SPARK PLUG 1 ..17620ZH7023 ..CAP, FUEL TANK 1 ..1762ZE2W01 ..FILTER, FUEL TANK 3 ..35111880003 ..KEY, IGNITION R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 33...

  • Page 34: Name Plate And Decals

    R2000H — NAME PLATE AND DECALS NAME PLATE AND DECALS PAGE 34 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)

  • Page 35: Name Plate And Decals

    514418 DECAL, MQ STEERING WHEEL PLATE, SERIAL NO......1 ....CONTACT PARTS DEPT. 514424 KIT, R-2000 DECAL ......1 ....INCLUDES ITEMS W/ R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 35...

  • Page 36: Brake Assembly

    R2000H — BRAKE ASSY. BRAKE ASSY. PAGE 36 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 37 CAP SCREW 1/2” - 13 NC x 1” EM490952 SNAP RING 530346 LEVER, PIVOT 530347 BRACKET, BRAKE 29298-001 BRAKE BAND EM492566 JAM NUT 5/16” - 24 NF R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 37...

  • Page 38: Steering Assembly

    R2000H — STEERING ASSY. STEERING ASSY. PAGE 38 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 39 CHAIN LINK, OFFSET 5/8” 530280 CHAIN LINK, STRAIGHT 5/8” 530340 EXTENSION, CHAIN 530281 EXTENSION, CHAIN 530282 SPACER, CHAIN 6109160 NUT, HEX 1/2” 530278 CHAIN, ROLLER 24600-001 BUSHING R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 39...

  • Page 40: Chassis And Covers Assembly

    R2000H — CHASSIS AND COVERS ASSY. CHASSIS & COVERS ASSY. PAGE 40 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 41 W/ MODEL & SERIAL NO. 491757 RIVET 1/8” 530463 FLOOR PLATE, ALUMINUM 506158 BOLT, 5/16” x 3/4” 2105164 NUT, 5/16” 530464 GUARD, FRONT 505186 CUSION, RUBBER R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 41...

  • Page 42: Battery Assembly

    R2000H — BATTERY ASSY. BATTERY ASSY. PAGE 42 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 43 CLAMP, BATTERY 3019092 WASHER 3/8” 492379 CAP SCREW 3/8” 506266 BATTERY TERMINAL COVER ....1 ....RED 505624 BATTERY TERMINAL COVER ....1 ....BLACK R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 43...

  • Page 44: Rear Drum Assembly

    R2000H — REAR DRUM ASSY. REAR DRUM ASSY. PAGE 44 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 45 SCREW, CAP 7/16” 505081 HEXNUT 7/16” 530297 FRONT ROLL UNIT 24194-001 SPROCKET - 70 TOOTH 530298 SCREW, HEX 5/8” EM969023 NUT, HEX 5/8” 491214 PIPE PLUG R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 45...

  • Page 46: Drive Assembly

    R2000H — DRIVE SYSTEM ASSY. DRIVE SYSTEM ASSY. PAGE 46 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 47 SCREW, HEX 1/2” NC X 2-1/2” G5 530338 SPROCKET 15 TEETH, IDLER 530339 SPACER, TENSION 492584 NUT, NYLOCK 1/2” NC 490166 BOLT, HHCS, 3/8” X 3-1/2” G5 R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 47...

  • Page 48: Transmission Assembly

    R2000H — TRANSMISSION ASSY. TRANSMISSION ASSY. PAGE 48 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 49 530330 SHIFT HANDLE EM963692 SCREW, HEX 1/2” NC x 1-1/2” G5 504322 WASHER, FLAT 1/2 “ 6109180 WASHER, LOCK 1/2” 492584 NUT, NYLOCK 1/2” R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 49...

  • Page 50: Water System Assembly

    R2000H — WATER SYSTEM ASSY. WATER SYSTEM ASSY. PAGE 50 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 51 506072 PVC TUBE, REAR DRUM 1/2 x 17” .... 2 ....CUT TUBE LENGTH TO 15.5" 506071 ELBOW PVC 513869 TEE PVC TUBE 1/2” R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 51...

  • Page 52: Honda Gx240K1Qae2 Engine Air Cleaner Asssembly

    HONDA GX240K1QAE2 ENGINE — AIR CLEANER ASSY. AIR CLEANER ASSY. PAGE 52 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 53 ELBOW COMP., AIR CLEANER ....1 ..... INCLUDES ITEMS W/ % 90325044000 WINGNUT, TOOL BOX SETTING 90009ZE2003 BOLT- WASHER 6 X 22 9405006000 NUT, FLANGE 6MM R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 53...

  • Page 54: Camshaft Asssembly

    HONDA GX240K1QAE2 ENGINE — CAMSHAFT ASSY. CAMSHAFT ASSY. PAGE 54 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 55 RETAINER, IN. VALVE SPRING 14773ZE2000 RETAINER, EX. VALVE SPRING 14781ZE2000 ROTATOR, VALVE 14791ZE2010 PLATE, PUSH ROD GUIDE 90012ZE0010 BOLT, PIVOT 8MM 90206ZE1000 NUT, PIVOT ADJ. R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 55...

  • Page 56: Carburetor Asssembly

    HONDA GX240K1QAE2 ENGINE — CARBURETOR ASSY. CARBURETOR ASSY. PAGE 56 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 57 JET, MAIN #88 99204ZE20400 JET SET, PILOT #40 ......... 1 ..... INCLUDES ITEMS W/ % 16015ZE8005 CHAMBER SET, FLOAT ......1 ..... INCLUDES ITEMS W/ R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 57...

  • Page 58: Control Asssembly

    HONDA GX240K1QAE2 ENGINE — CONTROL ASSY. CONTROL ASSY. PAGE 58 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 59 90015ZE5010 BOLT, GOVERNOR ARM 90114SA0000 NUT, SELF-LOCK 6MM 93500050280A SCREW, PAN 5 X 28 93500050160A SCREW, PAN 5 X 16 9405006000 NUT, FLANGE 6MM R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 59...

  • Page 60: Crankcase Cover Asssembly

    HONDA GX240K1QAE2 ENGINE — CRANKCASE COVER ASSY. CRANKCASE COVER ASSY. PAGE 60 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 61 OIL SEAL 30 X 46 X 8 9410106800 WASHER, PLAIN 6MM 957010803500 BOLT, FLANGE 8 X 35 961006202000 BEARING, RADIAL BALL 6202 961006206000 BEARING, RADIAL BALL 6206 R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 61...

  • Page 62: Crankshaft Asssembly

    HONDA GX240K1QAE2 ENGINE — CRANKSHAFT ASSY. CRANKSHAFT ASSY. PAGE 62 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 63 CRANKSHAFT COMP., Q- TYPE ....1 ..... INCLUDES ITEMS W/ 13351ZE2010 WEIGHT, BALANCER 90745ZE2600 KEY 6.3 X 6.3 X 43 961006206000 BEARING, RADIAL BALL 6206 R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 63...

  • Page 64: Cylinder Barrel Asssembly

    HONDA GX240K1QAE2 ENGINE — CYLINDER BARREL ASSY. CYLINDER BARREL ASSY. PAGE 64 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 65 91353671003 O-RING 9405010000 NUT, FLANGE 10MM 9410912000 WASHER, DRAIN PLUG 12MM 9425110000 PIN, LOCK 10MM 957010601200 BOLT, FLANGE 6X12 961006202000 BEARING, RADIAL BALL 6202 R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 65...

  • Page 66: Cylinder Head Asssembly

    HONDA GX240K1QAE2 ENGINE — CYLINDER HEAD ASSY. CYLINDER HEAD ASSY. PAGE 66 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 67 BULK HOSE, VACUUM 11X1000, 11X100 957011008000 BOLT, FLANGE 10X80 9807955846 SPARK PLUG, BPR5ES, NGK 9807955855 SPARK PLUG, W16EPR-U, DENSO, OPTIONAL 9807956855 SPARK PLUG, W20EPR-U, DENSO R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 67...

  • Page 68: Fan Cover Asssembly

    HONDA GX240K1QAE2 ENGINE — FAN COVER ASSY. FAN COVER ASSY. PAGE 68 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 69 CLIP, TUBE 19610ZE2010ZA COVER COMP., FAN *R8* BRIGHT RED 19631ZE2D00 SHROUD 81329567020 GROMMET, DRAIN HOLE 90013883000 BOLT, FLANGE 6X12, CT200 90684ZA0601 CLIP, WIRE HARNESS R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 69...

  • Page 70: Flywheel Asssembly

    HONDA GX240K1QAE2 ENGINE — FLYWHEEL ASSY. FLYWHEEL ASSY. PAGE 70 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 71 PART NAME QTY. REMARKS 19511ZE2000 FAN, COOLING 28450ZE2W11 PULLEY COMP., STARTER, SCREEN GRID 31100ZE2832 FLYWHEEL COMP. 90201ZE3V00 NUT, SPECIAL 16MM 90741ZE2000 KEY, SPECIAL WOODRUFF 25X18 R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 71...

  • Page 72: Fuel Tank Asssembly

    HONDA GX240K1QAE2 ENGINE — FUEL TANK ASSY. FUEL TANK ASSY. PAGE 72 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 73 FILTER, FUEL 91353671003 O-RING 14MM, ARAI 9405008000 NUT, FLANGE 8MM 950014500360M BULK HOSE, FUEL 4.5X3000, 4.5X222 9500202080 CLIP, TUBE, B8 957010802500 BOLT, FLANGE 8X25 R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 73...

  • Page 74: Ignition Coil Asssembly

    HONDA GX240K1QAE2 ENGINE — IGNITION COIL ASSY. IGNITION COIL ASSY. PAGE 74 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 75 COIL ASSY., CHARGE (3A) 36101ZE1010 WIRE, STOP SWITCH 370MM 36103ZE1000 HOLDER, STOP SWITCH WIRE 90013883000 BOLT, FLANGE 6X12 90015883000 BOLT, FLANGE 6X28 90017883000 BOLT, FLANGE 6X32 R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 75...

  • Page 76: Starter Motor Assembly

    HONDA GX390K1QAE2 — STARTER MOTOR ASSY. STARTER MOTOR ASSY. PAGE 76 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 77 WIRE, WATER COVER 31233ZE2003 INSULATOR 90110ZE2003 SCREW-WASHER (4X6) 91601ZE2003 GASKET 90007ZE2003 BOLT-WASHER (5X14) 938920503208 SCREW WASHER 5X3 9407006080 NUT-WASHER (6MM) 957010804000 BOLT, FLANGE (8X35) R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 77...

  • Page 78: Control Box Assembly

    HONDA GX240K1QAE2 — CONTROL BOX ASSY. PAGE 78 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 79 93500040120H SCREW, PAN (4x12) 94001043900S NUT, HEX (4mm) 9411104800 WASHER, SPRING (4mm) 9820031500 FUSE, BLADE 15A 34150ZH7003 ALERT UNIT, OIL 9410104800 WASHER, FLAT (4mm) R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 79...

  • Page 80: Muffler Asssembly

    HONDA GX240K1QAE2 ENGINE — MUFFLER ASSY. MUFFLER ASSY. PAGE 80 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 81 GASKET, MUFFLER, ARRESTER 90013883000 BOLT, FLANGE 6X12 CT200 90050ZE1000 SCREW, TAPPING 5X8 90055ZE1000 SCREW, TAPPING 4X6 90050ZE1000 SCREW, TAPPING 5X8 9405008000 NUT, FLANGE 8MM R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 81...

  • Page 82: Piston Asssembly

    HONDA GX240K1QAE2 ENGINE — PISTON ASSY. PISTON ASSY. PAGE 82 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 83 ROD ASSY., CONNECTING STANDARD ....1 ..INCLUDES ITEMS W/ 13200ZE2305 ROD ASSY., CONNECTING, US 0.25, OPT... 1 ..INCLUDES ITEMS W/ 90001ZE8000 BOLT, CONNECTING ROD 90551ZE1000 CLIP, PISTON PIN 18MM R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 83...

  • Page 84: Recoil Starter Asssembly

    HONDA GX240K1QAE2 ENGINE — RECOIL STARTER ASSY. RECOIL STARTER ASSY. PAGE 84 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 85 28442ZE2W01 SPRING, STARTER RETURN 28443ZE2W01 SPRING RATCHET 28444ZE2W01 RETAINER, SPRING 28461ZE2W02 GRIP, STARTER 28462ZE2W11 ROPE, RECOIL STARTER 90004ZE2W01 SCREW, CENTER 90008ZE2003 BOLT, FLANGE 6X10 R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 85...

  • Page 86: Engine Labels

    HONDA GX240K1QAE2 ENGINE — ENGINE LABELS ENGINE LABELS PAGE 86 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 87 HONDA GX240K1QAE2 ENGINE — ENGINE LABELS ENGINE LABELS PART NO. PART NAME QTY. REMARKS 87521ZE2W01 EMBLEM, INTERNAL 87522ZH9000 LABEL, CAUTION 87528ZE2810 MARK, CHOKE, EXTERNAL 87532ZH8810 MARK, OIL ALERT, E R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 87...

  • Page 88: Terms And Conditions Of Sale

    Multiquip’s designated receiving point. at the time of any price change. PAGE 88 —R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08)
  • Page 89 NOTES R2000H RIDE-ON STATIC ROLLER — OPERATION & PARTS MANUAL — REV. #4 (07/24/08) — PAGE 89...

  • Page 90: Please Have The Model And Serial

    © COPYRIGHT 2008, MULTIQUIP INC. Multiquip Inc and the MQ logo are registered trademarks of Multiquip Inc. and may not be used, reproduced, or altered without written permission. All other trademarks are the property of their respective owners and used with permission.
