Mazda 2009 CX-7 Smart Start Manual

Mazda 2009 CX-7 Smart Start Manual

2009 mazda cx-7
Hide thumbs Also See for 2009 CX-7:
Table of Contents

Advertisement

Quick Links

See also: Instruction and Installation Manual , Manual
Optional equipment shown.
164817_09a_Mazda CX-7_SSG_080808.indd 1
8/8/08 2:22:15 PM

Advertisement

Table of Contents
loading

Related Manuals for Mazda 2009 CX-7

Summary of Contents for Mazda 2009 CX-7

  • Page 1 Optional equipment shown. 164817_09a_Mazda CX-7_SSG_080808.indd 1 8/8/08 2:22:15 PM...
  • Page 2 ADVANCED KEYLESS Advanced Key ENTRY SYSTEm • Advanced Keyless Entry allows you to lock/unlock the doors and liftgate of the vehicle, and even start the engine Lock without ever taking the key out of Panic Alarm your pocket. Unlock While carrying the Advanced Key you can... • L ock the vehicle by simply pressing the driver’s door request switch once. • C lose the windows and moonroof by pressing and holding the driver’s door request switch; release to stop. Auxiliary Key Door Request Switch • U nlock the vehicle by pressing the driver’s door request switch.

  • Page 3: Keyless Entry System

    KEYLESS ENTRY SYSTEm This system remotely locks and unlocks the doors and the liftgate, and opens the power Release windows and moonroof. Button • To extend the key, press the release button. Lock • T o retract the key, press the release button Unlock and fold the key back into the holder. Panic Alarm STARTiNg ThE ENgiNE wiTh ThE ADVANCED KEY While carrying the Advanced Key you can... • S tart the engine by pushing the Start knob all the way in. When the KEY indicator light illuminates green, turn the Start knob from the ACC position to the START position and hold until the engine starts. • S hut the engine OFF by turning the Start knob to the ACC position and then pressing in and turning to the Lock position.

  • Page 4: Rear Center Position Seat Belt

    Seats ELECTRONiCALLY OPERATED DRiVER SEAT Recline Switch P ush forward or backward to adjust seatback angle. Slide/Tilt Switch Push forward or backward to slide the seat bottom. The seat can also be raised, lowered or tilted with this control. REAR CENTER POSiTiON SEAT BELT • T o connect the seat belt, pull the seat belt from the ceiling recess and connect tongue A to buckle B. • T o wear the seat belt, slowly pull out the lap/shoulder belt and insert tongue C into the buckle D until a click is heard. • To unfasten the seat belt, depress the buckle button to release. Note: Leave the rear center lap portion of seat belt fastened at all times except when folding the rear seat. To stow the seat belt, insert a key or other small object into the anchor buckle slot to release entire belt. Let it fully retract. Then, put tongues A and C together and insert securely into roof recess. Roof Recess Anchor Buckle Slot 164817_09a_Mazda CX-7_SSG_080808.indd 4 8/8/08 2:23:25 PM...
  • Page 5 FOLDiNg SECOND-ROw SEATS Folding second-row seats 1 U nfasten the lap portion of the rear center seat belt. 2 Support the seatback with your hand. 3 Push the rear seatback knob down. 4 Bring the seatback forward. Seatback Knob Returning second-row seats to upright position 1 Raise seatbacks until they lock into position. 2 P ull on the top of the seatbacks from inside the vehicle to make sure they are locked. 3 Check that all seat belts are routed properly for passenger use. LiFTgATE • To open, pull up on the handle and raise the liftgate. • T o close, push the liftgate down with both hands until it securely locks, but do not slam.

  • Page 6: Driver's View

    Driver’s View (shown with optional LighTiNg/ TURN SigNAL hEADLighT LEVELiNg TRACTiON CONTROL SYSTEm (TSC) hOOD BLUETOOTh TiLT STEERiNg whEEL LEVER RELEASE & AUDiO (behind steering wheel) 164817_09a_Mazda CX-7_SSG_080808.indd 6 8/8/08 2:23:53 PM...

  • Page 7: Auxiliary Power Point

    Navigation System) wiPER/ iNFORmATiON hAzARD NAVigATiON/AUDiO wAShER DiSPLAY wARNiNg DiSPLAY AUDiO SYSTEm wiThOUT NAVigATiON CRUiSE CLimATE AUxiLiARY CONTROL/ CONTROL POwER POiNT BLUETOOTh 164817_09a_Mazda CX-7_SSG_080808.indd 7 8/8/08 2:24:11 PM...

  • Page 8: Instrument Cluster

    Instrument Cluster InSTruMEnT CluSTEr DIMMEr TACHOMETEr SPEEDOMETEr glOSSAry OF WArnIng AnD InDICATOr lIgHTS Please see Owner’s Manual for more details and explanations Engine Oil Pressure (Antilock Brake System) Tire Pressure Monitoring System (TPMS) TCS OFF (Traction Control System) Check Engine TCS/DSC (Traction Control System/ Dynamic Stability Control)

  • Page 9: Trip Meter

    gEAr InDICATOr ODOMETEr/ FuEl gAugE EngInE COOlAnT TrIP METEr TEMPErATurE gAugE ODOMETEr/TrIP METEr SElECTOr Shift Position KEy Warning light Advanced key not (rED) detected or transmitter Air Bag/Front Seat Belt battery is dead. Pretensioner System KEy Indicator light Charging System Advanced key (grEEn) detected;...

  • Page 10: Feature Highlights

    Feature Highlights wiNDShiELD wiPER/wAShER • M IST-Push the lever up for a single swipe to clear mist. • I NT-Push down to first position, rotate the inner ring for speed control. • LO-Push down to second position. • HI-Push down to third position. • P ull lever toward you to dispense washer fluid; the wipers will make several passes across the windshield. Rear window wiper/washer • Rotate the rear window wiper/washer outer control knob to the desired speed. OFF = OFF iNT = Intermittent ON = Normal speed = R ear wash/wiper cycle, hold as desired Less sensitive more sensitive 164817_09a_Mazda CX-7_SSG_080808.indd 10 8/8/08 2:24:40 PM...
  • Page 11 TURN SigNAL/LighTiNg CONTROL LEVER • R otate the outer knob up to the first position for tail, parking and dashboard lights. • R otate the outer knob up to the second position for tail, parking, dashboard, and headlights. • R otate the outer knob up to the third position for AUTO. • Rotate the inner ring for fog lamps. • P ush the lever away from you to turn the high beams on. • P ull the lever back one position to turn the high beams off. • P ull the lever all the way back and release to flash the high beams. Outer Knob inner Ring AUTO With the headlight switch in AUTO position and the ignition ON, the light sensor determines the surrounding lightness or darkness and automatically turns the headlights, other exterior lights and dashboard illumination on or off.
  • Page 12 Feature Highlights SPORT AT mANUAL ShiFT mODE The Sport AT Manual Shift Mode gives you the feel of driving a manual transmission by allowing you to manually shift to control engine rpm and torque when more control is desired. To Use Manual Shift Mode: Shift the lever from D to M. Note: Changing to manual mode can be done while driving the vehicle. To Shift Up To A Higher Gear: Tap the shift lever back (+) once. To Shift Down To A Lower Gear: Tap the shift lever forward (-) once. TURBOChARgER TiPS After driving at freeway speeds or up a long hill, idle engine at least 30 seconds in order to cool turbocharger. Avoid shutting the engine off abruptly after a hard or long drive as turbocharger damage may result.
  • Page 13 homeLink indicator Light Auto-Dimming On and Off Light Sensor AUTO-DimmiNg miRROR AND hOmELiNK ® Auto-Dimming mirror • A uto-Dimming will automatically darken your rear view mirror to reduce headlight glare from vehicles behind you. • T he Auto-Dimming feature is active when the vehicle is started and cancels when the transmission in placed in Reverse. homeLink ® • T his feature provides a convenient way to replace up to three transmitters such as garage door openers, home lighting remotes and other radio frequency devices. • Refer to your Owner’s Manual for complete programming details. 164817_09a_Mazda CX-7_SSG_080808.indd 13 8/8/08 2:25:08 PM...
  • Page 14 Feature Highlights BACK-UP CAmERA (only with Navigation System) This automatically operates when the gearshift lever is put into Reverse and is viewable via the navigation display screen. When using the back-up camera, please check your surroundings as objects may be closer than they appear. Back-up Camera 164817_09a_Mazda CX-7_SSG_080808.indd 14 8/8/08 2:25:16 PM...
  • Page 15 mP3 PLAYER iNTEgRATiON USiNg ThE AUx jACK Your vehicle is equipped with an AUX or auxiliary jack that will allow you to play your MP3 player through the vehicle’s audio system. 1 Locate the AUX jack inside the center console. 2 P lug your MP3 player into the AUX jack and turn it on. 3 Turn the vehicle audio system on. 4 P ress the MEDIA button on the audio face, or the Mode button on the steering wheel controls. 5 U se the MP3 player controls to play back music. Note: Set the volume level on your MP3 player to the highest level before distortion starts. Then, adjust volume in the vehicle using the audio system power/volume control or the steering wheel volume up and down controls. 164817_09a_Mazda CX-7_SSG_080808.indd 15 8/8/08 2:25:30 PM...

  • Page 16: Manual Climate Control

    Manual Climate Control Temperature Fan control dial mode selector dial control dial • R otate the knob • R otate the knob to • P ush the to set desired fan select airflow mode. button to turn Air speed (1-4). Conditioning ON D ashboard and OFF. vents • P ush button • R otate the knob to recirculate D ashboard and to select a warmer...

  • Page 17: Automatic Climate Control

    Automatic Climate Control information Display AUTOmATiC AiR CONDiTiONiNg 1 Push AUTO dial to turn the automatic air conditioning system on. 2 R otate AUTO dial to the desired cabin air temperature setting (shown in the Information Display above). 3 Push OFF dial to turn climate control system off. Push to defrost the front windshield. Push to select desired airflow. Push to manually turn on/off and control the air conditioning system. Rotate fan speed dial to desired fan speed. Push to recirculate cabin air and reduce outside exhaust, odors and improve cooling. Push to defrost the rear window. Push to display the ambient temperature in the Information Display. information Display Functions • Clock • C limate Control Display • A udio Display • A mbient Temperature Display • B luetooth Hands-Free Display • P assenger Air Bag Off Indicator...
  • Page 18 Audio Controls Without Navigation SETTiNg YOUR CLOCK 1. Turn the ignition switch to the ACC or ON position. 2. Press and hold the CLOCK button for 1-1/2 seconds until the displayed time flashes. 3. Use H to set hours and M to set minutes, then press the CLOCK button. Audio System On Tuning • P ress the POWER/VOLUME T he radio has the following button to turn the radio on. tuning controls: • MANUAL media selection • TRACK/SEEK • FM 1/2 • SCAN • AM • PRESET CHANNEL • SAT (SIRIUS...

  • Page 19: Scan Tuning

    Scan tuning Auto-memory • P ress the SCAN button This is especially useful when to automatically sample driving in an area where the local strong stations. stations are not known. Additional AM/FM stations can be stored • T o hold a station, press without disturbing the previously the SCAN button again set channels. Refer to your Owner’s during this interval. Manual for complete details. Preset channel tuning The 6 preset channels can be used to store 6 AM and 12 FM stations. • T o set a channel, first select AM, FM1, or FM2. • Tune to the desired station. • P ress and hold a preset button until a beep is heard. • R epeat this operation for the other stations and bands you want to store.
  • Page 20 Audio Controls With Navigation Audio System On Seek tuning • P ress a band selector button • P ress and hold the SEEK TUNE (FM/AM) to turn the radio on. button to automatically seek a higher or lower frequency or track, depending media selection on media selected. • P ress the appropriate button: Note: If you continue to press and hold FM/AM, SAT (SIRIUS Satellite the button, the frequency will continue radio), CD, MEDIA (to switch to changing without stopping. AUX jack input) Scan tuning Tuning • P ress the SCAN button • T he radio has the following to automatically sample...
  • Page 21 SETTiNg YOUR CLOCK 1. Press the MENU button 2. Select the Set Clock tab. 3. C hoose a 24-hour display or a 12-hour display. 4. U se the + hour and - hour tabs to enter the correct hour. 5. Press the OK tab to exit. Note: Minutes and seconds are adjusted by the GPS, however, it is necessary to adjust hours under the following conditions: • Driving across different time zones • Daylight saving time start and end Sound • R epeat to store other stations. To tune one in memory, select • P ress the SOUND button to the band, then press its channel enhance sound settings.

  • Page 22: Navigation System

    Navigation System SELECTiNg A DESTiNATiON USiNg A STREET ADDRESS You can choose setting a destination using a street address, a point of interest, the nearest restaurants, ATMs, gas stations, hospitals and more. 1 Press the “Menu” button on the navigation face. 2 Select “Destination Entry”. 3 Select “Change” and then select your desired search area. 4 S elect State (or scroll past States to find Canadian Provinces) 5 Select “Address”. 6 S elect “City”. 7 Select “Input City Name”. 8 U se keyboard to enter city name, street name and house number. 9 When all the information is correct, press “OK”. Note: When entering numbers for a street name, (e.g. 1st Ave.), press “Sym.” button to switch to the numeric keyboard. Note: If you cannot find the address in the state you are looking for, you may have the wrong area selected. Press “Menu” to go back to the beginning and select the correct area on the US map.
  • Page 23 SELECTiNg A POiNT OF iNTEREST (POi) NEAR YOUR CURRENT LOCATiON 1 Press the “Menu” button on the navigation face. 2 Select “Destination Entry”. 3 Select “Point of Interest”. 4 Select “Nearest”. 5 Select “Current Position”. I n the QUICK POI screen, select the category of the point of interest you want to find. You can set multiple categories for searching up to five. 7 After selecting categories, press “List”. 8 S earch result shows up as a list in “LOCAL POIs” screen. Select the point of interest you want to set as the destination from the list. 9 Press “Destination”. 10 Press “Guide” or just start driving. Please refer to your Navigation System Owner’s Manual for complete details and important safety information. 164817_09a_Mazda CX-7_SSG_080808.indd 23 8/8/08 2:26:28 PM...
  • Page 24 Bluetooth ® without Navigation System (Refer to your Owner’s Manual for Bluetooth with Navigation operations) ® PAiRiNg YOUR BLUETOOTh PhONE ® Note: Before pairing your cell phone, it is recomended that you refer to you phone’s manual for steps to turn on Bluetooth and perform pairing. These steps will be required to perform steps 7-8 below. 1 Press the button located on the steering wheel. 2 From the options and after the beep say, “Set-up”. 3 F rom the next prompt options after the beep, say, “Pairing options”. 4 T he prompt will give you some more options. After the beep, say, “Pair”. 5 T he prompt will ask you for a 4-digit pairing code. After the beep, say any 4-digit code you’d like to use. 6 T he prompt will repeat the number and ask if it is correct. After the beep, say, “Yes” if it is or “No” if it isn’t. If it’s not, the system will repeat the process.
  • Page 25 TO mAKE A hANDS-FREE CALL To make a hands-free call, press the button and after the beep say, “Dial”. 2 S ay the number you would like dialed. The prompt will repeat the number and ask if it’s correct. If it is say, “Yes” and the prompt will say it’s dialing. 3 T o receive an incoming call, just press the button. To end a call or reject a call, press . A beep will confirm the call is ended. Note: When using voice recognition, wait until beep. Prompt can be interrupted by pressing TALK button. Sound quality of Bluetooth streaming audio varies depending on device.
  • Page 26 Notes 164817_09a_Mazda CX-7_SSG_080808.indd 26 8/8/08 2:26:31 PM...
  • Page 27 MyMazda.com—The Official Site for Mazda Owners Register today on MyMazda.com—the ultimate destination for Mazda Owners. Once registered, you’ll be able to take advantage of benefits exclusively for Mazda Owners: • I nsider access to exclusive events and promotions • Personalized maintenance schedules • Zoom-Zoom Owner Magazine • W arranty information and on-line Owner’s Manuals • Wallpaper, videos and other fun stuff...
  • Page 28 Customer Delivery Checklist VEhiCLE PRESENTATiON: Refer to the Smart Start Guide during presentation Keyless Entry ......... Exterior Lighting Controls ..• Keyless Entry Transmitter • A dvanced Key* • D oor Request Switches* • Liftgate Request Switch* • Power Door Locks AUx input ........Starting The Engine ....... Climate Control ......15-16 • Start Knob Ignition • Auto Mode*...

  • Page 29: Warranty Information

    Customer Delivery Checklist DEALERShiP DATE SALES CONSULTANT CUSTOmER’S NAmE E-mAiL PRESENTATiON OF OwNER’S mATERiALS: Review the following items with the customer Smart Start guide mymazda.com • R emove this checklist from • O ffer to register customer on Smart Start Guide MyMazda.com warranty information Owner’s manual • B asic Vehicle – 36 months/36,000 miles • Roadside assistance program SERViCE DEPARTmENT...
  • Page 30 SERViCE Because you and your Mazda deserve the best Your new Mazda deserves nothing less than the very best. To keep it running like new for years to come, trust the experts at your local authorized Mazda Dealer. Simply bring your vehicle in for your scheduled maintenance and any needed repairs.* At Mazda Full Circle Service Centers,** our technicians will automatically perform a complimentary Full Circle inspection on your vehicle and issue a detailed report card at every visit. This is designed to help you keep track of your Mazda’s critical operating condition. Our factory-trained technicians know your vehicle inside out and use Genuine Mazda Parts, giving your vehicle the optimum care and maintenance it requires to run with flawless precision. Remember, to further enhance your driving experience, visit your local Mazda Service Center for your scheduled maintenance. It’s also the place where you can find a wide variety of tires, parts, and accessories that are just right for your vehicle. * See vehicle’s scheduled-maintenance program for details. ** Visit mymazda.com/fullcircle for a list of Full Circle Service Centers...
