Appendix B Wiring Diagram

This section provides an example illustration of an input and output wiring scheme. Before making any connections,
please turn off ALL audio and video devices. Unplug those that do not have a main power switch. It is recommended
that all cables, including speaker cables be kept as short as possible for best sound quality.
From analog pre-
amp/processor
To Speakers—main
(or Woofer Section)
To Speakers—Bi-Wire
(Treble Section)
Figure 5 - Examples of Typical Input and Output Connections
From trigger output
