TOWN SQUARE SHOWER WALL FOR CORNER
INSTALLATION
Product Features:
• Dupont Corian
®
surface
• High gloss surface finish
• Simulated grout lines for luxurious tile
appearance
• Finished edge treatment
• Concealed corner and wall seams
• Premium wall height
• Installs over bath grade water proof
dry wall
3838.CWTS
For use with 3838.NEOTS Shower Base
3838.NEOETS2 Clear Glass
For use with 3838.NEOTS Shower Base
3838.NEOETS6 Antique Glass
For use with 3838.NEOTS Shower Base
To Be Specified:
Color: (see below)
COLOR
SOLIDS
GLACIER WHITE
PATTERNS
AURORA
DUSK
VENARO WHITE
BV-45
ABBREV. CODE
GLW
950
AUR
996
SDK
998
VEW
965
© 2004 American Standard Inc.
TOWN SQUARE™ SHOWER WALLS
FOR CORNER INSTALLATION
Model No.
3838.CWTS
34-1/2 W x 76 H
(876 x 1930mm)
NOTES:
REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH BATH WALLS FOR ADDI-
TIONAL INFORMATION.
IMPORTANT:
Dimensions of fixtures are nominal and may vary within the range of tolerances estab-
lished by ANSI Standard Z124.3.
These measurements are subject to change or cancellation. No responsibility is assumed
for use of superseded or voided leaflet.
DUPONT CORIAN
Side Panels
Corner Panels
(2 ea.)
(1 ea.)
1-1/2 x 1-1/2 x 76 H
(38 x 38 x 1930mm)
®
9/04
