Dymo LetraTag LT-100T Quick Reference Manual

LT-100T
Quick Reference Guide
2
Inserting the Label Cassette
1. Lift the label cassette cover to open the
label compartment. See Figure 2.
2. Remove the protective cardboard insert
from label exit slot. See Figure 3.
3. Insert the cassette with the label
positioned between the print head and
pinch roller.
4. Press firmly until cassette clicks into
place.
5. Close the label cassette cover and press
to turn on the power.
Remove
cardboard insert
3
Selecting a Language
1. Press .
2. Use the up or down arrow key to select Language and press
3. Use the up or down arrow key to select the language you want and
press .
Getting to Know Your Label Maker
Font Size # Lines CAPs Num Lock
Label Exit
Power
Cutter
Insert
Format
Settings
Clear
4
Setting the Date and Time
1. Press .
2. Select Set Date and press
3. Use the left or right arrow key to move the cursor over each setting
Figure 2
(month, day, and year) and use the up or down arrow key to increase
or decrease the value.
4. When finished, press
5. Use the left or right arrow key to move the cursor over each setting
(hours and minutes) and use the up or down arrow key to increase or
Figure 3
decrease the value.
6. When finished, press
5
Printing Your First Label
.
1. Enter text to create a simple label.
2. Press .
3. Press the cutter button to cut the label.
4. Remove the paper backing from the label to expose the adhesive, and
then attach the label.
Memory Memory
Save Recall Print LCD Display Power Connector
OK
Navigation
Cancel
Cancel
Num Lock
CAPs
Clear
Backspace
Space Bar
. The default date is displayed.
. The default time is displayed.
.
About Your New Label Maker
With your new DYMO LetraTag® label maker, you can create a wide
variety of high-quality, self-adhesive labels. The label maker uses
DYMO LetraTag (LT) 1/2 inch (12 mm) label cassettes. LT label cassettes
are available in a variety of colors and materials such as paper, plastic,
metallic, magnetic, and iron-on.
Visit www.dymo.com for a complete User Guide, and for information
on obtaining labels and an optional AC adapter for your label maker.
Product Registration
Visit www.dymo.com/registration to register your label maker online.

Getting Started

Follow the instructions in this section to print your first label.
1
Inserting the Batteries
1. Remove the battery compartment cover.
2. Insert the batteries following the polarity
markings (+ and –).
3. Replace the cover.
! Remove the batteries if the label maker
will not be used for a long period of time.
Designing Your Label
Changing the Font Size
Five font sizes are available for your labels:
Extra Small
Extra Large
Large
, and .
1. Press the key.
2. Select Size and press .
3. Select the desired font size and then press
Adding Font Styles
You can choose from six different font styles:
Normal
Bold
Italic
1. Press .
2. Select Style and press .
3. Select a font style and press .
Creating Two-Line Labels
1. Type the text for the first line and press
2. Select Second Line and press . A multi-line symbol is inserted at
the end of the first line, but will not print on the label.
3. Type the text for the second line.
Figure 1
, , Medium,
Small
.
Outline
Shadow
Vertical
.
Continued
