Phillips Pm2.5×6.0 Captive Screw - HP PAVILION DV5 Maintenance And Service Manual

Phillips PM2.5×6.0 captive screw
Color
Black
Where used:
(1) One captive screw that secures the Mini Card module compartment cover to the computer (screw
is secured by a C-clip)
(2) One captive screw that secures the memory module compartment cover to the computer (screw is
secured by a C-clip)
(3) Two captive screws that secure the hard drive bay compartment cover to the computer (screws are
secured by C-clips)
Quantity Length
4 6.0 mm
Thread Head diameter
2.5 mm 5.0 mm
Phillips PM2.5×6.0 captive screw 131
