- Page 1 TOSHIBA AMERICA INFORMATION SYSTEMS STORAGE DEVICE DIVISION IRVINE, CALIFORNIA MK3019GAX (HDD2172) 2.5-INCH HARD DISK DRIVE USER MANUAL Rev 02 11/2006...
-
Page 2: Table Of Contents
CONTENTS Introduction................1 Setup ..................2 Using the HDD .................4 Troubleshooting...............5 Specifications ................6 Drive Connectors..............8... -
Page 3: Introduction
9.5mm High • 12ms Average Seek Time • ATA-2,3,4,5 Interface • Supports high transfer rates of 100 MB/sec • 16MB Buffer • MTTF 300,000 Hours *Toshiba defines a megabyte (MB) as 1,000,000 bytes and a gigabyte (GB) as 1,000,000,000 bytes. -
Page 4: Setup
Master/Slave Settings Your Toshiba Hard Disk Drive can be configured as either a "Master" or "Slave" unit. Master configuration is used for all single drive applications, and master or slave configuration (only one of each per port) is used for two drive applications. - Page 5 Placing Hard Drive inside your Computer • Determine mounting configuration (the drive can be mounted in either a horizontal or vertical orientation) • Configure drive for system application. • Configure the adapter board for the specific system application (if required). •...
-
Page 6: Using The Hdd
USING THE HARD DISK DRIVE – MK3019GAX (HDD2172) Backing up Data Files To avoid data loss, regularly back up the data files on the hard disk drive. -
Page 7: Troubleshooting
Manager DiskGo by Ontrack. Check with your local computer/software supplier for availability or contact the software manufacturer. How do I install my 2.5" Toshiba Hard Drive into my You will need a HDD mounting kit in order to install a desktop or tower system? Toshiba 2.5"... -
Page 8: Specifications
Internal Transfer Rate 200.8 ~ 333.2 Mbits/sec (max) Host Transfer Rate 100Mbytes/sec *Toshiba defines a megabyte (MB) as 1,000,000 bytes and a gigabyte (GB) as 1,000,000,000 bytes. Internal Drive Characteristics Number of Disks Number of Read/Write Heads Track Density (TPI) 57.1k... - Page 9 Physical Height 0.37" (9.5mm) Width 2.75" (69.85mm) Depth 3.94" (100mm) Weight 3.563oz (101g) typ Regulatory The drive satisfies the following standards: Underwriters Laboratories (UL) 1950 Canadian Standard Association (CSA) C22.2 No.220 No. 950 TUV Rheinland EN 60 950 EMC - EN50081-1 EN55022: 1988 Class B EN60555-2: 1987+ A1 EN60555-3: 77A (Co) 38...
-
Page 10: Drive Connectors
DRIVE CONNECTORS –MK3019GAX (HDD2172) Figure 1.MK3019GAX HDD Rear View - Connectors Interface Connector Drive Side Connector Yamaichi GAP050K11617 or equivalent Recommended Host Side Connector Board Straight type: Berg 86455-044 86456-044 or equivalent Cable Berg 89361-044 or equivalent Recommended Cable Characteristics Standard diameter 0.32mm (28AWG) - Page 11 Interface Pin Assignment DRIVE INTERFACE SIGNALS SIGNAL SIGNAL RESET GROUND DD 7 DD 8 DD 6 DD 9 DD 5 DD 10 DD 4 DD 11 DD 3 DD 12 DD 2 DD 13 DD 1 DD 14 DD 0 DD 15 GROUND DMARQ...
