Night Owl CAM-OV600-365 Quick Setup Manual

Connecting your camera to your DVR / TV / Monitor (DVR / TV / Monitor is not included):
1. Locate the 60ft. BNC cable, BNC to RCA connector, power adapter, and the camera.
2. Locate the end of the 60ft. BNC cable labeled "TO CAMERA".
3. Connect the yellow BNC adapter on the 60ft. BNC cable to the yellow BNC adapter on the camera.
4. Connect the red RCA power adapter on the 60ft. BNC cable to the red RCA power adapter on the camera.
5. Locate the end of the 60ft. BNC cable labeled "TO DVR". If connecting to your TV / Monitor locate the BNC to
RCA connector.
6. If connecting to a DVR, connect the yellow BNC adapter on the 60ft. BNC cable to channel input on the back of
the DVR. The channel inputs are labeled by number.
If connecting to a TV / Monitor, connect the BNC to RCA connector (BNC end; the flat end with the two
notches) to the yellow BNC adapter on the 60ft cable. Connect the BNC to RCA connector (RCA end) to the
Video input on your TV/ Monitor. Keep in mind if your camera is plugged into a TV / Monitor it will not record
any videos.
7. Connect the red RCA power adapter on the 60ft. BNC cable to the power adapter.
8. Plug the power adapter into a wall socket or a surge protector.
Your camera is now connected and is ready for use.
NOTE: Connect the camera and cable to the DVR/TV/Monitor before mounting to ensure that they work properly.
Quick Set-up Guide
Model CAM-OV600-365
