Audio (optional)
The onboard Audio provides either of the following features:
• 5.1 Channel High Definition Audio Codec
• DACs support 96K/48K/44.1KHz sample rate
• Power support: Digital:3.3V; Analog:5.0V
TM
• WOW and Tru Surround
• Provides single ended CD input with DRM solutions and legacy OS
issues
• 7.1+2 Channel High Definition Audio Codec
• SPDIF In/Out supports 96K/48K/44.1KHz plus SPDIF OUT supports
88.2KHz
• Power supports: Digital:3.3V; Analog:5.0V
• MAxx PlayerTM from waves
• Provides single ended CD input with DRM solutions and legacy OS
issues
Expansion Options
The motherboard comes with the following expansion options:
• One PCI Express x16 for Graphics Interface
• One PCI Express x1 slot
• Two 32-bit PCI v2.3 compliant slots
• One IDE connector supporting up to two IDE devices
• Six 7-pin SATA connectors
This motherboard supports Ultra DMA bus mastering with transfer rates of 133/
100/66/33 MB/s.
Integrated I/O
The motherboard has a full set of I/O ports and connectors:
• Two PS/2 ports for mouse and keyboard
• One serial port
• One VGA port
• Four USB ports
• One LAN port
• Audio jacks for microphone, line-in and 6/8-ch (optional) line-out

BIOS Firmware

The motherboard uses AMI BIOS that enables users to configure many system
features including the following:
• Power management
• Wake-up alarms
• CPU parameters
• CPU and memory timing
The firmware can also be used to set parameters for different processor clock
speeds.
1. Some hardware specifications and software items are subject to change
without prior notice.
2. Due to chipset limitation, we recommend that motherboard be oper-
ated in the ambiance between 0 and 50 °C.
Introducing the Motherboard
TM
from SRS
